A machined cold plate looks like a flat aluminum block with pockets and a groove. On paper it holds a few dimensions. In a battery pack it also has to hold a flat mating face, keep coolant inside, and reject heat from cells, IGBT modules or a charger without adding pressure drop. Those three jobs sit on different scales.

Heat leaves the die or cell, crosses a thermal interface pad, enters the plate wall, and finally reaches the coolant. Each joint adds resistance. Machining decides two of them: how flat the contact face is, and how thin and uniform the wall is above the channel. A wall that varies by 0.3 mm across the plate costs you far more than a wall that is 0.3 mm thinner everywhere.

So the drawing tolerance is not the whole story. Two plates can both pass a ±0.05 mm check and behave differently in the pack, because one was roughed, stress-relieved and finished in a stable sequence, and the other was cut in one pass on a warm machine. EV thermal management plate machining is mostly about controlling that sequence.

A conventional bracket can tolerate a burr, a small burr on a coolant port does not matter. On a cold plate it can flake off later and travel to the pump. That single difference is why deburring and channel inspection belong in the process plan, not in a note at the bottom of the drawing.

Most liquid cold plates for batteries and power electronics are machined from 6061-T6. It welds, brazes, anodizes and machines well, and its thermal conductivity of roughly 167 W/m·K is enough for the heat fluxes seen in a module. We also run 6061, 6063, 6082, 5052 and 5083, plus 7075 when the plate doubles as a structural member.

7075 gives higher strength but machines with more residual stress and is harder to weld. If the plate is brazed to a cover, 6061-T6 is the safer pick. If the plate is bolted to a chassis and carries load, 7075 or 6082 earns its cost. Copper C101 or C110 appears in high-flux inverter plates where aluminum spread resistance is too high, but copper is three times denser and needs different tooling and coolant.

Channel geometry sets pressure drop. A serpentine with many tight turns raises both heat transfer and pump load. A parallel channel array cuts pressure drop but can starve the middle channels if the inlet manifold is not sized properly. Machined pockets with a wall of 1.0–2.0 mm above the channel are common; below 0.8 mm the wall can bow during machining and distort the floor of the channel.

Tell the shop the flow rate and the allowed pressure drop, not just the pocket depth. A plate that meets every dimension but chokes the loop at 4 L/min is a failed design, and it is cheaper to fix in CAM than in a bench test.

Aluminum moves when you remove material. A 400 × 300 × 12 mm plate with deep pockets on one side will bow toward the machined side once the clamps come off. The fix is not a stronger clamp. It is a process that removes stock evenly, releases stress, and finishes the sealing face last.

A workable sequence for a typical cold plate: face both sides to establish thickness, rough the pockets leaving 0.5 mm of stock, stress-relieve or rest the part, semi-finish, then finish the sealing face and the channel floor in the same setup where possible. If the sealing face and the channel floor are cut in two setups, the relationship between them depends on the fixture, not on the machine.

Vacuum chucks and low-pressure clamps work better than heavy vises on thin plates. On a 6 mm base, a vise can push 0.05 mm of distortion into the part that shows up only after unclamping. For large plates we use the 4,000 × 400 × 150 mm travel machines so the whole part sits in one setup and the number of re-clamps drops.

Thin floors also chatter. Reduce axial depth, raise spindle speed, and use a cutter with a small corner radius. On a 1.5 mm floor, a 6 mm end mill at 0.2 mm axial depth cuts cleaner than a 12 mm cutter at 1 mm depth. The heavier cut deflects the floor and leaves a witness mark on the coolant side.

The sealing face is the most expensive real estate on the plate. Ra 0.8–1.6 μm is usually enough for an O-ring or a gasket; a mirror finish is not automatically better, because some gasket materials need a slight texture to bite. What matters more is flatness and the absence of a step at the groove edge.

Groove depth and width must track the O-ring datasheet. A groove that is 0.1 mm too shallow will not compress the ring enough; 0.1 mm too deep and the ring will not seal at low pressure. Cut the groove with a sharp tool, deburr the edges, and never leave a raised lip on the inner wall. A raised lip lifts the cover and creates a leak path that no gasket can close.

Ports need the same care. Threaded ports should be machined with a form tool or thread milled, not tapped by hand, so the thread is concentric with the boss. A port that is 0.2 mm off center can load the fitting seal unevenly. Burrs inside a port are hard to see and easy to leave.

Every plate leaves the shop after leak testing. Air pressure decay is the common method for production, with water or helium testing reserved for high-spec programs. We inspect 100% of parts before shipment, and reports are available on request. A plate that passes a dimensional check but fails pressure decay is scrap, so test it before you ship it.

Not every feature needs ±0.005 mm. Put the tight tolerance where it earns its cost: the sealing face flatness, the groove depth, the port position, and the channel floor. Pocket outline dimensions can usually live at ±0.1 mm. That split keeps the price sane and the inspection focused.

Flatness is the number that decides most assembly problems. A common target is 0.05 mm over the sealing face on a plate up to 300 mm long. If the cover is bolted at 40 mm pitch, local flatness between bolts matters more than global flatness. Say which one you need, they are measured differently.

First article inspection reports matter for automotive programs. A full dimensional report on the first part, plus in-process checks on flatness and groove depth for the rest of the run, catches drift before it becomes a batch problem. We hold ±0.005 mm on critical features and 99.99% qualification across production runs.

Draw the datum scheme you actually use. If the plate is located by two dowel holes in the pack, those holes should be the datum, not a corner. When the drawing datum and the assembly datum disagree, the shop will meet the drawing and the part will still fight the fixture on your line.
