  Gear cutting method selection

A gear is a transmission, not a shape. What matters is how the flank contacts the mating flank under load. The work is a family of cutting and finishing operations that create those flanks within a stated tolerance band. The machine moves the tool along a programmed path; the geometry of that path, not the operator's hand, sets the tooth form.

The starting point is a CAD model or a drawing that defines module, pressure angle, helix angle, number of teeth and profile shift. From that, CAM software generates the tool path. On a gear shaping machine the cutter reciprocates while the work rotates in a timed relationship; on hobbing the cutter and blank rotate continuously as the tool feeds along the tooth width. Both are generating motions, which is why the cutter profile does not have to match the final tooth profile exactly.

Material removal happens in three rough stages before any finishing pass. Roughing clears the tooth space and leaves 0.2–0.5 mm of stock on each flank. Semi-finishing brings the profile to within 0.05–0.1 mm. Finishing or grinding takes the last few hundredths of a millimeter and establishes surface texture. Skip the middle stage and the finishing tool has to absorb an uneven load, which shows up later as profile deviation.

Heat treatment usually sits between roughing and finishing. Carburizing and hardening distort the gear blank, often by 20–60 μm on a 100 mm diameter part. That distortion is the main reason hardened gears are ground after heat treatment rather than cut to final size beforehand. On soft gears below roughly 35 HRC, hard milling or skiving can replace grinding and keep the flank in one setup.

Hobbing is the default for external spur and helical gears. A rotating hob with a worm-like form cuts one tooth space at a time as the blank indexes. It is fast, the tool is a standard catalog item, and it handles module 0.5 through 10 without special setup. Its limit is internal teeth and shoulders close to the gear face; the hob needs axial clearance to run off the part.

Shaping uses a pinion cutter that reciprocates and rotates with the work. It reaches internal gears, cluster gears and any tooth that sits against a shoulder. Cycle time is longer than hobbing because only one or two teeth are in cut at a time. For a 40-tooth internal gear at module 2, expect roughly three to four times the hob cycle on the same machine.

End milling a gear on a 5-axis center makes sense for large modules, low quantities and repair work. The tool is a standard ball or radius cutter, so there is no cutter lead time and no minimum order on the tooling. Accuracy depends on the machine's rotary axes: on our 16 simultaneous 5-axis centers, a milled gear up to module 6 typically holds profile deviation near 0.01 mm after a spring pass.

Skiving is a continuous cutting process for internal gears and hardened bores. The cutter and work rotate at a crossed-axis angle, so the cutting speed stays high while each tooth is engaged briefly. It suits parts that are too hard to hob and too awkward to shape. Tooling cost is the trade-off, and it only pays back above a few hundred pieces.

Three error sources dominate. The first is the workholding. A gear cut on a mandrel that runs out by 0.01 mm will show runout in the finished teeth, no matter how good the cutter is. We indicate the blank before the first cut, not after the last one.

The second is thermal drift. A machine that has been running for six hours is not the same machine it was at start-up. On a 4,000 mm maximum processing size part, a 3 °C spindle growth can shift the tooth flank beyond the drawing tolerance. Warm-up cycles and in-process probing handle most of that.

The third is the finishing operation itself. Hobbing alone typically lands between DIN 8 and DIN 10. Grinding after heat treatment reaches DIN 5 to DIN 7 with profile deviation around 0.005–0.01 mm. That gap is what buyers are paying for when they specify a ground gear.

Inspection closes the loop. A gear analyzer measures profile, lead, pitch and runout against the drawing. We inspect 100% before shipment, with raw material check, in-process monitoring, final inspection and reports on request. For gears that carry a safety function, that record matters more than the number on the drawing.

Spur gears are the simple, noisy choice. They carry load well, cost less to cut and need no axial thrust bearings. Use them at moderate speeds where noise is not a constraint, such as a slow indexing table or a hand-cranked adjustment.

Helical gears run smoother and quieter because contact starts at one end of the tooth and travels across. The trade-off is axial thrust, which means a thrust bearing or a thrust shoulder on the shaft. Above roughly 3,000 rpm, the noise difference is usually enough to justify the extra bearing.

Bevel and hypoid gears turn a corner. Cutting them needs a dedicated bevel generator or a 5-axis center with a continuous rotary table. On our machines the Ø400 mm rotary table sets the practical ceiling for a spiral bevel pair; larger diameters move to a different process route.

Plastic gears are not a cheap substitute for steel. They absorb vibration, run without lubrication in light duty, and fail by creep rather than fatigue. Load capacity is a fraction of a steel gear of the same size, so keep them to instrument drives, timing functions and low-torque transfer.

Volume changes the answer. A gear that will be made 50,000 times a year belongs on a forging die, a powder metal press or an injection mold. Machining one-off and low-volume gears from bar stock avoids tooling cost entirely and keeps the design free to change between revisions.

Size is the second boundary. Our largest travel is 4,000 × 400 × 150 mm, which covers most shaft-integrated gears and large ring gears cut in segments. Beyond that, the part has to be split or the process has to move to a gear-cutting machine built for the diameter.

Geometry is the third. Teeth that sit inside a blind bore with no relief for a cutter, or a tooth form with undercut below the root, may not be reachable at all. That is a design conversation, not a machining problem, and it is better had before the drawing is released.

Finally, hardness sets the sequence. If the drawing calls for 58–62 HRC through the case, the teeth will be cut soft, heat treated and ground. If the part must stay soft, it can be cut to final size in one setup. Choosing the sequence early avoids a second heat treat and a second setup.
