CNC prototyping removes material instead of adding it. That single fact shapes every design decision. An internal channel that a printer builds in one pass becomes a deep cavity that needs a long, slender tool, and slender tools deflect. If the channel does not need to be round, a slot the cutter can reach is faster and more accurate.

Start by asking which features actually have to be in the first article. A prototype usually exists to test fit, function or a specific failure mode. If the goal is to confirm that a bracket bolts to a frame, the mounting pattern and hole diameters matter. Surface finish on a non-contact face does not. Splitting the requirements this way keeps the part simple enough to machine in one or two operations.

Compare that with additive methods. A 3D printed part can carry internal lattices and undercuts that no cutter reaches. Those shapes are real advantages when the geometry itself is the thing being tested. For a housing with internal ribs and no mating hardware, printing may be the better first step, then switch to CNC once the rib layout is settled.

The practical rule: choose CNC when the prototype must behave like the production part in metal, when tolerances are tighter than about ±0.1 mm, or when the material is a specific alloy that will carry into production. Choose printing when the geometry is the question and the material is not.

Every dimension on a drawing carries a cost once the tolerance tightens. A blanket ±0.005 mm note across a whole part forces the shop to slow down, take lighter cuts and inspect more. On a prototype that runs 3–5 days, that is time you may not need to spend.

Apply tight tolerance only to features that mate. Bearing bores, dowel holes, seal grooves and connector seats are worth ±0.005 mm. Overall length, non-mating faces and clearance holes are fine at ±0.1 mm or looser. Mark the tight ones individually on the drawing rather than with a general block tolerance.

Surface finish follows the same logic. Ra 0.2–0.8 μm is available for sealing faces and sliding surfaces. Ra 0.8–1.6 μm covers most functional prototypes. Ra 1.6–3.2 μm is the as-machined result and is usually enough for a fit check. Ask for a finer finish only where a seal, O-ring or optical surface touches.

One more habit worth building: put the datum on the drawing. When the model has no defined datum, the programmer picks one, and the inspection report may not line up with your design intent. A datum that matches how the part mounts in the assembly removes that ambiguity.

Thin walls are the most common cause of a prototype that measures wrong. Cutting force pushes the wall away from the tool, the wall springs back after the pass, and the finished dimension sits outside the band. In aluminum, keep walls at 1.0 mm or more. In stainless and steel, 1.5 mm is a safer floor. Plastics such as POM and ABS need 1.5–2.0 mm because they deflect more before they cut.

Internal corners need a radius. A square internal corner cannot be cut by a round tool, so the shop either leaves a radius or the part gets a sharp notch that concentrates stress. A good starting point is a corner radius at least one third of the pocket depth. A 12 mm deep pocket wants a 4 mm radius or larger.

Pocket depth has its own limit. A tool can only reach about three to four times its diameter before it starts to chatter. A 6 mm wide, 30 mm deep pocket is at that edge. If the design needs deeper, widen the pocket or split the part so the cavity is open on one side.

Threads are worth checking too. A tapped hole needs about 1.5 times the nominal diameter in thread depth to develop full strength. Below that, the thread strips before the bolt does. Add the depth to the model rather than leaving it to the machinist's judgment.

For a first article, 6061-T6 aluminum covers more prototyping needs than any other metal. It machines fast, holds ±0.005 mm, takes anodizing and bead blasting well, and is stocked in most bar and plate sizes. If the prototype is for an enclosure or a bracket, start there.

Move to 7075 when the part needs higher strength, and to 304 or 316L stainless when corrosion resistance or a food and medical environment is the driver. Titanium Ti-6Al-4V and Inconel are available, but they cut slowly and tool wear is high, so they belong in a prototype only when the production part will use the same alloy.

Plastics behave differently. POM is dimensionally stable and good for moving parts. PEEK handles heat and chemicals but costs more and needs sharp tooling. ABS and PC are common for covers and housings. Carbon fiber reinforced grades wear tools quickly and are better suited to a later stage once the geometry is frozen.

Stock size is often the hidden delay. When the CAD model fits a standard plate or bar, machining can start within 24 hours. A near-net forging or an unusual extrusion may take days to source. If the prototype is urgent, design around standard stock and note the production stock separately.

A 3-axis machine cuts from one direction at a time. Every new face means a new setup, and every setup reintroduces a small alignment error. On a part with four angled faces, those errors add up and the prototype can drift out of tolerance even when each individual cut is accurate.

A simultaneous 5-axis center tilts the tool and rotates the part at the same time. Compound curves, deep cavities and angled holes that would need three or four fixtures on a 3-axis machine come off in one setup. That is the main reason to route a prototype to 5-axis: fewer setups, less stacked error.

Typical parts that benefit are turbine and impeller blades, medical instrument bodies with angled lumens, and automotive housings with curved sealing faces. If your part is mostly prismatic with holes on two or three perpendicular faces, a 3-axis or 4-axis machine is usually the faster and cheaper route.

One caution for the model. Simultaneous 5-axis cutting needs smooth toolpaths. Sharp changes in surface curvature cause the machine to accelerate and decelerate hard, which leaves marks. Blending adjacent surfaces with a small fillet, 0.5–1.0 mm, gives the toolpath something to follow.
