Milling is a subtractive process. A rotating multi-flute cutter travels along a programmed path while the workpiece stays clamped. The machine controls three values at every moment: spindle speed in rpm, feed rate in mm/min, and depth of cut. Those values set the chip thickness. Chip thickness decides whether the aluminum milling CNC machine cuts cleanly or rubs.

Aluminum behaves well here because it is soft, light, and conducts heat away from the zone fast. A sharp carbide tool removes material in long curls rather than breaking it into powder. That keeps cutting forces low and lets the machine run at high surface speed without burning the edge.

Heat still matters. Most of it leaves with the chip, not with the part. If the cutter rubs instead of shearing, heat stays in the workpiece and the wall moves. That is why feed per tooth is the number to hold, not just spindle rpm.

The rules below cover alloy choice, cutter geometry, workholding, and axis count. Each one changes what the drawing can ask for.

• 1
  Surface speed500–1,000 m/min is common in 6061 with carbide.
• 2
  Feed per tooth0.05–0.15 mm for a 3-flute cutter in the same alloy.
• 3
  Radial engagementKeep below 50% of cutter diameter on thin walls.
• 4
  CoolantMist or air blast is often enough; flood for deep pockets.

Alloy choice sets the starting point for every other decision. 6061-T6 is the general workhorse: good strength, welds well, machines predictably, and holds tight tolerance without drama. 7075-T6 is roughly twice the yield strength and machines to a better finish, but it costs more and is less forgiving of poor clamping.

2024-T4 cuts fast and is common in aerospace brackets, yet it has lower corrosion resistance and often needs anodizing or a protective finish. 5052 and 5083 are chosen for sheet and formed parts, not for heavy hogging. 6082 sits close to 6061 with slightly higher strength.

Cast alloys such as ADC12 behave differently again. Porosity inside the casting can open up during milling, so a drawing that tolerates ±0.1 mm may be realistic while a cosmetic surface may not. If the part is a die casting, say so on the RFQ.

The practical rule: pick 6061 unless a load case or weight target forces 7075 or 2024. Then tell the shop which surfaces matter.

• 1
  6061-T6Default for brackets, housings, and fixtures.
• 2
  7075-T6High load, thin ribs, aerospace structure.
• 3
  2024-T4Aerospace skins and fatigue-critical parts.
• 4
  ADC12Die-cast housings finished by milling.

A rigid setup matters more than a faster spindle. Vises and clamps work for blocky parts. Thin plates and frames need vacuum chucks, soft jaws, or a sacrificial base. Once the part starts ringing, no feed override will fix the surface.

For a wall thinner than 1.5 mm, climb milling with light radial engagement keeps the force pushing the wall into the core rather than pulling it away. Leave a roughing allowance of 0.3–0.5 mm and finish in two passes. Spring passes at zero radial depth clean up the last few microns.

Thermal growth is the quiet problem. A 500 mm aluminum part can move 0.02 mm or more over a long run as the spindle and coolant warm up. Rough in the morning, finish after the machine has stabilized, and check critical bores with a bore gauge rather than trusting the program alone.

Deburring belongs in the plan, not at the end. Sharp edges on aluminum roll over easily. Specify a 0.2–0.5 mm chamfer or edge break on drawings so the shop can cut it while the part is still on the machine.

• 1
  Thin wallsLight radial cut, climb milling, two finish passes.
• 2
  Long partsRough and finish in separate thermal windows.
• 3
  Cosmetic facesLeave 0.2 mm for the finish cutter.
• 4
  Edge breakCall out 0.2–0.5 mm chamfers on the drawing.

As-machined aluminum typically lands between Ra 1.6 and 3.2 μm. A careful finishing pass with a sharp cutter and light stepover reaches Ra 0.8–1.6 μm. Going below Ra 0.8 μm usually means a second operation such as lapping, polishing, or bead blasting.

Anodizing changes the surface you worked for. Clear anodizing preserves tool marks and makes them easier to see. Hardcoat builds a thicker oxide layer and can dull tight corners. If the part will be anodized, tell the shop before the finish pass so they can leave enough stock.

For mating faces and seals, specify the finish on the drawing rather than leaving it to the shop. A Ra value on a sealing face is a functional callout, not a cosmetic one.

Milling removes material from a solid block or plate. That is wasteful when the part is mostly air. If a housing has large internal voids and thin walls, die casting or vacuum casting may beat milling on cost once volume reaches a few hundred pieces.

Very deep, narrow pockets are another limit. A cutter needs reach; a pocket deeper than five times the cutter diameter starts to deflect and chatter. If the drawing needs a 40 mm deep slot 6 mm wide, expect a slower run and a higher price.

Aspect ratio matters for shafts too. A long slender aluminum shaft is better turned than milled. Mill-turn centers handle one operation for both features, which cuts setup error and shortens the route.
