Precision processing means removing material along a controlled cutter path and holding the result inside a stated window. The window is the whole job. A part can be perfectly round and still be scrap if the diameter sits outside ±0.005 mm, and a part can be slightly out of round and still pass if the drawing only calls the diameter.

Three numbers decide whether a feature is achievable. Tolerance is the allowed deviation. Surface finish is the arithmetic mean roughness, written Ra. True position is how far a hole center may sit from its theoretical location. They trade against each other. Tightening one usually loosens the process window for the others.

The machine is only one link. Workholding, tool runout, coolant, material condition and room temperature all push the same part around. A 5-axis center rated at ±0.005 mm will not deliver that on a thin wall clamped in a vise with 0.03 mm of jaw lift.

So the useful question is never "how accurate is your machine." It is "what does this specific feature need, and what has to be controlled to get there." That is the frame for the rest of this guide.

A CNC machine positions a tool by counting. The control sends pulses to servos, the servos move ballscrews, and the screws push the table or the spindle. Every conversion has error. Ballscrew pitch error, thermal growth in the screw, bearing play and servo lag stack into what the control thinks is happening versus what the cutter actually does.

Linear scales close that loop on better machines. The control reads the table position directly instead of trusting the screw, which removes most of the screw error and a large share of the thermal drift. That is why two machines with the same nominal travel can hold very different tolerances on a long part.

Spindle error is a separate budget. Toolholder runout, tool imbalance and spindle growth with speed all show up as a size shift. Runout of 0.01 mm on a 10 mm end mill cuts a hole that is roughly 0.01 mm oversize before any axis error is counted.

Thermal drift is the slow one. A machine that starts at 21 °C and runs for four hours can move several microns as the spindle and screws warm. On a ±0.005 mm feature, that is the difference between in-spec and out. Shops that hold that tolerance either control the room or warm the machine before the first cut.

A workpiece moves under cutting force. Clamp a thin plate on two edges and the middle deflects while the cutter passes, then springs back after. The measured result is a bowed surface that looks like a machine error but came from the setup.

The fix is support, not more clamping pressure. Add a support under the cut, use a vacuum plate or a sacrificial backing plate, or machine in two operations so the second pass releases the stress from the first. Soft jaws bored to the part diameter do the same job for round parts.

Residual stress is the other half. Rolled plate and extruded bar carry internal stress from the mill. Remove material from one side and the part bends toward the remaining material. Rough first, let the part rest, then finish. For 6061 and 7075 plate, leaving 0.5–1.0 mm of stock for the finish pass is a common way to keep flatness.

Thin walls follow the same logic. A wall under 1 mm will deflect away from the cutter and then ring. Reducing radial depth of cut, increasing spindle speed and using a smaller stepover usually holds the wall better than slowing the feed.

Surface finish and dimensional tolerance are not the same requirement, but they interact. A Ra 0.8 μm finish on a face normally needs a finishing pass with a sharp insert, a small stepover and a stable setup. The same face at Ra 3.2 μm can come off a roughing pass.

Ra values are averages, so a burr or a single deep scratch can blow the number while the rest of the surface looks fine. Inspectors measure a short trace, often 0.8 mm cutoff. Where the trace sits matters, so call out the face if only one face needs the fine finish.

Material changes the ceiling. Aluminium cuts to Ra 0.2–0.8 μm with a polished cutter and good coolant. Stainless 316 work-hardens and tends to smear, so Ra 0.8–1.6 μm is a more realistic floor without a secondary operation. Titanium and Inconel sit higher still.

If a sealing face or a bearing bore needs better than Ra 0.2 μm, plan for lapping, honing or polishing as a separate step. Asking the mill to reach it in one pass usually adds cost and inspection time without holding the number.

Put the tight tolerance on the features that need it and leave the rest loose. A drawing where every dimension carries ±0.005 mm forces the shop to treat the whole part as critical, which raises cost and slows inspection without improving function. Datum the part properly so position tolerances can be checked.

Use geometric tolerancing where a simple size callout is ambiguous. Flatness, perpendicularity and true position describe the function directly. A hole pattern called by true position at Ø0.1 mm MMC can be checked functionally with a gauge, which is faster and less arguable than measuring each hole center.

State the finish only where it matters and name the face. Add the inspection method if the feature is critical, since a CMM and a micrometer can disagree on an edge break. If the part must match a mating component, send that component or its model.

Flag material condition too. 6061-T6 and 6061-O machine very differently, and a hardened 17-4PH part may need a stress-relief step before finishing. Those details change the process plan more than the tolerance number does.
