A machine is not used up as a whole. It wears part by part, and the parts wear at different rates. Spindle bearings, linear ways or box ways, ball screws, the tool changer, and the controller each have their own clock. Two machines of the same model and year can be 10 years apart in remaining life because of how they were run.

The spindle is where money disappears fastest. Bearings degrade with speed-hours, not calendar years. A machine that ran 8,000 rpm in aluminium for a decade may be in better shape than one that ran 20,000 rpm for two years in hardened steel. Ask for spindle hours, not just machine hours. If the seller cannot show them, treat the spindle as unknown.

Ways and ball screws follow a different curve. A machine that cut light passes in aluminium for 15 years can still hold ±0.01 mm, while one that roughed steel forgings for three years may have 0.05 mm of lost motion in X. Contamination matters more than load: fine cast iron dust and dry chips grind a way surface like lapping compound.

The controller ages on a software and support clock, not a mechanical one. A 2008 Fanuc control still has parts and service. A discontinued control from a builder that left the machine tool business may leave you hunting eBay boards. Before you negotiate price, check that the control still has a service channel and a post-processor your CAM software supports.

Bring an indicator, a test bar, and a dial test indicator with 0.001 mm resolution. On a vertical mill, sweep the spindle taper with a test bar at 300 mm from the gauge line. More than 0.02 mm of runout usually means bearing replacement, which on a large spindle can run into five figures and weeks of downtime.

Check squareness and geometry with a granite square and a ball bar if you have one. A quick circularity test on a 300 mm circle tells you more about a machine than a full day of cutting sample parts. Look for a consistent error shape: a lobed circle points to a mechanical problem, while a shifting centre points to a control or servo tuning issue.

Backlash is the cheapest thing to measure and the most expensive to ignore. Mount an indicator on the table against the spindle nose, jog the axis 0.10 mm in one direction, then reverse. On a healthy machine you should see 0.005–0.01 mm of lost motion. Anything above 0.03 mm on a machine you intend to hold ±0.01 mm is a rebuild, not an adjustment.

Run the spindle through its full speed range and listen. A bearing on its way out changes tone above 60% of maximum rpm. Check the lubrication system, the way covers, and the chip conveyor too. Those are low-cost items on paper but they tell you whether the previous owner did any preventive maintenance at all.

The purchase price is the smallest number in the equation. Add rigging and transport, foundation work if the machine needs a pit, power and air connections, a post-processor for your CAM system, and operator training on an unfamiliar control. On a mid-size VMC those items often add 15–30% to the invoice before the first chip.

Plan for the first repair window. A second-hand machine that has sat idle for a year will usually need way lube lines flushed, seals replaced, and a full geometry check after it is levelled. Budget for it rather than being surprised by it. A machine that was in daily production until last month is usually the safer buy.

Parts availability sets the ceiling on how long you can keep the machine running. Before you commit, price the three items most likely to fail: spindle bearings, a servo drive, and a control board. If any of those is unobtainable or quoted above 20% of the machine price, the economics change.

Resale matters less than people think, but support matters more. A widely sold model with an active user forum and third-party repair shops will keep running long after a rare machine becomes a parts donor. That is the single best predictor of whether a used CNC is a good deal.

A used machine fits when your tolerance is achievable and your volume is modest. If your parts sit at ±0.05 mm and you run 50 to 500 pieces a month, a well-kept 3-axis VMC from a major builder is a sound buy. You get a rigid iron structure that a new machine at the same price cannot match.

A used machine is the wrong choice when the process window is tight. Hard turning, high-speed aluminium with small tools, or any job needing ±0.005 mm on a production basis belongs on a machine with known geometry and a documented spindle history. Rebuilding a worn machine to that level often costs more than a new one.

Five-axis work is the hardest case. A used 5-axis machine may need a full kinematic calibration, and rotary table wear is expensive to correct. Unless you can verify the rotary axes yourself, price the machine as a 3-axis machine with a tilting table and treat the extra axes as a bonus.

The practical test is simple. Can you inspect the first article on your own equipment and prove it holds over 30 parts? If yes, buy. If you need the seller's promise to feel confident, keep looking.
