A medical part rarely fails because the machine was not accurate enough. It fails because the tolerance stack was never assigned. When you call out ±0.005 mm on a bore, the machinist has to hold the tool, the fixture, the thermal drift and the probe inside that number. On a 40 mm bore in 316L, that is realistic on a 5-axis mill-turn center. On a 300 mm thin-wall housing, it is not, and the drawing should say so.

Start by splitting the budget. Datum features and mating surfaces deserve the tight callouts. Clearance holes, cable routes and cosmetic faces usually do not. If every dimension is tight, the process route gets longer, the part gets more setups, and each extra setup adds a new source of error. A well-split budget often allows a two-setup route instead of four.

Thermal behavior matters more on medical work than on general machining. Titanium and stainless cut hot. A spindle that runs for six hours will move a few microns as the casting and the ballscrews warm up. Shops that hold ±0.005 mm do it with temperature-controlled rooms, in-process probing, and a warm-up cycle before the first cut, not with a better operator.

The engineering takeaway is simple. Tolerance is a process decision, not a wish. Tell your supplier which features touch the patient, which features mate with other parts, and which are structural only. That single conversation usually removes more cost than switching suppliers.

• 1
  Assign, do not defaultTighten only the features that mate or contact tissue.
• 2
  Count the setupsEvery extra setup re-datums the part and adds error.
• 3
  Watch heatTi-6Al-4V and 316L both grow with spindle temperature.

Simultaneous 5-axis machining is not a marketing feature. It changes what is possible. When the tool can tilt, you can reach under a flange, machine a compound-angle port in one pass, and keep a single datum through the whole operation. On bone plates, surgical handles and orthopedic trial components, that means fewer fixtures and fewer re-clamps.

The measurable gain is in the surface. With a tilted tool you can keep the contact point near the tool tip and hold a consistent stepover on a curved face. That is how a contoured surface comes off the machine at Ra 0.8–1.6 μm instead of Ra 1.6–3.2 μm, which then reduces hand polishing. Hand polishing on a medical part is a risk: it rounds edges, changes wall thickness, and adds a manual step that is hard to validate.

There are limits. Simultaneous motion needs a rigid setup. Long, thin end mills deflect, and no amount of rotary motion fixes a tool that is chattering. Deep cavities smaller than Ø6 mm with a 5:1 depth-to-diameter ratio are often better done on a 3-axis machine with a long reach tool and a slower feed, or split into two parts.

For a part like an instrument jaw or a bone screw guide, the decision is usually about access, not about tolerance. If the tool can reach the feature from three directions with a 3-axis setup, use it. If it cannot, 5-axis is cheaper than three separate fixtures.

• 1
  One datum, one setupRotary motion keeps the part on the same reference.
• 2
  Better surface on curvesTilted tooling holds a consistent stepover.
• 3
  Know the limitDeep, narrow cavities still favor long-reach 3-axis work.

The material list for medical work is short for a reason. Each alloy brings a specific mechanical or biological property, and each one cuts differently. Picking the alloy is a design decision. Cutting it is a process decision, and the two have to agree before the first chip.

316 and 316L stainless are the workhorses for instrument bodies, brackets and housings. They resist corrosion and clean well, but they work-harden. A light pass that rubs instead of cuts will harden the surface and dull the next tool. Machinists counter this with a positive rake geometry, a deeper depth of cut, and no dwelling in the cut. 17-4PH (SUS630) is chosen when you need higher strength after heat treatment, and it machines better in the solution-treated condition than after aging.

Titanium TC4 (Ti-6Al-4V) is used for implants and load-bearing instruments. It has low thermal conductivity, so heat stays in the cutting zone and goes into the tool. Tool life drops fast if you push speed instead of feed. Feeds stay aggressive, speeds stay low, and coolant flow has to reach the tip, not the part.

PEEK and POM cover insulators, seals and fluidic manifolds. Both are dimensionally stable when machined dry with sharp tooling, but PEEK is abrasive on cutters and absorbs little coolant, so chip evacuation has to be designed into the program. Aluminum alloys such as 6061-T6 and 7075 suit housings and heat sinks, and they cut fast, which makes them the right choice for early prototypes.

• 1
  Stainless work-hardensCut deep enough to stay under the hardened layer.
• 2
  Titanium traps heatLow speed, high feed, coolant at the tip.
• 3
  Plastics need sharp toolsDull edges cause melting and burrs, not chips.

A machined edge is never finished when the spindle stops. It carries a burr, and on a medical part that burr is a functional defect. It can shed particles, injure a gloved hand, or block a fluid channel. Deburring is a process step with its own tooling, not a favor the operator does at the end.

Edge break callouts should be explicit. On a machined surface, a 0.2 mm edge break is a real feature. Specify it, and expect it to be produced with a controlled tool path or a dedicated deburring tool. On parts that touch tissue, a radiused edge is often specified rather than a chamfer because it distributes contact stress and is easier to verify visually.

Surface finish follows the same logic. Ra 0.2–0.8 μm on a sealing face is achievable, but it usually means a finishing pass with a small stepover, and then a controlled polish that does not change the geometry. Bead blasting, tumbling and brushing change the surface texture and can hide a scratch. If the finish is functional, say what the function is.

For stainless parts, passivation removes free iron left by cutting tools and restores the passive oxide layer. Electropolishing goes further and smooths micro-peaks, which helps in fluid paths. Both add lead time, so decide early whether the part needs them or whether a clean machined finish is enough.

Cleaning closes the loop. A machined part holds chips in blind holes, in thread roots and under a flange. A documented wash, a dry, and a particle check belong in the route before the part reaches final inspection.

• 1
  Specify the edgeA 0.2 mm break is a feature. Write it down.
• 2
  Finish has a functionSay whether it is sealing, sliding or cosmetic.
• 3
  Clean before inspectBlind holes and thread roots hide chips.

A process is only as good as the evidence behind it. On medical work, the drawing defines the part and the inspection record defines the proof. That record has to be built into the route, not added the day before shipping.

The first article is where the route is validated. A machinist cuts the part, the CMM or vision system measures the critical features, and the results either confirm the setup or send it back. If the first article passes only after a manual adjustment to the program, the process is not stable. A stable process repeats the first article on the tenth part and the hundredth part.

In-process probing helps on long runs and on parts with tight positional tolerance. A probe can check a datum, update the work offset, and keep the next part aligned to the same reference. It does not replace final inspection, but it reduces drift across a batch.

Material traceability is part of the same record. The mill certificate follows the bar stock to the finished part, so the alloy and the heat lot can be traced later. When a customer asks for a full inspection report with dimensional results, that report is generated from the same measurement data used to make the accept or reject decision. Nothing is written from memory.

For parts that will be validated, it helps to agree on the inspection plan early. Which features are measured, on what equipment, and to what resolution. Once that plan is fixed, the manufacturing route can be designed around it instead of the other way around.

• 1
  First article proves the routeIf it needs a manual tweak, the process is not stable.
• 2
  Probing reduces driftWork offsets stay aligned across a batch.
• 3
  Trace the heat lotMill certificates follow the bar to the finished part.
