Wholesale CNC Plastic Processing Services: 7 Checks Before You Order

• 1
  Key takeaways
• 2
  Wholesale CNC plastic processing services: what to compare
• 3
  Tolerance claims on plastic parts
• 4
  Why wholesale CNC plastic processing is not injection molding
• 5
  Resin grade and machining behavior
• 6
  Minimum order quantity and setup cost
• 7
  Machine capacity behind the quote
• 8
  Inspection, finishing and documentation
• 9
  Quote turnaround and production start
• 10
  Step by step: qualifying a wholesale plastic supplier

Metal suppliers quote one tolerance number for the whole part. Plastic does not work that way. A machined ABS housing with 3 mm walls and a 200 mm span will move after machining as internal stress releases. A PEEK seal ring of the same diameter holds much better because the material is stiffer and the wall is thicker.

When a supplier offers wholesale CNC plastic processing services, ask which features carry ±0.005 mm. On most parts that is bearing bores, seal grooves, mating faces and dowel holes. Cosmetic surfaces and non-critical pockets can sit at Ra 1.6-3.2 μm and ±0.05 mm without any loss of function.

A supplier who writes ±0.005 mm on every dimension is either guessing or planning to scrap parts. A supplier who names the tight features and explains how they will hold them is the one to keep. GreatLight holds ±0.005 mm (±0.0002 in) on machined plastic features and we say which ones before the order starts.

• 1
  Name the tight featuresBores, grooves and mating faces, not the whole drawing.
• 2
  Wall thickness mattersThin walls warp more than thick ones on the same resin.
• 3
  Ask for the measurement methodCMM, pin gauge or optical, stated in the inspection plan.

Volume plastic parts usually go to injection molding. That is correct above roughly 10,000 pieces per year with a stable design. Below that, and on any design still changing, machining wins. There is no mold, no tooling lead time and no cost of a steel change when a boss moves 2 mm.

Machined plastic also reaches shapes molding cannot. Undercuts, deep pockets, threaded inserts set after molding, and low-volume glass-filled grades all favor a milling setup. For carbon fibre and PEEK parts in the tens or hundreds, wholesale CNC plastic processing services are usually the only path that pays back.

The trade is cycle time. Milling one POM bracket may take 12 minutes against 30 seconds in a mold. That gap only matters at high volume. At 500 pieces the mold is still being cut while the machined parts have shipped.

• 1
  Choose machiningUnder 10,000 pieces, design still moving, undercuts and inserts.
• 2
  Choose moldingStable design, high annual volume, simple geometry.
• 3
  Bridge bothMachined pilot parts prove the design before mold steel is cut.

Two suppliers quoting the same ABS part can be quoting different materials. General purpose ABS machines cleanly and takes a fine finish. Glass-filled ABS dulls cutters fast and needs carbide with a sharper rake. If the quote does not state the grade and the filler percentage, the price is not comparable.

We machine over 50 polymers and composites, including ABS, PC, PMMA, POM, PA, PEEK, PP, HDPE and carbon fibre. Each one has a feed and speed window. POM wants high feed and light radial engagement to avoid chatter. PEEK needs sharp tooling and low cutting temperature to keep from smearing. PMMA will craze if coolant chemistry is wrong.

Ask for the material certificate and the lot number. On medical and automotive work, traceability is not optional. A supplier who cannot produce a mill certificate for the resin cannot support an IATF 16949 or ISO 13485 program.

• 1
  State the gradeResin family plus filler type and percentage.
• 2
  Ask for the lot certificateRequired for medical, automotive and aerospace programs.
• 3
  Match finish to resinPMMA polishes well; glass-filled PA does not.

A minimum order quantity on machined plastic is a business choice, not a technical limit. The setup for a 5-axis job is the same whether you run 1 part or 500. What changes is fixture time and how the shop schedules the batch.

GreatLight has no minimum order quantity. We run from one prototype to 10,000+ part runs. That matters when a design is still being validated. You can order 3 pieces, test them on the line, change a wall thickness and reorder without a tooling penalty.

Watch for hidden setup charges. A low piece price with a large fixed setup fee is often more expensive than a higher piece price with no setup. Ask for both numbers separately so you can see where the money goes.

• 1
  Ask for setup and piece price separatelyYou cannot compare quotes that bundle them.
• 2
  Check fixture amortizationSoft jaws and vacuum plates should not be charged twice.

Wholesale pricing depends on how many spindles a shop can point at your order. A supplier with 3 machines will schedule your 2,000 piece run around other work. A supplier with 127 high-precision CNC machines, including 16 simultaneous 5-axis machining centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers, can hold a delivery date.

Size limits also matter. Our maximum processing size is 4,000 mm, with travels of 4,000 × 400 × 150 mm and 750 × 1,150 × 550 mm on the larger platforms. Small work runs on 600 × 600 × 600 mm or 500 × 500 × 450 mm machines with a Ø400 mm rotary table. Long plastic profiles and large enclosures need the bigger frames.

Ask which machine will run your part and how many hours per week it is booked. That answer predicts the ship date better than any promise.

• 1
  Match part size to travelA 900 mm part cannot run on a 600 mm machine.
• 2
  Ask about 5-axis availabilityUndercuts and compound angles need it.

Machined plastic parts often carry both a dimensional spec and a cosmetic spec. The cosmetic one is where disputes start. Define what a scratch is, what a witness line is allowed, and which surfaces are class A. Then agree on the inspection method.

GreatLight inspects 100% of parts before shipment, covering raw material check, in-process monitoring and final inspection, with reports on request. Qualification rate is 99.99%. For plastic, that process usually includes a pin gauge on bores, a CMM check on the tight features, and a visual pass under controlled light.

Finishing changes dimensions slightly. Anodizing is for aluminium, not plastic, but bead blasting, tumbling, brushing and laser marking all apply. Laser marking has a minimum character height of 1.5 mm, so plan part numbers and traceability codes around that limit.

• 1
  Write a cosmetic specClass A surfaces, allowed witness lines, scratch limits.
• 2
  Confirm marking space1.5 mm minimum character height for laser marking.
• 3
  Request reports up frontDimensional and material reports, not after a rejection.

Slow quoting usually means slow production. A shop that takes a week to price a plastic bracket is not set up for volume work. We return a quotation and a free DFM analysis within 12 hours, and production can start within 24 hours of approval.

Parts ship in 3-5 days on standard plastic work. Historical late-delivery probability is below 2%. Those numbers only hold if the drawing is complete. Missing tolerances, undefined radii and an unspecified resin grade are the three most common causes of a stalled order.

Send a STEP file, a 2D drawing with critical dimensions called out, the resin grade, the surface finish and the quantity. That package gets an accurate price on the first pass instead of three rounds of questions.

• 1
  Send STEP plus 2D drawing3D alone leaves tolerances undefined.
• 2
  Name the finishRa value or the cosmetic standard you work to.
