A milling cutter is a set of wedges spinning at speed. Each tooth enters the workpiece, shears a chip, and exits. The chip carries away most of the heat, which is why chip thickness matters more than spindle rpm on its own. If the chip is too thin, the edge rubs instead of cutting, and the tool wears fast.

The basic variables are surface speed, feed per tooth, and radial and axial depth of cut. For 6061 aluminium, surface speed often lands between 300 and 500 m/min with carbide. For 304 stainless, 80 to 150 m/min is a safer window. Push past the upper end and you get chatter, poor finish, and short tool life.

Climb milling is the default on a CNC. The tooth engages at maximum chip thickness and thins to zero, which pulls the workpiece toward the cutter and reduces rubbing. Conventional milling does the opposite and is now mostly used for rough castings with hard surface scale, where the first pass would otherwise damage the edge.

• 1
  Surface speedSets heat and tool life; material-specific, not a single number.
• 2
  Feed per toothControls chip load. Too low causes rubbing, too high breaks edges.
• 3
  Depth of cutAxial and radial together decide cutting force and deflection.

A toolpath is not just a shape. It is a sequence of loads. Trochoidal and adaptive paths keep radial engagement low so the cutter can run deeper without stalling. On a pocket 40 mm deep in 4140 steel, a 12 mm end mill at 5 mm axial depth with adaptive passes removes metal faster than a full-width pass at 1 mm, and it sounds steadier too.

Corners are where most problems start. When the tool enters a sharp internal corner, the engagement angle jumps and the cutter deflects. Roughing with a smaller tool, leaving 0.3–0.5 mm of stock, then finishing with a smaller stepover keeps the wall straight. This matters more than spindle power on a 750 × 1,150 × 550 mm machine.

Entry and exit matter as much as the cut. Plunging straight down into metal with a flat end mill loads the center of the tool, which does not cut well. A ramp or helical entry spreads the load. On a 4,000 mm long part, a bad entry at one end can shift the whole datum before the first finishing pass.

• 1
  Adaptive roughingLow radial engagement, deeper axial cuts, steadier load.
• 2
  Corner controlLeave stock in corners, finish with a smaller tool.
• 3
  Entry methodRamp or helix instead of straight plunge on solid material.

Tolerance is a stack, not a single number. Machine geometry, thermal growth, tool deflection, fixture stiffness, and measurement uncertainty all add up. A machine quoted at ±0.005 mm cannot hold that on a thin wall 300 mm from the vise. The part, not the spec sheet, sets the real limit.

Deflection scales with the cube of tool length. A 6 mm end mill sticking 60 mm out of the holder bends far more than the same tool at 30 mm. On deep cavities, this is why we sometimes step down to a 3 mm tool for the final pass, even though it takes longer. The finish shows it: Ra 0.8–1.6 μm is achievable when the tool is short and the feed is steady.

Thermal effects are small but real. Aluminium grows about 23 μm per meter per degree Celsius. A part that measures correctly at 20 °C may drift if it sits in a warm inspection room. For tight work, let the part equalize before the final check.

• 1
  Tool overhangThe biggest single cause of missed tolerance on deep features.
• 2
  Fixture rigidityA weak setup moves more than the machine does.
• 3
  Thermal driftAluminium moves ~23 μm/m/°C; let parts settle before inspection.

Every setup adds error. A part machined in one operation from five sides is more accurate than the same part run through three vises. That is the practical reason for 5-axis work: fewer datums, less re-clamping, and the same zero for every feature. It is not about the number of axes for its own sake.

For thin plates and frames, vacuum fixturing or soft jaws with a machined pocket hold the part without squeezing it out of shape. A standard vise can distort a 2 mm wall by more than the tolerance. If the drawing shows a flatness callout, tell the shop early so the setup can be planned around it.

Workholding also sets the tool length. A tall fixture forces long tools and invites chatter. When a part needs a deep pocket, we sometimes flip the job and machine from both sides rather than reach 150 mm down with a slender cutter. It costs a setup but holds the tolerance.

• 1
  One setupFewer datums, less stack-up error.
• 2
  Soft jaws or vacuumHold thin parts without crushing them.
• 3
  Short toolsFlip the part rather than reach deep with a long cutter.

Material decides almost everything. Aluminium 6061 and 7075 cut fast and clean, but 7075 is less forgiving of poor chip evacuation. Stainless 304 and 316 work-harden if the tool rubs, so the feed has to stay high enough to keep cutting under the hardened layer. Titanium TC4 (Ti-6Al-4V) cuts at low surface speed and needs flood coolant.

Plastics behave differently. POM and ABS cut easily but melt if the chip sits in the flute. PEEK needs sharp tools and modest depth. Carbon fibre is abrasive and wears carbide quickly, so tool changes are planned into the run rather than treated as a surprise.

The right material choice is often about the feature, not the part name. A bracket in 6061 with a 0.8 mm wall may be better in 7075 or redesigned with a rib. When a design is marginal, we flag it in the DFM report before cutting metal.

• 1
  AluminiumFast, clean cuts; watch chip evacuation on deep pockets.
• 2
  StainlessKeep feed high to avoid work-hardening under the edge.
• 3
  TitaniumLow speed, flood coolant, sharp tools.
