Every resin supplier publishes a tensile strength number and almost nobody publishes the test standard behind it. Before you compare two 3D printing r grades, find the standard. ASTM D638 Type I and Type IV specimens give different numbers from the same bottle, because the gauge length changes how the load spreads. ISO 527 uses a different specimen again.

The second thing to check is cure state. A part pulled off the build plate and wiped clean is not the material on the data sheet. Most published values assume a full post-cure under the supplier's recommended wavelength and time. Skip that step and a tough resin behaves like a brittle one.

Third, look at elongation at break next to tensile strength, not instead of it. A resin with 70 MPa tensile and 2% elongation is stiff. It carries load without deflecting, then cracks at the first sharp corner. A resin with 45 MPa and 25% elongation bends, absorbs impact, and holds a snap fit. Those are two different parts, not two quality levels.

• 1
  Find the standardASTM D638 Type I versus Type IV, or ISO 527, changes the result.
• 2
  Check cure stateData sheet values assume a full post-cure, not a wiped part.
• 3
  Pair strength with elongationStiff and tough solve different problems.

Layer orientation matters more in resin than in filament printing, though less than most people assume. A tensile bar printed flat and a bar printed on edge can differ by 10 to 20 percent in strength, because the layers run across the load path in one case and along it in the other. If a part sees bending, orient the build so layers run parallel to the neutral axis.

Impact resistance is where the gap between resin classes shows up fastest. Standard rigid resin at 3 to 6 percent elongation will survive a drop from a desk and shatter from a drop onto concrete. Tough ABS-like resin at 15 to 30 percent elongation takes the second drop too. For enclosures with clips, choose by elongation first.

Creep is the parameter engineers forget. A resin bracket holding a 2 kg load at 40 °C will keep moving for weeks. Published data rarely includes creep curves, so the practical test is a loaded sample on a shelf next to your desk. Check it after a week. If it has moved, the part needs metal or a glass-filled grade.

• 1
  Build orientationRun layers along the load path, not across it.
• 2
  Impact firstElongation predicts drop survival better than tensile strength.
• 3
  Creep testLoad a sample and measure it after seven days.

Heat deflection temperature, usually quoted at 0.45 MPa or 1.82 MPa, tells you when a loaded part starts to sag. Standard rigid resin sits around 55 to 65 °C at 0.45 MPa. A part in a car interior on a summer day can reach 70 °C. That part will bow.

High-temperature resins push the number to 120 °C and above, and the trade is elongation. They are stiff and often brittle. If your part needs both heat resistance and toughness, the honest answer is usually a machined or cast metal part, not a resin one.

Post-cure raises heat deflection, sometimes by 20 °C or more, but it also raises shrinkage. A part that measured 50.00 mm after wash may measure 49.85 mm after a full thermal cure. For anything with a fit, machine the mating part after the resin part is fully cured, not before.

• 1
  Car interiors70 °C is reachable and standard resin will sag.
• 2
  High-temp trade-offHeat resistance usually costs elongation.
• 3
  Cure before measuringShrinkage continues through post-cure.

Resin printing wins on geometry that cannot be cut: internal channels, lattice cores, nested parts, and organic shapes. It wins on speed for the first article, and it wins when you need five parts tomorrow.

It loses on anything that threads, bears load long term, or needs a tolerance tighter than ±0.1 mm across a long dimension. Resin shrinks during cure and keeps moving for days. Threads printed in resin strip at low torque.

For those parts we machine them. Aluminium 6061 holds ±0.005 mm and takes real threads. A machined bracket with a printed cover is a common split: the resin does the shape, the metal does the load. Send both and we quote them together with a DFM note on which features belong on which process.

The decision usually comes down to one question. Will this part be measured, or will it be looked at? Measured parts get machined. Looked-at parts get printed.

• 1
  PrintInternal channels, lattices, organic shapes, first articles.
• 2
  MachineThreads, long tolerances, sustained loads, wear surfaces.
• 3
  Split the partPrinted cover on a machined bracket is often cheapest.

Wash time is a real variable. Under-washed parts keep uncured resin in the surface, and that resin bleeds out over weeks, turning the part tacky and changing its dimensions. Over-washed parts in IPA go chalky and lose impact strength. Follow the supplier's wash time and change the solvent before it saturates.

Support placement decides surface finish on downward faces. Fewer, thicker supports leave larger marks. More, thinner supports leave a smoother face but take longer to remove and raise the risk of a failed build. For cosmetic faces, orient the part so the visible surface is either upward or vertical.

Post-cure in a chamber with the correct wavelength, usually 405 nm for LCD and DLP, and rotate the part halfway through. A part cured on one side only will be hard on the top and soft underneath. That difference shows up as warping after a few days.

• 1
  Wash timeUnder-washed bleeds, over-washed goes chalky.
• 2
  Support marksKeep cosmetic faces upward or vertical.
• 3
  Rotate during cureUneven cure causes warping days later.
