Every machine shop advertises tight tolerance. The useful question is where that number applies. A ±0.005 mm callout on a 12 mm bore in aluminium is routine work. The same number across a 900 mm frame with three setups is a different job, and it needs a different plan.

Ask which datums the shop will use, how the part is held, and whether the tight features are cut in the same setup. On a bracket with two bolt patterns on opposite faces, flipping the part adds stack-up error. A 5-axis center that reaches five faces in one setup removes that error entirely.

For turning work, the limit is usually roundness and surface finish rather than diameter. A mill-turn center holds concentricity better than a two-machine sequence, because the part never leaves the spindle. If your drawing has a Ø400 mm flange and a coaxial bore, say so in the RFQ. It changes the routing.

Thin walls are the other trap. A 1.5 mm wall on a 200 mm aluminium housing will move during and after cutting. A shop that quotes it without asking about clamping pressure is quoting a drawing, not a part.

• 1
  Name the tight featuresList them in the RFQ with datums, not as a blanket note.
• 2
  One setup beats threeCompound angles and opposed faces belong on a 5-axis machine.
• 3
  Finish is separateRa 0.8–1.6 μm covers most sealing faces. Ra 0.2–0.8 μm needs a specific process step.

A machine list is not a scorecard. It is a routing map. A shop with 16 simultaneous 5-axis centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers can split work by geometry instead of forcing every part onto one platform.

Size matters more than count for oilfield and energy work common around Houston. A shop that can reach 4,000 mm in one travel handles long manifolds, rails and structural plates. A shop capped at 600 mm will farm the job out, and you lose control of the schedule.

For small, high-mix parts, the useful figure is how many spindles run unattended. A Ø400 mm rotary table on a 4-axis mill lets one operator load a tombstone and cut twelve parts overnight. That is where unit cost drops on 200-piece runs.

Ask how the shop decides routing. If the answer is a person rather than a process, expect variation between the first order and the fifth.

• 1
  Long partsLook for 4,000 mm travel before you commit to a supplier.
• 2
  Five-sided parts16 five-axis centers means no queue on complex geometry.
• 3
  Turning plus millingMill-turn removes a second op and its stack-up.

Certificates are only useful when you read the scope. ISO 9001:2015 says the shop has a documented quality system. It does not say the shop can build your medical implant or your EV busbar.

IATF 16949:2016 adds automotive-specific controls: PPAP, traceability, change notification. ISO 13485:2016 adds design and process validation for medical devices. ISO 27001:2022 covers information security, which matters when you send proprietary CAD files to an outside party.

A shop holding all four has already built the paperwork habits that audits demand. That saves you time later, when your own customer asks for a material certificate or a first-article report.

One more item: ask how files move. Secure upload, restricted access and a signed NDA before transfer are normal requests. A shop that hesitates on an NDA is telling you something about how it treats customer data.

• 1
  Read the scopeA certificate number and issuing body, not a logo.
• 2
  Match the standard to the sectorAutomotive, medical and general industrial need different ones.
• 3
  NDA before uploadSign it first, then send drawings.

Minimum order quantity is the fastest way to filter shops. A supplier that wants 100 pieces before it starts a spindle cannot help a team still testing a design. A shop with no MOQ runs from one prototype to 10,000+ parts and prices both ends honestly.

Lead time needs a start date. "Two weeks" from the day the PO arrives is not the same as two weeks from drawing release. Ask what happens if you revise a dimension on day three.

Quote format is a quality signal. A single lump sum hides the finish, the inspection level and the material grade. A line-item quote lets you compare shops fairly and lets you drop a cosmetic finish to hit a budget.

Payment and shipping terms belong in the same conversation. Incoterms, packaging and whether parts ship in 3–5 days after production should be written down, not assumed.

• 1
  No MOQOne prototype and 10,000+ runs from the same process.
• 2
  Anchor the lead timeTie it to drawing release, not to the PO.
• 3
  Line-item quotesMaterial, machining, finish and inspection as separate rows.

The material list tells you how wide the shop's supply chain runs. Aluminium 6061-T6, 7075 and 2024 are everyday. Stainless 17-4PH, titanium Ti-6Al-4V and Inconel are not, and they machine very differently.

Titanium and Inconel cut slowly, generate heat at the edge and wear tools fast. A shop that quotes them at aluminium cycle times will either lose money or rush your part. Ask for a separate cycle-time estimate on these grades.

Finishing is where budgets quietly change. Anodizing, electroless nickel, powder coating and black oxide all add a step and a lead time. Hardcoat anodizing on a 0.05 mm wall can also distort the part, so the finish sequence has to be planned with the dimensions.

If your part carries laser marking, note that the minimum character height is 1.5 mm. Smaller text will not read reliably after anodizing.

• 1
  Exotic grades cost timeTitanium and Inconel need slower feeds and fresh tooling.
• 2
  Plan finish before dimensionsHardcoat and plating can move thin walls.
• 3
  Marking limits1.5 mm minimum character height.

Houston's manufacturing base is broad. Energy and oilfield equipment create demand for large, tough parts in 4140 and 17-4PH. Aerospace and defense work needs traceability and tight geometry on titanium and aluminium.

Medical device teams around the Texas Medical Center need ISO 13485:2016 process control and clean handling. Automotive and EV programs need IATF 16949:2016 paperwork and repeatable high-volume output.

Robotics, electronics and new energy round out the list. These sectors share one trait: the design changes fast, so the shop has to be comfortable with small batches and quick turnarounds.

Pick a supplier whose existing work looks like yours. A shop that lives in oilfield parts will not automatically understand a 0.4 mm wall on a medical housing, even with the right certificates.

• 1
  Energy and oilfieldLarge parts, tough steels, long travels.
• 2
  Aerospace and medicalTraceability and validated processes.
• 3
  Automotive and EVVolume repeatability and PPAP paperwork.
