A guitar is a stack of tolerances. Neck pocket depth, heel angle, bridge position, fret slot spacing, pickup cavity depth. Each one is small, and all of them add up along the string path. Hand building controls those numbers with jigs, feel, and repetition. CNC controls them with a digital model and a machine that repeats the same cut thousands of times.

The change is not about shape. Most acoustic and electric bodies were already shaped well by hand. The change is about the dimensions you cannot see: how deep the neck pocket sits relative to the top, how parallel the fretboard is to the string plane, how repeatable the bridge screw pattern is across a run of 200 units.

A guitar with CNC keeps those hidden numbers inside a known band. On our 5-axis centers the working tolerance is ±0.005 mm on metal hardware, and wood parts typically hold tighter than ±0.1 mm because the cut is deterministic and the fixture is rigid. That repeatability is the product, not the surface finish.

It also moves labor. Roughing a body outline, cutting a neck profile, drilling a tuner pattern, and pocketing a control cavity are hours of hand work per instrument. Those hours can go into final fretwork, neck fitting, and setup instead, which is where a player actually feels the difference.

The sequence matters more than the machine. Cut the reference surfaces first, then everything else is located from them. If you cut the outline first and the neck pocket last, you are stacking error on error.

For a bolt-on electric body, a typical order is: face the top and back flat, machine the neck pocket and the neck heel as a matched pair, then drill the bridge and pickup cavities from the same zero. Do the outline last. A 3-axis machine can handle most of this if you flip the part with a locating pin, but a 5-axis center lets you cut the pocket walls and the arm contour in one setup, which removes the flip error entirely.

For necks, the truss rod channel is the feature that punishes sloppy work. Cut it before the profile. If the channel wanders 0.3 mm off center, the rod binds and the neck will not adjust cleanly. Rough the profile with a 12 mm end mill, then finish with a 6 mm ball nose at 0.2 mm stepover.

Wood moves after machining. A body cut on Monday can shift 0.2 mm by Friday as moisture equalizes. That is why we rough, rest, and finish rather than cutting to final size in one pass. On a 4,000 mm machine bed we can also fixture two or three bodies at once, which keeps the setup cost per unit down.

• 1
  Reference firstFace and square the blank before any pocket is cut.
• 2
  Match the pairNeck pocket and heel should be cut from the same zero point.
• 3
  Rough, rest, finishLeave 0.5 mm stock, let the wood settle, then take the final pass.
• 4
  One setup wins5-axis removes flip error on contoured pockets and carves.

Machining wood is not machining aluminum. Density varies along the grain, and a cutter that holds ±0.02 mm in 6061 will deflect in a soft spruce top. Feed rates need to drop, and climb milling with a sharp upcut spiral leaves fewer tear-outs on figured maple.

Metal parts behave better. Bridge plates, tuner housings, control plates, pickup rings, and tremolo blocks are conventional precision work. We machine 6061-T6, 7075, brass C36000, stainless 303 and 316L, and titanium TC4 in the same shop that cuts the wood fixtures. That matters because a bridge plate and the body pocket it sits in should come from one tolerance budget.

Composites and carbon fiber are the awkward middle. They cut cleanly with diamond-coated tooling but the dust is abrasive and gets into everything. If a design uses a carbon fiber neck or a composite top, plan for dedicated fixturing and a slower spindle speed to avoid delamination at the edges.

Finish choice follows material. Anodizing gives a bridge plate a hard, thin skin that does not change the fit. Powder coating adds 60–100 μm per side and will change a press fit, so mask the mating surfaces. Laser marking on a control plate needs a minimum character height of 1.5 mm to stay legible.

CNC cannot voice an instrument. It can cut a top to 2.8 mm thickness with a repeatable graduation, but it cannot decide that this particular piece of spruce wants to be 2.6 mm near the bass side. That call comes from tapping, flexing, and experience.

Fretwork is the clearest split. A machine can cut slots and radius the board. Leveling, crowning, and polishing the frets is still a hand process because it depends on the actual relief under string tension, which only exists once the instrument is strung up.

Setup is the same story. Nut slot depth, saddle height, intonation, and pickup height are tuned to the player. A machine can get you within 0.1 mm of a target. The last 0.1 mm is feel and ear.

So the honest boundary is this: CNC owns geometry, repeatability, and the parts that must interchange. Hand work owns tone, feel, and the final adjustment. A shop that treats CNC as a replacement for the second group usually builds instruments that measure well and play flat.

Individually, each guitar feature is easy. The neck pocket is ±0.05 mm, the bridge holes are ±0.03 mm, the fret slots are ±0.05 mm. Add them along the string path and the total error can reach 0.3 mm, which is audible as intonation drift and felt as uneven action.

Stack-up analysis is the tool that catches this before cutting. Assign a tolerance to every feature that sits between the nut and the bridge. If the sum exceeds your playability budget, tighten the two features with the highest contribution or move them into the same setup.

The practical trick is to define one datum on the body and reference every critical feature to it. On a bolt-on design, that datum is usually the neck pocket floor. Bridge position, pickup routes, and control cavity all reference back to it. One datum, one error source.

For a run of 200 units, this is what makes the difference between an instrument that needs 20 minutes of setup and one that needs two hours. Our inspection record on production runs sits at a 99.99% qualification rate, and 100% inspection before shipment is where that number comes from, not from the machine spec sheet.

Sharp internal corners cannot be cut by a round tool. If a pickup cavity has a 0.5 mm internal radius and you plan to use a 6 mm cutter, the tool will not reach the corner. Either specify a corner radius at least half the cutter diameter or accept a relieved corner.

Deep pockets need relief. A control cavity 40 mm deep with vertical walls and a 6 mm cutter needs a tool length around 60 mm, which deflects. Add a draft or step the depth so a shorter, stiffer tool can reach the floor.

Thin walls move. A body section thinner than 3 mm will vibrate during the cut and chatter. If the design calls for a thin wall, add temporary support ribs and cut them away in a later pass, or accept a slower feed and more finishing time.

Threaded features in wood are unreliable. Use a metal insert, a threaded bushing, or a through-bolt pattern instead. If the design needs threads in metal, we cut them on a mill-turn center and inspect the pitch diameter, not just the major diameter.
