A three-axis mill moves the tool along X, Y and Z. The part stays still, so every feature that faces away from the spindle needs a new fixture or a manual reposition. Each reposition adds a setup, and each setup adds a stack of small errors: fixture locating, clamp distortion, tool touch-off. On a part with four angled faces and two undercuts, that stack is where the tolerance disappears.

An advanced 5-axis CNC machining solution adds two rotary axes. One rotates around X (A axis), one around Z (C axis), or the spindle head tilts instead. The controller keeps the tool tip on the programmed path while the rotary axes move, a function called TCPM or RTCP depending on the control brand. The part no longer has to be re-clamped for each face.

The practical result is fewer datums. Instead of stacking four setups, you hold one datum and machine five sides from it. Errors that used to accumulate across setups now come from a single alignment, which is easier to control and easier to measure.

That said, 5-axis does not automatically hold ±0.005 mm. The rotary axes carry their own positioning error, and thermal drift moves the part as the spindle runs. Reach the tight numbers only when the machine is calibrated, the tool is short, and the finishing pass is light.

A trunnion machine puts the rotary axes under the part. The table tilts and rotates, so the workpiece moves while the spindle stays mostly vertical. This layout is common on machines with a Ø400 mm rotary table and suits parts that fit inside the table envelope.

A swivel-head machine moves the spindle instead. The head tilts in A and rotates in C, so heavy parts can sit still on a large bed. This is the layout behind long travel sizes such as 4,000 × 400 × 150 mm, where the part outweighs the table.

Both layouts give the same five degrees of freedom. The difference shows up in rigidity and in how the chips fall. A trunnion table carries the part mass on the rotary bearings, so a heavy block limits acceleration. A swivel head keeps the mass on the bed but the tilting head is a longer cantilever, which shows up as chatter on deep cuts.

Pick by part, not by preference. Compact parts with many faces favor a trunnion. Long, heavy or awkward parts favor a swivel head with a fixed bed.

Toolpath generation for five axes is not a three-axis path with tilt added. The post-processor must convert the tool tip position into coordinated moves of X, Y, Z, A and C, and it must keep the tool axis inside the machine travel limits.

Collision checking is the second job. A tilted holder can reach into a pocket that a vertical tool cannot enter, but the same tilt can also drive the holder into the wall. Good CAM software simulates the holder, the tool and the fixture, not just the tool tip.

The third job is feed rate. When the tool tilts, the contact point on the cutter changes, so a constant tip feed rate produces a varying chip load. Controls compensate with feed rate linearization, which maps the programmed feed to the actual contact point.

These are software problems, but they decide the outcome. A shop can own a good 5-axis machine and still scrap parts if the post-processor is generic and the simulation is thin.

The tolerance figure that matters is the one the shop can hold across the whole batch, not the best number from a single part. We quote ±0.005 mm (±0.0002 in) on 5-axis work, and that applies to features machined in the same setup. Features added in a second setup pick up the second alignment error.

Surface finish follows the same logic. As-machined surfaces land at Ra 1.6–3.2 μm. A high-finish pass reaches Ra 0.8–1.6 μm, and fine finishing with a small step-over reaches Ra 0.2–0.8 μm. Tighter finish costs cycle time, so specify it only where a seal, a bearing or a sliding surface needs it.

Five-axis does not remove the physics of cutting. A long tool still deflects. A thin wall still moves when the cutter pushes it. Titanium and Inconel still work-harden if the feed is too low. The rotary axes add reach, not stiffness.

Where 5-axis genuinely helps on finish is in keeping the tool engaged at a constant angle. A tilted tool spreads the wear across a longer edge, so the surface stays consistent from the first part to the last.

Aluminium grades such as 6061, 7075 and 6082 machine fast and tolerate aggressive tilt. Five-axis pays off when the part is a thin-walled housing with angled ports, or an impeller with twisted blades that no vertical cutter can follow.

Stainless 17-4PH, 316L and 440C, plus titanium TC4 (Ti-6Al-4V) and Inconel, are slower and push tool wear. Here the gain is not speed, it is avoiding a second fixture. Re-clamping a hardened or heat-treated part often marks it or moves it, and that risk disappears when all faces come off one setup.

Medical and aerospace parts usually combine a tight tolerance with a surface that cannot be re-datumed. A 5-axis cut that finishes a curved face without a witness line is worth more than the cycle time it costs.

Plastics and composites are a different case. PEEK and carbon fibre cut easily but need sharp tools and controlled dust extraction. Tilt helps reach internal geometry, though the fixture often costs more than the machining.
