A fiber laser delivers a focused beam, typically 1,070 nm, into a spot a few tenths of a millimeter wide. The spot melts and partially vaporizes metal. Assist gas, usually nitrogen or oxygen, blows the molten material out of the kerf before it can re-solidify on the underside.

Three variables set how fast that front can travel: absorbed power density, the gas jet's ability to clear the kerf, and the thermal conductivity of the workpiece. Aluminum and copper pull heat away quickly, so they cut slower than mild steel at the same thickness.

Speed is therefore a result, not an input you pick first. The operator sets power, focus position and gas pressure, then raises feed rate until dross appears on the bottom edge, then backs off 5–10%. That ceiling is the practical cutting speed for that material and thickness.

Push past the ceiling and the beam stops penetrating. The kerf narrows, the cut face turns rough, and heat soaks into the surrounding metal. On a thin bracket that means discoloration. On a 10 mm plate it means a recast layer and a part that will not hold ±0.005 mm after finishing.

Below roughly 3 mm, the process is close to ideal. The beam cuts through in a single pass, the gas clears the kerf easily, and the heat-affected zone stays within a few hundredths of a millimeter. Feed rates on 1 mm mild steel commonly run several times higher than on 6 mm plate of the same alloy.

This is the zone where speed and precision stop fighting each other. Thin-gauge brackets, covers, shims and busbar blanks come off the table with a clean edge, often good enough to skip a secondary deburr. Edge finish on nitrogen-cut stainless typically lands in the Ra 1.6–3.2 μm range.

Nesting matters more than raw feed rate here. A part with 40 small holes spends more time piercing than cutting. Reducing pierce count, or switching to a flying pierce on thin stock, can cut total cycle time by a third without touching the feed rate at all.

If your parts are flat, thin and needed in volume, laser cutting is usually the right first operation. If they carry pockets, threads or tight bores, the laser becomes a blanking step and the real work happens on a mill.

Above about 6 mm the story changes. The kerf widens, the cut face develops striations, and the taper grows. A fast pass on thick plate leaves dross that has to be ground off by hand, which adds labor and can move a datum surface.

Heat is the real limit. Every extra millimeter of thickness means more energy stays in the part. On long, narrow features that heat builds unevenly and the part can bow after cooling. A 12 mm steel plate with a long slot is a classic case: cut it fast and it cups, cut it slow and the edge quality improves but the heat input rises.

For these jobs we often cut a near-net blank and finish on a 5-axis machining center. That keeps the laser doing what it does best, removing large areas of flat material, and puts the tight features on a machine that holds ±0.005 mm without arguing with heat.

The same logic applies to titanium and Inconel. They cut, but slowly, with high gas pressure and more attention to the recast layer. If the drawing calls for a fatigue-critical edge, plan a machining pass after the laser.

A laser head rarely reaches its rated maximum feed rate on a real part. It accelerates, cuts 8 mm, decelerates, turns a corner, then accelerates again. On a part with dense hole patterns or fine contours, average speed can sit well below half the machine's peak.

That is why two machines with the same rated feed can differ by 30% on the same job. Light gantries, linear drives and a controller that looks ahead through the toolpath keep the head moving instead of stopping at every vertex.

Corner behavior is the tell. A controller that slows on every sharp corner produces a clean edge but a long cycle. One that holds speed through the corner can round the geometry slightly. For a bracket that is fine. For a locating feature with a ±0.05 mm callout, it is not.

When we quote a laser job, we look at the toolpath length, the pierce count and the corner density before we look at material thickness. Those three numbers predict the real hour count better than any feed-rate chart.

A laser-cut edge is not a machined edge. It carries a thin oxide or nitride layer, microscopic striations, and a heat-affected zone that can reach 0.1–0.3 mm into the material. For most brackets and covers that is invisible and harmless.

It matters when the edge is functional. A sealing face, a bearing seat or a fatigue-critical fillet should not be a raw laser edge. The recast layer is hard and brittle, and it can crack under cyclic load. We machine or tumble those features after cutting.

Deburring is the other routine step. Nitrogen-cut stainless often needs only a light tumble. Oxygen-cut mild steel produces a heavier dross that needs grinding or a vibratory pass. Budget that time; it is real, and it is frequently left out of cycle-time estimates.

After finishing, edges can be brought to Ra 0.8–1.6 μm or finer by bead blasting, brushing or polishing. That is a separate operation with its own lead time, and it should be on the drawing from the start.

Profile tolerance on a laser is usually ±0.1 mm on thin stock and looser as thickness grows. That is fine for most sheet work. It is not the same as the ±0.005 mm we hold on a machining center, and confusing the two is a common source of failed first articles.

Hole size is the other trap. Small holes cut undersize because the beam has a finite kerf and the pierce point sits off center. If a drawing calls for a Ø3 mm hole with a ±0.05 mm tolerance, expect to drill or ream it after cutting.

Datum strategy matters too. If a laser-cut blank becomes the datum for a machining operation, any bow in the blank transfers straight into the finished part. We usually machine the datum surfaces first, then locate from them.

The practical rule: use the laser for outline and clearance features, and put anything with a tight callout on a mill or lathe. That split keeps cost down and tolerance honest.
