A repair visit that only swaps a part and walks away leaves you with the same failure in six months. What you want is a diagnosis with numbers attached: spindle runout before and after, squareness across the table, backlash on each axis, and a repeatability figure taken over 30 cycles. Those readings tell you whether the fault was a component or the geometry holding it.

Ask the provider what they measure and what instrument they use. A dial indicator on a magnetic base is fine for a quick check, but a ballbar or laser interferometer gives you a defensible record. If a shop quotes a price before measuring anything, the number is a guess.

The scope should also say who does the work. Spindle cartridge rebuilds, way scraping, and ballscrew replacement are three different skills. A general millwright can handle a pump swap, not a taper regrind. Ask directly and get the name of the person who will be on your floor.

Run these in order. Each one either clears the machine or points at a specific subsystem, so you are not paying for a shotgun approach.

Start with spindle runout at the taper, measured with a test bar. Anything above 0.005 mm on a precision machine is a problem, and above 0.010 mm it will show up as chatter or a finish that will not hold Ra 0.8–1.6 μm. Next, check the drawbar force; a weak clamp lets the tool move under load and mimics a spindle fault.

Then move to geometry. A ballbar circle test over 300 mm tells you about squareness, backlash, and servo mismatch in one pass. If the circle shows a step at the quadrant, that is backlash, not alignment. If it shows a long oval, that is scale or screw pitch error.

Finally, log thermal drift. Run the spindle at production speed for two hours and measure position every 20 minutes. A machine that moves 0.03 mm over a shift cannot hold tight tolerance no matter how many parts you replace. That drift is a design limit, and the fix is a warm-up routine or compensation, not a rebuild.

• 1
  Runout above 0.010 mmPlan for a taper regrind or cartridge rebuild, not just new bearings.
• 2
  Ballbar step at quadrantBacklash. Check the nut, the thrust bearings, and the coupling.
• 3
  Drift over 0.03 mm per shiftThermal, not mechanical. Fix with warm-up and compensation first.
• 4
  Repeatability worse than 0.008 mmLook at the guideways before touching the control parameters.

The contract is where most repair disputes start. Put the acceptance numbers in writing before the machine is touched. Spell out spindle runout after repair, squareness over the full travel, backlash per axis, and a repeatability figure. If the provider will not sign off on numbers, treat that as your answer.

Payment should follow the measurements, not the schedule. A common split is a deposit for parts, a second payment when the machine is reassembled, and a final payment after a witnessed accuracy test on your floor with your test bar. That final step is the one that matters, because a machine can pass a bench check and fail under a real cut.

Ask about the warranty on the specific work performed. Bearing replacement and way scraping carry different risk. Get the term in months and what voids it, such as running the machine past its rated load or skipping the recommended warm-up.

ISO 9001:2015 and IATF 16949:2016 tell you the provider runs a documented system with traceable records. That matters when a repaired machine later produces a bad batch and you need to know what changed. ISO 13485:2016 and ISO 27001:2022 matter if your parts are medical or your drawings are sensitive.

Certifications do not tell you the technician's skill. Ask what training the spindle rebuilder has and how many cartridges they have rebuilt this year. A shop that does ten a month will have better tooling and fixtures than one that does two a year.

Spare parts are the next trap. Original bearings, ballscrews, and drive boards for older machines can take weeks. Ask the provider how they source parts, whether they will fit used or aftermarket components, and what that does to the warranty. A cheap aftermarket screw that fails in three months costs more than the original.

Sometimes the honest answer is no. If the guideways are worn past 0.05 mm and the base casting has moved, re-scraping will not hold because the structure itself is no longer stable. The repair cost can approach a large share of a replacement machine, and you still have an old control and an old spindle.

A second case is when the machine is the wrong size for your work. If your parts have grown and the machine is running at its travel limit every day, repair money buys you a few more months of the same constraint. Better to move that capital toward a machine that fits the current job mix.

A third case is the orphan control. If the manufacturer is gone and no one supports the drives or the software, a mechanical rebuild leaves you with a machine that cannot be programmed or serviced. Check control support before you approve any mechanical work.
