  After Processing Attention: What to Check and What Goes Wrong

A machined feature is only as good as the state it is in when the part comes off the table. The spindle stops, the coolant drains, and everything that happens next is manual. That gap is where most escapes are born. Dimensions were already held inside the cycle; the damage done afterwards is deburring that rounds a corner, air blast that drives chips into a cross-hole, or a part that sat on a bench overnight and picked up rust.

After processing attention is not a personality trait. It is a sequence of physical checks that either happen or do not. A 40-tool cycle can hold ±0.005 mm on every bore, and the job still fails because the last operation left a 0.2 mm burr on a sealing face.

The reason is simple. Cutting forces, thermal growth and tool wear are all managed by the program. Post-machining handling is not. One operator with a hand deburring tool and no print can undo an hour of stable cutting in twenty seconds.

So treat the minutes after cycle end as an operation of their own, with its own tooling, its own inspection points and its own sign-off. That is the mindset this page is built around.

A burr is folded metal, not a chip. It forms where the cutting edge exits the material and the remaining ligament is too thin to shear cleanly. Aluminum 6061 folds easily; 316L work-hardens and can tear instead. The size of the burr tracks the exit angle, the feed per tooth and how sharp the tool was on that pass.

Check every exit face, not just the visible one. Cross-holes, slot ends, thread entries and the back side of a through-pocket all produce burrs on the side you are not looking at. A 3 mm cross-hole in a 6061 housing often hides a burr ring that survives a quick wipe.

Edge break is the opposite problem. The print may call a 0.3 mm × 45° chamfer or a 0.2–0.5 mm radius. Over-deburring turns that into a 1 mm round-over, and now the mating face no longer sits flat. On sealing surfaces and bearing shoulders, an over-broken edge is a functional defect even though the part looks better.

Use the right tool for the location. A hand-held scraper for straight edges, a rotary burr at low rpm for internal corners, a ceramic fiber brush for blended radii. Keep the rpm down. High speed on a thin wall generates heat and smears the surface instead of cutting the burr.

• 1
  Burr checkRun a fingernail or a 0.05 mm shim along every exit edge. If it catches, the burr is still there.
• 2
  Edge break specChamfer or radius per print; never more than the drawing tolerance on sealing faces.
• 3
  Blind holesBlow out from the bottom, then check with a bore light. Trapped chips read as a burr later.

Threads are the most commonly damaged feature after machining, and the damage is usually mechanical rather than dimensional. A go gauge passes, the no-go does not, and the hole is still rejected because a chip was pressed into the flank during cleaning or the crest was rolled over by a power brush.

Check thread form with the gauge set the print specifies, then look at the crest with a 10× loupe. Rolled-over crests on a 1/4-20 or M6 thread mean the deburring tool was run across the axis instead of along it. Thread depth matters too; a tapped hole that is 0.5 mm shallow will not take full engagement.

Chip clearance is the check most operators skip. Blind holes, cross-drilled intersections, internal keyways and O-ring grooves all trap chips. A single aluminum chip left in a hydraulic port will score the bore on first actuation. Blow from the deepest point outward, then verify with a light and a pick.

Do not use compressed air on parts headed for a cleanroom or a vacuum application without a controlled rinse step. Air moves chips, it does not remove them. For medical and semiconductor work, follow the shop's cleaning procedure and record it.

• 1
  Gauge setGo and no-go per print class (2B, 6H). Log which holes were gauged.
• 2
  Crest condition10× loupe on the first three threads of every tapped hole.
• 3
  Trapped chipsDeepest point first, then outward. Verify with light and pick, not by feel.

A part measured right off the machine is not at room temperature. Aluminum 6061 grows about 23 μm per meter per °C. A 300 mm part that is 8 °C warmer than the inspection room reads roughly 55 μm large. That is more than ten times a ±0.005 mm tolerance, and it is the single most common argument between the shop floor and the CMM room.

Let the part stabilize. For tight work on aluminum, 30 minutes on a granite plate is a reasonable minimum; steel and titanium take longer. Measure at the temperature your tolerance was written for, usually 20 °C.

Datum choice matters as much as temperature. Measure from the same datum the print uses, and confirm the datum surface itself is clean and burr-free. A 10 μm burr under a datum pad tilts the whole part and shows up as a taper that is not really there.

Check tool wear before the last pass, not after. A finishing end mill that has run 40 minutes in 17-4PH will push the last bore 10–15 μm off nominal. Change or offset the tool, then cut the feature. Do not chase it with a re-cut after the fact.

• 1
  Soak timeAluminum 30 min minimum on granite; steel and titanium longer.
• 2
  DatumClean pad, no burr, same datum as the print.
• 3
  Tool wearCheck offset before the finishing pass. Record the change in the setup sheet.

Surface finish is specified as a Ra value and measured with a profilometer on a defined area. Ra 0.8–1.6 μm is a normal machined finish; Ra 0.2–0.8 μm needs a dedicated finishing pass and often a different insert. If the print calls a finish, measure it on the same surface orientation the print shows. A reading taken across the lay will not match one taken along it.

Look for smeared material, chatter marks and heat discoloration. Smearing means the tool was dull or the rpm too high. Chatter means the setup was not rigid enough. Discoloration on stainless means the coolant was starved at that point. All three are visible before any gauge is picked up.

Marking is a check in itself. Laser marking needs a minimum character height of 1.5 mm to stay legible after anodizing or plating. Part numbers, revision letters and date codes should be placed where a later finishing step will not erase them. Engraving depth must not break through a thin wall.

Finally, the paperwork. Record the operator, the machine, the program revision, tool offsets changed, and the inspection results. If a part is questioned three weeks later, that sheet is the only thing that explains what actually happened. In shops running IATF 16949 or ISO 13485, traceability is not optional.

• 1
  FinishMeasure Ra on the specified surface and orientation, not a convenient one.
• 2
  Marking1.5 mm minimum character height; place away from finishing stock.
• 3
  RecordsOperator, machine, program revision, offsets, inspection results.
