Coolant has three jobs: remove heat, reduce friction at the tool-chip interface, and flush chips out of the cut. Synergy 735 CNC coolant is a water-miscible fluid built around those three jobs. The water carries heat away; the concentrate adds lubricity, corrosion protection and biological control. None of these work alone.

Heat is the first problem. In aluminum at 12,000 rpm, the edge can see several hundred degrees Celsius in the shear zone. Water absorbs that heat far better than oil, which is why water-miscible fluids dominate milling. If heat stays in the part, the part grows. A 200 mm aluminum plate can move 0.05 mm from a 10 °C rise, which is enough to lose a ±0.005 mm tolerance.

Lubricity matters more at low speed. Tapping 304 stainless at 8 m/min is a boundary-lubrication problem, not a cooling problem. The polar additives in the concentrate form a thin film that keeps the chip from welding to the flute. Run the same tap dry and you will hear it before you measure it.

Flushing is the quiet job. Deep pockets and cross-drilled holes trap chips that recut and wreck surface finish. Coolant delivered at pressure clears them. On a 4,000 mm gantry part, poor flushing shows up as Ra drift long before the tool wears out.

So the fluid is a system: water, concentrate, additives and delivery. Change one and the other three shift. That is why mix ratio and flow rate get more attention here than brand claims.

A water-miscible concentrate is a package: base oil or synthetic ester, emulsifiers, corrosion inhibitors, extreme-pressure additives, biocides and defoamers. When you mix it with water, the emulsifiers lock the oil into droplets a few microns across. That emulsion is what you pump.

Droplet size drives stability. Too coarse and the emulsion splits, leaving oil on the walls and rust on the part. Too fine and you lose lubricity because the droplets no longer plate out at the edge. Most shops never measure droplet size; they judge by whether the sump looks milky and whether the walls stay clean.

The corrosion inhibitors are sacrificial. They bond to bare steel and aluminum and get consumed over time. When concentration drops, the inhibitor film thins and you get flash rust on fixtures overnight. That is a concentration problem, not a fluid problem.

Biocides are the other consumable. Bacteria and fungus feed on the oil phase and on tramp oil. Once the population grows, the sump smells and the pH drops. A stable emulsion with the right biocide package holds pH between 8.5 and 9.5, which is where most ferrous protection works.

Tramp oil is the main destabilizer. Way lube and hydraulic oil float, get emulsified by the pump, and feed the microbes. If your sump has a thick brown layer, fix the machine leak before you buy a different coolant.

This fluid is aimed at general machining of aluminum, steel, stainless and copper alloys. It handles milling, turning, drilling and light grinding on machines with a normal coolant system. It is not a replacement for neat oil in high-pressure deep-hole drilling or in gear hobbing, where extreme-pressure load is far higher.

Aluminum is the easy case. 6061-T6, 7075 and 2024 cut cleanly with good cooling and moderate lubricity. The risk is staining from high pH, so keep concentration in the middle of the range and rinse parts before they sit overnight.

Stainless and titanium are the hard case. 316L and Ti-6Al-4V work-harden instantly and hold heat at the edge. Here you need higher concentration, higher flow and sharp tools. If the operation is a deep pocket in titanium, consider high-pressure through-tool delivery or a switch to a heavier fluid.

Magnesium is the case to avoid. Water-miscible fluids react with magnesium chips and can generate hydrogen. AZ31B and AZ91D belong on a dedicated machine with a dedicated fluid, not on a shared sump.

Cast iron is the messy case. Graphite fines load the sump and the fluid turns gray. It still machines, but you will filter more often and change the charge sooner.

• 1
  Good fitAluminum and brass milling, general steel turning, mixed-machine shops.
• 2
  Workable fit316L and 17-4PH with higher concentration and pressure.
• 3
  Poor fitMagnesium, deep-hole drilling, gear cutting with heavy EP demand.

Concentration is the single largest lever. Most general machining runs between 6% and 10% by volume. Aluminum usually sits at 6–8%. Stainless and titanium push toward 8–12% for extra lubricity and corrosion protection. Below 5%, you lose both.

Measure with a refractometer, not by eye. Refractometers read the dissolved solids, and the conversion factor differs by fluid. If the label factor is 1.0, the reading equals the concentration. If it is 1.5, divide the reading by 1.5. Get this wrong and you will run at half strength for months.

pH should sit between 8.5 and 9.5. Below 8.0, ferrous parts flash rust and the sump smells. Above 9.8, aluminum can stain and skin irritation rises. A drop in pH usually means microbial growth, not a bad batch of concentrate.

Water quality matters more than most shops admit. Hard water above 200 ppm as CaCO3 leaves scale and shortens emulsion life. Use softened or deionized water where you can. Chloride above 100 ppm raises the risk of pitting on stainless.

Refractometer checks: daily on the machine, weekly on the central sump. Log the number. A single reading tells you little; a trend tells you when tramp oil or evaporation is winning.

Temperature control is often ignored. Keep the fluid between 20 °C and 30 °C at the nozzle. Below 15 °C, mist and foaming rise. Above 35 °C, bacteria multiply faster and the fluid life drops sharply.

A sump is a living system. Every week it gains tramp oil, metal fines, bacteria and evaporated water. If you only top up with concentrate, the additives and the water balance drift apart. Top up with premix at the target concentration, never with neat concentrate.

Skim tramp oil at least once a week. A belt skimmer or a coalescer removes the free oil layer before the pump emulsifies it. If your machine has a leaking way-lube line, fix the leak. No coolant survives a steady oil feed.

Filtering fines extends life. A 50 μm bag or a chip conveyor with a fine screen keeps graphite and aluminum dust out of the recirculation loop. In cast iron cells, filter at 25–50 μm and clean the screens daily.

Fluid life in a well-managed sump runs several months. In a neglected sump it can fall to a few weeks. The gap is mostly tramp oil and concentration control, not the fluid itself.

When you dump a charge, treat it as chemical waste and follow local rules. Do not pour it into a storm drain. Most regions classify water-miscible coolant as industrial wastewater and require pH adjustment before discharge.

Keep a simple log: date, concentration, pH, temperature, tramp oil depth, action taken. When a finish problem appears, the log usually shows the cause two weeks earlier.

The main exposure route is mist and skin contact. Enclosed machines with good extraction keep airborne mist low. Open machines need local exhaust and a splash guard. If you can smell the sump across the aisle, extraction is not working.

Skin contact causes dermatitis more often than any chemical hazard. Provide gloves and barrier cream, and wash with mild soap, not solvent. Solvent washing strips the skin and makes the next exposure worse.

Aerated fluid is the enemy. High-pressure nozzles and a low fluid level whip air into the emulsion and create mist. Keep the level above the pump inlet and use the lowest pressure that still clears chips.

Bacteria are a smell and a pH problem before they are a health problem. A clean sump, correct concentration and weekly skimming keep the population in check. Biocide top-ups are a fix, not a routine.

If an operator reports a rash, check concentration and pH first. Over-concentration and high pH are common causes, and both are easy to correct.
