A CNC cutting machine fabric system replaces the hand-guided blade with a gantry or a moving head that follows a CAD or vector path. The controller reads the same file the designer drew, converts it to motor commands, and drives the head along that path. The operator no longer steers the tool. They load the roll, set the nesting, and watch the first article. That change in who controls the path is the whole point of the shift.

The head itself is not one tool. Blade cutting drags a reciprocating or tangential knife through the ply. Laser cutting burns or vaporizes the edge. Ultrasonic cutting uses a vibrating blade at roughly 20 kHz to separate fibers with far less fraying. Each method leaves a different edge, so the file and the material decide which one belongs on the machine.

Software does more work than most buyers expect. Nesting software packs parts to reduce waste, and a typical textile layout can recover a meaningful share of material compared with manual marker making. Cut order matters too: a controller that cuts internal holes before the outer contour keeps the ply from shifting mid-cut.

• 1
  Path controlThe controller, not the operator, holds the geometry.
• 2
  Tool choiceBlade, laser and ultrasonic heads leave different edges.
• 3
  NestingSoftware decides material yield before the first cut.

Textiles are not rigid. A woven cotton shifts, a knit stretches, and a coated synthetic can spring back after the knife passes. That movement sets the real tolerance, not the machine spec sheet. On a stable woven material with a vacuum table holding the ply, a blade system can hold roughly ±0.5 mm on a long contour. On a loose knit the same machine may drift past ±2 mm unless the ply is compressed first.

Heat is the second variable. Laser cutting seals synthetic edges and stops fraying, which is useful on polyester and nylon. It also leaves a browned or hardened edge that some medical and apparel buyers reject. Ultrasonic cutting gives a sealed edge with less discoloration, but the blade heats up and needs dwell time between dense layouts.

Moisture and finish change the result as well. Fabric that has been washed or dyed can shrink after cutting, so a part cut to nominal size may come back undersized. For anything that will be laundered, cut the sample, wash it, then measure before you lock the drawing.

• 1
  WovenStable enough for tight nesting and clean corners.
• 2
  KnitStretches; expect a wider tolerance band.
• 3
  Coated syntheticSeals well under laser, discolors under some settings.

Pick the head by edge requirement first. If the part needs a sealed, non-fraying edge on a synthetic, laser or ultrasonic is the practical answer. If the material is a natural fiber and the buyer wants a soft hand, a blade leaves the cleanest result with no thermal damage.

Volume comes second. A single prototype and a 10,000-part run do not need the same setup. Low volume tolerates a slower pass and more manual handling. High volume rewards good nesting and a conveyor or continuous feed, because the cutting time per part drops sharply.

Third, look at what happens after cutting. Fabric parts often get sewn, bonded, or laminated, and each of those steps adds its own tolerance. A part that is perfect off the table can still fail at assembly if the downstream process pulls it out of shape. Design the cut tolerance around the assembly, not around the cutter.

• 1
  Edge firstSealed edge points to laser or ultrasonic.
• 2
  Volume secondHigh volume needs nesting and continuous feed.
• 3
  Assembly thirdBudget tolerance for sewing and bonding.

Textile cutting and metal cutting share the same control logic, but the tolerances live in different worlds. A fabric head fights material movement. A metal head fights tool deflection and heat. That is why a shop that cuts both keeps separate process windows rather than one universal setting.

For rigid parts, the numbers are tighter and better defined. At GreatLight we hold ±0.005 mm (±0.0002 in) on machined features, with surface finish from Ra 0.2–0.8 μm on fine work up to Ra 1.6–3.2 μm as-machined. Those figures apply to metal and engineering plastic, not to a knit ply, and mixing the two expectations is the most common mistake in a mixed-material drawing.

The bridge between the two is the fixture. Fabric is held by vacuum and friction. Metal is held by clamps, vises and soft jaws, sometimes on a Ø400 mm rotary table. Both approaches exist to stop the workpiece moving while the tool does its job.

• 1
  FabricMovement sets the tolerance, not the machine.
• 2
  MetalDeflection and heat set the tolerance.
• 3
  Shared ruleHold the workpiece still or nothing repeats.
