Precision is not one number. A ±0.005 mm callout on a bore is a different job from ±0.005 mm across a 900 mm face. The first depends on spindle and tool runout. The second depends on machine geometry, thermal drift and how the part is clamped. When a precision CNC China supplier accepts your drawing without asking which dimensions are functional, treat the quote as a placeholder.

Most well-run shops in Dongguan hold ±0.005 mm on features under roughly 100 mm, with a temperature-controlled room and a probe on the machine. Beyond 500 mm, ±0.02 mm is the honest working tolerance unless the shop has both a large-travel machine and a metrology plan for it. Ask which machine will cut the part and what its stated positioning accuracy is. The answer should arrive without a pause.

Surface finish and tolerance are linked. Ra 0.2–0.8 μm usually needs a finishing pass with a small stepover and a sharp tool, which adds time. Ra 0.8–1.6 μm is a normal machined finish for mating faces. Ra 1.6–3.2 μm is fine for brackets and covers. If a quote offers Ra 0.4 μm at the price of Ra 3.2 μm, one of the two numbers is wrong.

A part with features on five faces and a compound angle is a 5-axis job. Doing it on 3-axis means three or four re-fixtures, and every re-fixture adds stack-up error and labor. The question is not whether a shop owns a 5-axis center, but whether the programmer will use simultaneous motion or just index the table and call it 5-axis. Ask how many setups the process needs. One is a good sign. Four is a warning.

Size decides the machine class more than tolerance does. A 4,000 × 400 × 150 mm envelope covers long rails, beams and extrusion profiles. A 750 × 1,150 × 550 mm machine handles most plate work. Compact 500 × 500 × 450 mm centers are efficient for small, high-mix parts because the spindle moves less and the thermal load stays low. Sending a 40 mm fitting to a large gantry wastes setup time and money.

Turning and milling on one platform matters for parts with concentric features plus cross-drilled holes. A mill-turn center holds that relationship in a single setup, which removes the coaxiality error you get from moving between a lathe and a mill. If your part has a bore, a face and radial holes with a position callout, ask whether it runs on a mill-turn or in two operations.

Every supplier claims quality control. The useful question is what gets measured and who signs it. A three-stage flow covers incoming raw material, in-process checks and final inspection. For a tight part, final inspection should happen on a CMM with a report keyed to the drawing balloons, not a caliper reading typed into a spreadsheet. Ask for one sample report before you place the order.

Certifications tell you which industries the quality system was built for. ISO 9001:2015 covers general machining. IATF 16949:2016 is what automotive and EV programs expect, including traceability and change control. ISO 13485:2016 is the medical baseline. ISO 27001:2022 covers information security, which matters when you send CAD files and customer drawings. Check the scope statement, not just the logo.

Qualification rate is a number worth asking for, but ask how it is defined. A shop reporting 99.99% may mean first-pass yield on shipped parts, or it may mean something looser. What you want to know is the rework and scrap rate on parts within your tolerance band. A shop that tracks that number is a shop that understands its own process.

For prototypes, MOQ is the wrong lever to pull. A supplier with no minimum order quantity will run one piece and give you a real DFM note on it. That single part often saves more money than a discount on a later run, because it exposes a wall thickness that will warp or a corner the tool cannot reach. Prototype-stage engineering support is the actual product.

Lead time has three parts: quote, production start and shipping. A quote with free DFM inside 12 hours and production starting within 24 hours is a shop with a standing engineering queue. Parts shipping in 3–5 days is normal for machined aluminum and steel under 500 mm. Anything faster usually means the part sits in a queue elsewhere or the tolerance was quietly relaxed.

Read the quote line by line. Material, machining, finishing, inspection and freight should each be visible. A single lump sum hides where the cost is, and it makes it hard to compare two suppliers. If the quote includes a DFM note, read it. The notes about thin walls, deep pockets and thread depth are the ones that decide whether the part comes back correct.

Aluminum 6061-T6 is the default for machined prototypes and light production parts. It cuts fast, holds tolerance and anodizes cleanly. 7075 offers higher strength but machines slower and is tougher on tooling. Stainless 303 and 304 are common for food, medical and marine hardware; 17-4PH is the choice when you need strength plus corrosion resistance and can accept heat treatment. Titanium Ti-6Al-4V and Inconel cut slowly and need rigid setups, so expect longer lead time and higher cost.

Finishing is often where a good part turns into a rejected one. Anodizing adds a thin oxide layer that can shift a tight bore by a few microns. If a bore mates with a pin, mask it or hold the pre-plate dimension accordingly. Hardcoat and conductive anodizing behave differently again. For a first article, always confirm which surfaces are masked and which are functional.

Laser marking has a practical limit. A minimum character height of 1.5 mm keeps the mark legible after anodizing or powder coating. Smaller text fills in and becomes unreadable. If your part needs a serial number or a logo, plan the marked area as a machined or masked surface so the contrast survives the finish.
