A router is a computer-controlled cutting machine built around a large flat table. The controller reads G-code, breaks each move into short segments, and sends step and direction signals to the servo or stepper drives. Each drive turns a ball screw or a rack and pinion, and the cutting head follows the programmed path. Nothing about the motion is manual, so the same file produces the same shape on the tenth run and the thousandth.

The frame decides what the machine can hold. A gantry router carries the spindle on a bridge that spans the table, so the bed can stay open and long. A moving-table router pushes the workpiece instead. The gantry design keeps the motor load steady on wide parts, but the bridge can flex if the beam is thin. On a 2,400 mm span, a few tenths of a millimeter of sag shows up in the finished depth.

Most shop routers run three axes: X and Y across the bed, Z down through the stack. Some add a fourth axis as a rotary table, usually Ø200 to Ø400 mm, which lets the tool index around a cylinder. Five-axis routers tilt and rotate the head or table together, so undercuts and angled faces come off in one setup. That extra motion is what separates routing from simple panel cutting. The mechanics are the reason the limits exist, and the limits are what matter on the shop floor.

The spindle is the part that turns the cutter, and its power sets the ceiling on material removal. A 3 kW to 6 kW spindle handles MDF, plywood, ABS and acrylic all day. Aluminum needs more torque at low rpm, so a 9 kW to 12 kW spindle with a proper collet is the practical floor for plate work. Below that, the tool rubs instead of cutting, and the edge work-hardens.

Tool holding matters as much as power. An ER32 collet chuck is common on wood routers and holds well enough for Ø6 mm to Ø20 mm tools. For metal, a hydraulic or shrink-fit holder keeps runout under 0.01 mm, which lengthens tool life and holds wall thickness. A worn collet adds runout that no program can correct.

Feeds and speeds follow the same logic as any milling operation. In 6061 aluminum, a Ø10 mm three-flute carbide tool runs around 8,000 to 12,000 rpm, 1,500 to 2,500 mm/min, 1 to 2 mm depth of cut, with air blast or mist. On MDF, a Ø12 mm compression bit runs 18,000 rpm and 6,000 to 9,000 mm/min. Listen to the cut. Chatter means the feed is too high or the tool is too long.

Routers earn their keep on sheet goods. Plywood, MDF, melamine, solid wood, acrylic, polycarbonate, ABS, HDPE and foam cut clean and fast with the right bit. Composite panels such as carbon fiber and glass fiber also route well, but the dust is abrasive and needs extraction. A compression bit gives a clean top and bottom edge on veneered board, which is why cabinet shops use them.

Soft metals are workable but demand respect for the machine stiffness. Aluminum 6061, 5052 and 5083 plate up to about 20 mm thick cut fine on a rigid gantry with coolant or air blast. Brass and copper cut too, though they grab more. Thin sheet under 2 mm tends to lift and chatter, so vacuum fixturing or a sacrificial layer is needed.

Hard metals are not router work. Stainless 304, 17-4PH, tool steel, Inconel and titanium need the rigidity, damping and thermal control of a machining center. A router will cut them slowly and badly, with poor finish and short tool life. If the part is steel or titanium, it belongs on a mill, not a router.

A well-built router holds roughly ±0.1 mm to ±0.25 mm on sheet goods over a 2,400 mm table. That is fine for signage, furniture panels, enclosures and jigs. It is not fine for bearing bores or sealing faces. The gap comes from frame flex, thermal growth in a long beam, and the way a large gantry reacts to a change in direction.

A machining center is built the other way round. A cast iron or polymer concrete base damps vibration, and the travels are shorter. On our 5-axis centers we hold ±0.005 mm (±0.0002 in) and finishes from Ra 0.2–0.8 μm on a fine cut, Ra 1.6–3.2 μm as machined. Those numbers come from a rigid structure and a controlled thermal environment, not from the control software.

The practical rule is simple. If the drawing has a tight tolerance, a sealing surface, a threaded interface or a bearing fit, route the blank and mill the critical features. If the part is flat, large and non-critical, route it whole. Mixing the two processes on one part is normal and often cheaper than forcing either machine to do everything.
