Tight tolerance is not a single number you buy. It is the sum of every error source between the spindle and the part. A shop that quotes ±0.005 mm is really quoting its ability to control thermal drift, tool wear, fixture stiffness, and machine geometry at the same time. Change any one of those and the same machine will drift out of band.

Start with machine geometry. A three-axis mill positions the tool with three linear axes. Add two rotary axes and every cut now depends on the accuracy of the rotary table, its backlash, and how the controller transforms coordinates near the pivot point. Simultaneous five-axis motion spreads wear across the tool and reaches faces a three-axis setup cannot, but it also stacks rotary error on top of linear error. That is why the number of axes is not the whole story.

Thermal behavior runs in parallel. Spindles heat up as they run. Ballscrews warm from friction. Castings absorb heat from the room and from the cut. A machine that cuts within ±0.005 mm at 8:00 a.m. can drift past that by noon if the shop does not manage warm-up cycles and coolant temperature. Good shops run a spindle warm-up program before the first tight cut and keep the room at a stable temperature.

Tool pressure and fixturing finish the picture. A long end mill deflects under side load; a thin wall bows away from the cutter; a part held only on the bottom face moves when the vise releases it. The best provider predicts these moves in the CAM setup and adjusts, rather than cutting to nominal and measuring the damage afterward.

Every process has a boundary. Below a certain feature size, a rotating cutter simply cannot reach. Deep pockets narrower than the tool shank need long-reach tooling, which deflects more. Aspect ratios past roughly 4:1 in a pocket start to push tool length, and by 8:1 you are usually better off with EDM or a different geometry.

Thin walls behave the same way. A wall under 0.5 mm thick will move under cutting force no matter how light the pass. It may spring back after the cut and look correct on a CMM, then distort when the part is clamped in service. If the design needs a wall that thin, the drawing should say so and the shop should plan stress relief and light finishing passes.

Surface finish has its own limit. Turning and milling produce a scalloped surface from the tool path. Ra 0.8–1.6 μm is a normal machined finish. Ra 0.2–0.8 μm needs slower feed, sharper tooling, and often a separate finishing pass. Chasing Ra below 0.2 μm with a cutter alone is usually wasted effort; lapping or polishing gets there faster.

Material hardness sets the ceiling too. Soft aluminum cuts easily but grabs and galls. Hardened tool steel above roughly 45 HRC needs carbide or ceramic tooling and lighter depths of cut. Titanium and Inconel work-harden at the surface, so a rubbing pass makes the next pass harder. A provider that knows this will adjust feeds and speeds instead of forcing the same recipe onto every alloy.

Ask what the shop measures, and how. A provider that only checks the finished part with calipers is telling you something. A provider with a CMM, a surface roughness tester, and a documented in-process check plan is telling you something different. Precision comes from controlling the process, not from sorting good parts from bad ones at the end.

Look at the machine list against your part. A 4,000 mm gantry handles long frames but will not hold ±0.005 mm on a 20 mm feature. A compact 500 × 500 × 450 mm machine with a clean thermal environment holds tight tolerance on small parts far better. Match the machine envelope to the part, not the other way around.

Check the quality system against your industry. ISO 9001:2015 covers general quality management. IATF 16949:2016 adds automotive traceability and PPAP expectations. ISO 13485:2016 covers medical device manufacturing. ISO 27001:2022 covers information security, which matters when your drawings are confidential. A provider holding all four has already built the paperwork your auditor will ask for.

Finally, ask how the shop handles a problem. Every provider will hit a dimension that will not hold. The difference is whether they tell you early with data, or ship it and hope. A quote that comes back with a DFM note about a thin wall or a deep pocket is a good sign. Silence usually means nobody looked.

The first article inspection report is the clearest signal you will get. It should list every dimension on the drawing, the nominal, the tolerance band, and the measured value. If the report shows only a few key dimensions, the shop did not check the rest. If the measured values sit at the edge of the band, the process is not centered and will drift out on the next run.

Watch the spread across a small batch. Order three to five parts and measure them. A centered process shows values scattered around the middle of the tolerance band. A drifting process shows values marching in one direction, which means tool wear or thermal growth is not being compensated. The second case is the one that fails at 10,000 parts.

Ask for the inspection method on any tight feature. A bore measured with a plug gauge is a go/no-go check, not a number. A bore measured with an air gauge or a CMM gives you a value you can trend. For ±0.005 mm features, the measurement method matters as much as the cut, because gauge error eats part of your tolerance budget.

Then compare the paperwork to the parts. If the report says Ra 0.8 μm and the surface looks visibly scalloped, one of the two is wrong. Trust the physical part. A provider that lets that mismatch leave the building is not controlling its own process.

Speed and precision pull against each other. A roughing pass removes material fast but leaves tool marks, heat, and residual stress. A finishing pass is slow but brings the part into tolerance. A provider that quotes a very short lead time on a tight-tolerance part is either planning to run light passes anyway or planning to skip something. Ask which.

Fixture design is where the trade-off shows up. A simple vise setup is fast but flexible, and flexible means the part can move. A dedicated fixture takes time to build but holds the part rigidly for the whole run. For one prototype, the vise is right. For 5,000 parts, the dedicated fixture pays for itself in scrap avoided.

Inspection strategy carries the same tension. Full CMM inspection on every part is slow and expensive. Sampling is fast but misses drift. Most shops use in-process checks during the run and a final inspection on a sample or on every part, depending on the industry and the drawing. The right answer depends on what a bad part costs you.

Material choice moves the balance too. Aluminum 6061 cuts fast and holds tolerance well. Titanium Ti-6Al-4V cuts slowly, wears tooling, and needs more coolant and lower speeds. A provider quoting the same lead time for both is not accounting for the difference.
