Boises CNC Machining Service: What to Check Before You Award

Most quoting problems start before the RFQ is sent. A part with undercut pockets, angled port faces, or blended radii across five faces needs simultaneous five-axis motion. A bracket with three orthogonal faces does not. Send the first type to a shop running only three-axis mills, and you get either a fixture stack that adds cost or a quote that quietly assumes a redesign.

Simultaneous five-axis means the tool stays normal to the surface through a continuous path. That is what makes a single setup possible on a turbine blade fillet or a medical implant with compound curvature. On a prismatic housing, three-axis work with two refixtures often holds the same tolerance for less money. The geometry decides, not the machine list.

Flip the question around: instead of asking what a shop owns, ask which features drive the cost. Undercuts, thin walls under 1 mm, deep bores with a length-to-diameter ratio above 5, and surfaces tighter than Ra 0.8 μm are the four features that push a part into a higher tier. Everything else is routine milling and turning.

At GreatLight we run 127 high-precision CNC machines, including 16 simultaneous five-axis machining centers, 12 four-axis mills, 27 three-axis machines, and 16 mill-turn centers. Maximum processing size is 4,000 mm, and the largest travel is 4,000 × 400 × 150 mm. That mix matters because a shop with only five-axis spindles will quote every job as if it needs one.

• 1
  Five-axis pays off whenCompound angles, undercuts, or five-face access in one setup.
• 2
  Three-axis is enough whenOrthogonal faces, loose datums, or simple prismatic shapes.
• 3
  Watch for cost driversThin walls, deep bores, tight radii, and fine surface finishes.

The same geometry in 6061-T6 and 17-4PH stainless is not the same job. Aluminum cuts fast, holds a fine finish with light passes, and rarely needs more than one roughing cycle. Stainless work-hardens, so feeds and speeds have to stay aggressive enough to cut under the hardened layer instead of rubbing it. Tool life drops, cycle time climbs, and the price follows.

We machine aluminium grades 6061, 6061-T6, 2024, 5052, 5083, 6063, 6082, 7075, and ADC12. Stainless covers 303, 304, 316, 316L, 420, 430, 431, 440C, and 17-4PH (SUS630). Steel grades include 1018, 1045, 4130, 4140, 4340, A36, and tool steel. Copper and brass run from C101 to C36000, with beryllium copper available. Titanium and nickel work is limited to TA1, TA2, TC4 (Ti-6Al-4V), and Inconel, plus magnesium AZ31B and AZ91D. Plastics include ABS, PC, PMMA, POM, PA, PEEK, PP, HDPE, and carbon fibre.

PEEK and carbon fibre are the two materials that surprise people most. PEEK needs sharp tooling and generous coolant to avoid smearing, and carbon fibre abrasive dust wears cutters quickly. Neither is a reason to avoid the material, but both add cost that a plastic-part quote from a general shop may miss.

If a prototype is headed for die casting or injection molding later, the machined version should use the same alloy where possible. Testing 6061 when production will run ADC12 tells you less about the final part than you think.

• 1
  AluminumFast to cut, good for housings, brackets, and heat sinks.
• 2
  Stainless and steelHigher tool wear, better strength and corrosion resistance.
• 3
  Titanium and InconelSlow speeds, high heat, reserved for demanding applications.
• 4
  PlasticsWatch clamping force and heat build-up on thin sections.

Certificates tell you a system exists. They do not tell you what happened on your parts. Ask what is measured, on which features, and in what format the data comes back. A first article inspection report on a new part plus in-process checks on critical dimensions is a reasonable baseline. Dimensional reports on request are standard for us.

GreatLight holds ISO 9001:2015, IATF 16949:2016, ISO 13485:2016, and ISO 27001:2022. Those cover general quality management, automotive, medical devices, and information security respectively. If your part is a medical device component, the ISO 13485 scope is the one that matters for traceability and process control. For automotive work, IATF 16949 governs how change control and corrective action are handled.

We inspect 100% of parts before shipment, starting with a raw material check, then in-process monitoring, then final inspection. Qualification rate runs at 99.99%. One hundred percent inspection does not mean zero defects, but it does mean no part leaves without being looked at.

Surface finish is where drawings are often underspecified. Ra 1.6–3.2 μm is a normal as-machined result. Ra 0.8–1.6 μm needs a finishing pass. Ra 0.2–0.8 μm calls for careful tool selection and may need polishing after machining. Specify the finish only on faces that need it, because a blanket Ra 0.4 μm callout across a whole part can double the cycle time.

Finishing options include anodizing in clear, colour, hardcoat, and conductive types, electroless nickel, zinc, silver and gold plating, powder coating, black oxide, bead blasting, tumbling, brushing, and polishing. Laser marking has a minimum character height of 1.5 mm, so plan your part numbers accordingly.

• 1
  Send with the RFQ2D drawing with GD&T, 3D STEP file, material, finish, and quantity.
• 2
  Ask forFirst article report, material certs, and dimensional data on critical features.
• 3
  Flag earlyAny feature with a tolerance tighter than ±0.005 mm or a finish below Ra 0.8 μm.

Quotation and a free DFM analysis come back within 12 hours. Production can start within 24 hours of approval, and parts typically ship in 3–5 days. Our historical late-delivery probability is below 2%. Those numbers assume a released drawing and available material, so send complete files the first time.

There is no minimum order quantity. We run from one prototype to 10,000+ part runs on the same floor, which means the fixture and setup decisions made on the prototype do not have to be thrown away at volume. For a Boises CNC machining service relationship, that continuity saves a second qualification cycle.

Uploads are secure and confidential, and an NDA is available on request. If your drawings cannot leave your network without one, say so in the first email and we will get it signed before files move.

DFM feedback is worth reading even when you disagree with it. A note about a corner radius that needs a larger cutter, or a tolerance that is tighter than the function requires, is usually a cost signal rather than a criticism.

• 1
  Quote turnaround12 hours, including DFM analysis.
• 2
  Production startWithin 24 hours of approval.
• 3
  Shipping3–5 days for typical parts.
• 4
  Order sizeOne part to 10,000+ with no MOQ.
