A CNC razing machine is a finishing machine. The cutting tool is driven by a pin or arbor, the workpiece is held in a clamp and rotates relative to the tool, and the relative motion between tool and part forms the tooth or the finished profile. Because the cut is light and the surface is the product, the machine is sensitive to vibration and to any runout that a roughing machine would tolerate without complaint.

That changes the maintenance priority. On a heavy mill you can run a worn way for a shift and still hold size. On a razing machine the same wear shows up immediately as a wavy surface, an out-of-round bore, or a tooth profile that drifts along the part. Operators who treat it like a general-purpose machine usually lose the finish before they notice the cause.

The machine also runs at higher spindle speed with a smaller chip load. Heat builds in the spindle and in the workholding, not in the chip. So the checks that matter here are spindle condition, lubrication film, alignment, and thermal stability, in that order.

GreatLight runs this class of finishing work on 127 high-precision CNC machines across three wholly-owned plants in Dongguan and Singapore, holding ±0.005 mm (±0.0002 in) and finishes down to Ra 0.2–0.8 μm. The routine below is the same one we apply to our own razing and finishing cells before any part is released.

Start before the spindle turns. Wipe the taper and the tool holder with a clean lint-free cloth and check for scoring or fretting marks. A 0.01 mm chip pressed into the taper is enough to push runout past the limit and leave a mark on every tooth of the part.

Check the coolant. On a razing machine the coolant does two jobs: it cools the contact zone and it flushes fine chips away from the workholding. If the concentration drifts below the maker's range, typically 6–10 percent for a water-miscible fluid, the chips start to pack in the clamp and the part moves. Measure with a refractometer, not by eye.

Then check lubrication. Look at the way lube pump reservoir and the pressure gauge on the lube line. A pump that has lost pressure leaves a dry film on the ways and the slide starts to stick-slip, which shows as a periodic mark at the same pitch as the axis lead.

Finish with a warm-up cycle. Run the spindle at 25 percent of maximum speed for 10 minutes, then 50 percent for 5 minutes, then the working speed. A cold spindle with tight preload will grow 10–20 μm as it heats, and that growth moves the tool relative to the part.

• 1
  Taper and holderWipe clean, inspect for fretting, never seat a holder with a visible chip on the flange.
• 2
  Coolant strengthRefractometer reading in the maker's range, usually 6–10 percent.
• 3
  Way lubeReservoir above the low mark, pressure gauge steady at the setting.
• 4
  Warm-up10 min at 25 percent speed, 5 min at 50 percent, then cut.

Spindle condition decides the finish more than any other single item on a razing machine. Measure runout with a dial test indicator mounted on the table, touching a precision test bar held in the spindle. Take the reading at the gauge line, not at the end of a long bar, because bar deflection adds error that is not in the spindle.

For finishing work, keep radial runout at the gauge line inside 0.005 mm and axial runout inside 0.003 mm. If the reading is above that, clean the taper first and repeat. If it stays high, the problem is in the taper seat or the bearings and belongs with a service engineer, not with an in-house adjustment.

Listen as well as measure. A bearing that is starting to fail makes a higher-pitched noise at speed and the noise changes with spindle temperature. Record the sound at the same speed each week, or record spindle vibration if you have a meter. The trend is more useful than a single reading.

Never run the spindle above its rated speed to chase a finish. Higher speed raises heat and preload, and on a light finishing cut the extra speed usually makes the surface worse, not better.

The lubrication film on the ways is what keeps the slide moving in small, smooth increments. On a razing machine the axis moves are short and slow, which is exactly the condition where a marginal film turns into stick-slip. Keep the lube pump interval at the maker's setting and check that every distribution point actually receives oil, not just that the pump runs.

Filtration matters as much. Fine chips from a finishing cut are small enough to pass a coarse screen and reach the way wipers. Replace or clean the wipers on schedule, and change the coolant filter when the pressure drop rises, not when the flow stops. A blocked filter raises coolant temperature and that heat goes into the workholding.

Temperature is the quiet variable. A razing machine that holds ±0.005 mm in the morning can drift out of tolerance by mid-afternoon if the shop warms by 5 °C. Keep the machine away from direct sunlight and from door drafts, and let the spindle warm up before the first finishing pass.

If your parts are large, remember that a 4,000 mm maximum processing size part grows with temperature as well. On a 300 mm aluminium part, a 5 °C rise moves the part about 0.02 mm. That is four times the tolerance band, so thermal control is not optional on this class of work.

Check squareness and parallelism after any crash or after moving the machine. On a small machine, a 0.01 mm per 300 mm squareness error is a normal starting point; if the reading is worse, realign before you run production. Use a granite square and a dial indicator, and repeat the check at two heights so you catch a tilt, not just an offset.

Backlash on the finishing axis should stay under 0.005 mm. Measure it by approaching a position from both directions with an indicator on the slide. If backlash is growing, check the thrust bearing and the coupling before you compensate in the control. Compensation hides the wear and the wear continues.

Workholding deserves its own check. On a razing machine the part is clamped and turns against the tool, so clamp force and clamp concentricity both print onto the part. Indicate the clamp bore each week. A clamp that is 0.02 mm off center will make an out-of-round tooth no matter how good the spindle is.

Finally, keep a simple log. Date, spindle runout, backlash, squareness, coolant concentration, and any noise noted. After three months you will see which value moves first, and that value is the one to watch.

Some work belongs in-house and some does not. Daily cleaning, coolant checks, lubrication top-ups, runout measurement, backlash measurement and clamp indication are all operator-level tasks. They need a clean machine, a dial indicator and a log.

Spindle bearing replacement, taper regrinding, ball screw replacement and control parameter changes are not operator tasks. If runout stays above 0.005 mm after a clean taper, or if backlash stays high after checking the thrust bearing, stop. Running the machine in that state wears the part, and it wears the spindle faster.

The same rule applies to alignment after a crash. If squareness moves more than 0.01 mm per 300 mm or the machine will not hold level, realign with the maker's procedure and a certified square. Guessing the correction in the control offset usually makes the geometry worse and hides the real error.

A finishing machine that is maintained on schedule holds ±0.005 mm for years. One that is run until it fails usually needs a spindle rebuild, and that costs more than the routine ever would.
