  How the Cut Removes Metal
• 2
  From CAM Toolpath to Machine Motion
• 3
  Workholding and Setup Decide the Part
• 4
  Tolerance, Finish, and What Drives Cost
• 5
  Materials and Their Machining Behavior
• 6
  Process Choices by Part Requirement

Every milling operation is a controlled fracture. A flute edge enters the material, the material shears along a plane ahead of the edge, and a chip slides up the rake face. If the chip is too thin, the edge rubs instead of cutting and work hardens the surface. If it is too thick, the edge breaks down. The window between those two is the real subject of a CNC milling basics course.

Chip load per tooth is the number that decides which side of that window you land on. It depends on feed rate, spindle speed, and flute count. For 6061 aluminum on a 12 mm three-flute carbide end mill, 0.05–0.10 mm per tooth is a normal roughing range. Drop below 0.02 mm per tooth and the edge starts burnishing the wall.

Surface speed changes with the material, not the part. Aluminum runs fast, often 300–500 m/min. Stainless 316 runs at roughly a quarter of that. Titanium TC4 (Ti-6Al-4V) is slower still, and heat stays in the cut, so coolant delivery matters more than speed.

The radial and axial depth of cut set how much of the tool is engaged. A 50 percent radial stepover with a 1× diameter axial depth is a common roughing starting point. Full-width cuts at full depth push the tool into chatter unless the setup is very stiff.

• 1
  Chip load0.05–0.10 mm per tooth in aluminum, lower in steel
• 2
  Surface speedSet by material, not by part size
• 3
  EngagementRadial stepover and axial depth decide cutter load

CAM software does not cut metal. It writes coordinates. The post-processor turns those coordinates into G-code for a specific control, and the machine turns G-code into axis motion. A mistake anywhere in that chain shows up on the part, not in the software.

G00 moves at rapid feed to a position. G01 moves at the programmed feed. G02 and G03 cut arcs clockwise and counterclockwise. Most of a milling program is those four codes plus tool changes and coolant commands. Reading a program is a useful skill even for engineers who never touch the control.

Cutting direction matters. Climb milling, where the tooth enters at maximum chip thickness, pushes the tool away from the finished wall and usually gives better surface finish and longer tool life on a rigid machine. Conventional milling does the opposite. On older machines with backlash, conventional milling is sometimes the safer choice.

Toolpath style decides cycle time as much as feed rate does. Trochoidal paths keep radial engagement low and let the tool run deeper and faster. Adaptive clearing does the same in CAM. On a part with deep pockets, that change alone can cut cycle time by a third.

• 1
  G00 vs G01Rapid position vs programmed feed move
• 2
  Climb millingBetter finish and tool life on rigid setups
• 3
  Trochoidal pathsLow radial engagement, higher feed and depth

A perfect toolpath on a loose part produces scrap. Workholding has to resist cutting force in three directions and still let the tool reach the features. Vises are fine for blocky parts. For thin plates, vacuum chucks or adhesive fixturing spread the load and avoid distortion.

Zero point matters more than most people expect. A 0.02 mm error in the work offset shows up on every feature cut from that setup. Probing on the machine, rather than touching off by hand, removes most of that error and takes less time on a repeat job.

Thin walls are the classic failure mode. A 1 mm wall in aluminum will deflect under cutting force and spring back after the tool passes, leaving a tapered or wavy surface. Roughing both sides, leaving 0.3–0.5 mm for a finishing pass, and taking light finish cuts usually fixes it.

Multiple setups multiply error. Every re-clamp adds a new datum. On a part with tight relationships between faces, a five-axis machine or a mill-turn center can cut most features in one setup, which removes stacked tolerance. GreatLight runs 16 simultaneous 5-axis machining centers for exactly that reason.

• 1
  Vacuum and adhesiveBetter for thin plates than vise jaws
• 2
  On-machine probingRemoves hand touch-off error from the offset
• 3
  Wall deflectionRough both sides, leave 0.3–0.5 mm, finish light

Tolerance is not a single number for the whole part. A bearing bore at ±0.005 mm and a mounting hole at ±0.1 mm can sit on the same print. Cost tracks the tightest requirement, not the average one, because the tight feature sets the machine, the inspection plan, and the scrap risk.

Surface finish is separate from dimensional tolerance. Ra 1.6–3.2 μm is a normal as-machined finish. Ra 0.8–1.6 μm needs a controlled finishing pass. Ra 0.2–0.8 μm usually means a fine finishing strategy, a sharp tool, and often a second operation. Calling out Ra 0.4 μm on a non-sealing face adds cost for no function.

Feature geometry sets the floor on cost too. A pocket 4× deeper than its width needs a long, thin tool that deflects. A sharp internal corner needs a tool radius no larger than the corner. Both are machinable, and both raise cycle time. Redesigning to a 2× depth-to-width ratio and a corner radius of 1.5–2× tool diameter usually cuts cost more than any parameter change.

Datum choice is part of the tolerance plan. If the print dimensions from a face that the machine cannot reach first, the shop has to add a setup or re-datum in CAM. Dimensioning from the same face that will be the first machining datum keeps the stack short and the cost down.

• 1
  Tightest feature sets costNot the average tolerance on the print
• 2
  Finish is a separate calloutRa 0.4 μm where it is not needed adds cost
• 3
  Depth-to-width ratioPast 4×, tool deflection becomes the limit

Material choice changes the cut more than any other decision. Aluminum 6061 machines cleanly at high speed and holds a good finish. 7075 is stronger but more prone to distortion after machining because of residual stress in the plate. Rough it, stress-relieve if the geometry is thin, then finish.

Stainless steels split into two groups. 303 and 304 cut reasonably well with sharp tools and steady feed. 316 and 316L work harden quickly, so a light finishing pass with a dull tool makes the next pass harder. 17-4PH in the solution-treated condition is gummy; in the aged condition it machines better but the heat treat has to come before the finish cut.

Titanium TC4 (Ti-6Al-4V) and Inconel sit at the hard end. They hold heat in the cut, so the tool edge softens and wears fast. Low surface speed, high coolant pressure, and a rigid setup are not optional. Expect shorter tool life and plan the process around it.

Plastics behave differently again. POM and ABS cut cleanly but melt if the chip cannot clear. PEEK needs sharp tools and slower speeds. Carbon fiber is abrasive and wears carbide quickly, so coated tools or diamond-coated edges are worth the cost.

• 1
  6061 vs 70757075 distorts more; rough then finish
• 2
  316 and 17-4PHWork hardening punishes light dull-tool passes
• 3
  TC4 and InconelHeat stays in the cut; coolant pressure matters
