Every custom CNC cutting work operation is a controlled fracture. A rotating or advancing edge presses into metal until the material ahead of it shears away as a chip. The force needed depends on the material's shear strength, the cross-section of the chip, and how much of the tool flute is touching the workpiece at once. A common end mill removing 0.5 mm radial depth in 6061 aluminium sees far lower forces than the same tool in 17-4PH stainless at identical feed.

That force has to go somewhere. It pushes back through the tool, the holder, the spindle, and the fixture into the machine bed. Any element in that chain that deflects will move the cutting edge away from its commanded position. This is why a machine quoted at ±0.005 mm positional accuracy can still produce a part that is 0.05 mm out of flat: the control is accurate, but the loop is not stiff.

Chip evacuation matters as much as cutting. Aluminium forms long stringy chips that wrap around the tool if the flute space fills. Titanium and stainless work-harden, so a dwell or a rubbed cut turns a soft surface into a hard one that kills the next pass. Feed per tooth, coolant delivery, and depth of cut have to be chosen together, not one at a time.

• 1
  Shear, not abrasionSharp edges shear material; dull edges rub, generate heat, and work-harden the surface.
• 2
  Deflection closes the loopTool, holder, fixture, and spindle all bend under load and shift the cut.
• 3
  Heat stays localMost heat leaves with the chip. Poor evacuation means the part absorbs it and grows.

A drawing tolerance is a promise about the finished part, not about the machine. The gap between the two is usually fixturing. When a part is held in a vise with three points of contact and cut on the fourth side, the released stress and the clamping pressure both move the geometry. Thin walls spring back after the vise opens. Long parts sag between supports.

The practical fix is to plan the datum set before programming. Choose one primary datum face that stays untouched across operations, then reference every subsequent setup to it. Where a part needs five-sided access, a dovetail or a machined soft jaw carries more rigidity than a standard vise and lets the tool reach the bottom face without re-clamping the finished surfaces.

For parts that are long relative to their section, support the middle. GreatLight's 4,000 × 400 × 150 mm travel envelope allows a single setup on large frames, but a 4,000 mm part still needs intermediate jacks or a matched fixture to stop chatter in the center. Chatter leaves a visible pattern and a surface finish that drifts from Ra 0.8–1.6 μm to far worse.

• 1
  One datum, all operationsKeep a single reference face untouched so every setup shares the same origin.
• 2
  Clamp where you are not cuttingMove clamping away from thin sections to reduce release distortion.
• 3
  Support long spansIntermediate support prevents chatter and keeps wall thickness uniform.

A single machining operation can hold tight limits because the tool never leaves its reference. The trouble starts when a part needs two or three setups. Each re-clamp adds a positioning error that stacks with the machine's own repeatability and with any thermal growth from a warm spindle. The sum is what the inspector sees, not the best single number on the datasheet.

Thermal drift is often underestimated. A spindle running for hours can grow a few tens of microns, and a part that measured in tolerance at 9 a.m. may drift by mid-afternoon. For tight work we let the machine reach thermal equilibrium before the first cut and keep the finishing pass short so the part is measured soon after it is cut.

The drawing itself can absorb some of this. Where a feature only needs to sit accurately relative to another feature, dimension it that way instead of from a distant edge. Reducing the number of intermediate references removes error before the machine even starts.

• 1
  Count your setupsEvery re-clamp adds position error. Fewer setups means tighter stack-up.
• 2
  Warm up before finishingLet the spindle stabilize so thermal growth does not drift into the final pass.
• 3
  Dimension feature to featureShort reference chains carry less accumulated error than long ones.

Custom CNC cutting work covers more than one method, and the geometry usually picks the process. Prismatic parts with pockets, slots, and angled faces go to milling. Round parts with a dominant axis of symmetry go to turning, where a single continuous cut produces a rounder, better-finished surface than an interpolated one. Mill-turn centers handle parts that need both, and GreatLight runs 16 of them alongside 16 simultaneous five-axis machining centers.

Five-axis matters when the part has features on many faces or when a single setup is worth more than raw speed. Tilting the tool also lets a short, stiff cutter reach deep pockets that a long three-axis tool would have to reach with chatter. For a bracket with holes on four sides, one five-axis setup replaces three or four three-axis setups and removes the position error between them.

Hardened or heat-treated parts change the picture. Once material passes roughly 45 HRC, carbide milling gets expensive and slow. Wire EDM cuts fully hardened steel without cutting force, holds sharp internal corners, and leaves no burr. It is slower per part, so it suits features that milling cannot reach rather than bulk removal.

• 1
  Prismatic to millingPockets, slots, and contoured faces are milled with 3, 4, or 5 axes.
• 2
  Axial to turningRound parts cut in one continuous pass come out rounder and smoother.
• 3
  Hardened to EDMWire EDM cuts post-hardened steel without force or burrs.
