Direct CNC Service Explanation: What to Check Before You Order
This direct CNC service explanation is for design engineers and sourcing leads who need a real part, not a sales pitch. You will see which parts a direct shop should quote, which numbers to demand in writing, and when to walk away.
In this article
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
What matters most
Which machining route fits your part
Match the geometry and volume to the process before you compare prices.
| Part situation | Right process | Why |
|---|---|---|
| 3 faces, simple pockets, 500+ pcs | 3-axis mill | Cheapest cycle time, easy fixturing |
| 4th-side features, slots, cross holes | 4-axis mill | One setup, fewer re-clamps |
| Undercuts, deep cavities, blisks | 5-axis simultaneous | Tool reaches at an angle in one pass |
| Turned OD plus milled flats | Mill-turn center | Avoids two machines and two datums |
| Thin walls under 1 mm | 5-axis with light passes | Lower radial load, less chatter |
| Prototype, 1 to 5 pcs | 3-axis or 5-axis, no MOQ | Fixture cost dominates, not volume |
What a complete RFQ response should contain
| Item | Weak response | Strong response |
|---|---|---|
| DFM feedback | None, price only | Named risks and suggested changes |
| Tolerance | One general note | Feature-by-feature callouts |
| Lead time | Vague 2–4 weeks | Quote, DFM, start, ship dates |
| MOQ | 500 pcs minimum | 1 pc to 10,000+ pcs |
| Certification | We are ISO certified | ISO 9001, IATF 16949, ISO 13485 |
| Inspection | Visual check | 100% inspection, reports on request |
Pick the shop that answers questions, not the one with the lowest number
A direct CNC quote is only useful if it tells you what could go wrong and what it costs to prevent it. Ask for the DFM note, the tolerance map and the inspection plan. If those three are missing, the price is not comparable.
What a direct CNC service explanation actually covers
A direct CNC service means one supplier takes the CAD model, makes the fixture, cuts the metal, runs the finish and inspects the part before it ships. You are not chasing a broker who forwards your file to a second shop. That matters when a part has tight tolerances, because every handoff adds a new datum and a new chance for error.
The alternative is a layered supply chain: a sourcing agent, a machine shop, a plating vendor and a third-party inspector. Each step adds days and markup. On a simple bracket that is fine. On a 5-axis housing with a Ø400 mm rotary table setup, it becomes a quality risk.
We run 127 high-precision CNC machines across 3 wholly-owned plants, with 16 simultaneous 5-axis centers and 16 mill-turn centers. This direct CNC service explanation is based on the parts that actually come through those machines, and on the RFQs that go wrong before cutting starts.
Seven checks that separate a real shop from a reseller
First, demand a DFM note with the quote. A real shop will point out that a 0.8 mm wall on a 7075 part will deflect, or that a 12:1 depth-to-diameter hole needs peck drilling and a longer cycle. If the quote is just a price and a lead time, you are talking to a middleman.
Second, ask where the tolerance applies. General block tolerance of ±0.1 mm is normal. Critical features might need ±0.005 mm. Get the drawing marked so the shop knows which is which. Otherwise they will quote the loosest reading and the part will fail inspection.
Third, check the machine list against your geometry. A shop with only 3-axis mills cannot cut an undercut in one setup. If your part has compound angles, you need a 5-axis center or a lot of custom fixturing.
Fourth, ask about inspection. 100% inspection before shipment, with raw material check and in-process monitoring, is the baseline. Reports should be available on request. A shop that only inspects the first article is not ready for production.
- 1DFM noteSpecific feedback on walls, pockets and tool reach.
- 2Tolerance mapWhich features are tight, which are general.
- 3Machine matchAxis count and table size against your geometry.
- 4Inspection planWhat is measured, when, and what report you get.
How to read lead time, MOQ and certification claims
Lead time is not one number. A quote that says 3–5 days for shipping is only useful if you know when production starts. Ask for the full chain: quotation and free DFM analysis within 12 hours, production start within 24 hours, parts ship in 3–5 days. That is a schedule you can plan around.
Minimum order quantity is a filter. Some shops will not touch a single prototype. Others will run one part and then scale to 10,000+ pieces. If you are in the prototype phase, no MOQ matters more than a small price difference.
Certifications are not decoration. ISO 9001:2015 covers quality systems, IATF 16949:2016 covers automotive, ISO 13485:2016 covers medical devices and ISO 27001:2022 covers information security. Match the certificate to your industry. A medical implant supplier needs ISO 13485, not a generic quality claim.
Confidentiality is part of the deal. Uploads should be secure and confidential, and an NDA should be available on request. If a shop hesitates on an NDA for a defense or medical part, keep looking.
Materials and finishes change the quote more than you think
Aluminium 6061 and 7075 cut fast and hold tight tolerances well. Stainless 316L and 17-4PH are tougher on tooling and slower, so the cycle time rises. Titanium Ti-6Al-4V and Inconel need lower cutting speeds and more rigid setups. If your quote does not change between 6061 and Inconel, something is wrong.
Finishes add their own lead time. Anodizing, electroless nickel, powder coating and black oxide are common. Bead blasting and polishing change surface texture. Laser marking has a minimum character height of 1.5 mm, so do not design 0.5 mm text and expect it to read.
Surface finish is specified in Ra. As-machined is Ra 1.6–3.2 μm, a high finish is Ra 0.8–1.6 μm, and fine work reaches Ra 0.2–0.8 μm. Each step down adds polishing or a slower finishing pass. Tell the shop which surfaces actually need it.
When a direct CNC service is the wrong choice
Direct CNC is not always the answer. If your part is a thin sheet metal enclosure, laser cutting and bending will be faster and cheaper. If you need 50,000 identical plastic housings, injection molding wins on unit cost. If the geometry is a lattice or internal channel that no cutter can reach, additive manufacturing may be the only route.
Direct CNC also loses when tolerances are loose and the part is simple. A shop with 5-axis centers and mill-turn machines has overhead. You pay for capability even if you do not use it. For a flat plate with four holes and ±0.2 mm tolerance, a local 3-axis job shop is enough.
The honest test: does your part have features that need multiple setups, tight tolerances, or a finish that must be controlled? If yes, a direct shop with the right machines and inspection saves you time. If no, keep the process simple.
How to run a direct CNC RFQ in seven steps
Follow these in order and you will get a comparable quote from every shop.
- 11. Prepare one clean CAD fileSTEP or IGES, plus a 2D PDF with tolerances and datums. Send only one version to avoid confusion.
- 22. Mark critical featuresUse color or callouts for anything tighter than ±0.05 mm. State the general block tolerance separately.
- 33. List material and finishGive the alloy grade, for example 7075-T6, and the finish, for example clear anodize. Vague specs get vague prices.
- 44. State quantity and target dateOne prototype, 50 pcs, or 10,000 pcs. Include your needed ship date so the shop can flag risk.
- 55. Ask for a DFM noteRequest written feedback on walls, deep pockets, tool reach and any feature that drives cost.
- 66. Compare the same scopeCheck that every quote covers machining, finish and inspection. A low price that excludes anodizing is not low.
- 77. Confirm inspection and paperworkAsk what is measured, what report you receive, and whether an NDA is needed before files move.
Common questions
What does direct CNC service mean compared to a broker?
A direct service means the shop you talk to owns the machines and the inspection. A broker forwards your file to another shop.
The practical difference is speed and accountability. With a direct shop you get DFM feedback from the people who will cut the part, and one point of contact if something goes wrong.
How tight a tolerance can a direct CNC shop hold?
We hold ±0.005 mm on critical features when the drawing calls for it and the setup supports it.
That number only applies to the features marked as tight. General tolerances on the same part are usually ±0.1 mm. Mixing the two is the most common source of failed inspection.
Is there a minimum order quantity?
No. We run from one prototype to 10,000+ part runs.
For a single part, fixture and setup cost dominate the price. That is normal, not a penalty.
How fast can a quote and a part arrive?
Quotation and free DFM analysis come within 12 hours. Production can start within 24 hours, and parts ship in 3–5 days.
Those windows assume a clean CAD file and a confirmed material and finish. Missing information is the main cause of delay.
Which certifications should I check?
We hold ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022.
Match the certificate to your industry. Automotive work needs IATF 16949. Medical devices need ISO 13485. Information security matters when you share sensitive designs.
Can you handle large parts?
Yes. The maximum processing size is 4,000 mm, with travels of 4,000 × 400 × 150 mm on the largest machines.
For smaller work we run 750 × 1,150 × 550 mm, 600 × 600 × 600 mm and compact 500 × 500 × 450 mm cells. Send the envelope and we will match the machine.
Send your part and get a real DFM response
Upload a STEP file and we will return a quote with DFM notes, material options and an inspection plan. No minimum order quantity, and your files stay confidential.
12-hour quote100% inspectionNo MOQNDA on request
