A metal printer does not make a finished part. It makes a near-net shape attached to a build plate, with supports, residual stress, and a surface that a mating bore will not accept. So when a supplier quotes five days, the number is really a statement about how many of the following steps they control: file review, build preparation, printing, stress relief, support removal, finishing, and inspection.

This is where most quotes quietly break. A broker prints well but outsources heat treatment. Heat treatment runs on its own schedule, often in batch loads. Then the part travels to a machine shop for the critical bore, then to a finisher, then back for inspection. Each handoff costs a day or more and reintroduces the risk that the part arrives out of tolerance after the last operation.

At GreatLight we run additive and subtractive work under one roof across 3 wholly-owned plants, 7,600 m² of floor space, and 127 high-precision CNC machines. That layout is not about capacity for its own sake. It removes the gaps where rush jobs lose their days.

One more thing about the word fast. Ask what is being measured. A shop that prints in 48 hours but needs two weeks of post-processing is slower than a shop that prints in four days and ships finished parts in five. Compare finished-part dates, not print dates.

• 1
  Print time is one of seven stagesEverything after the build decides whether the part is usable.
• 2
  Handoffs cost daysHeat treat, machining, and finishing vendors rarely share a schedule.
• 3
  Compare finished datesA quote is only fast if the part leaves in spec.

Laser powder bed fusion melts metal layer by layer, typically in 20–60 μm layers. Each pass heats and cools the part unevenly. The cooler regions resist the contraction of the hot ones, so stress builds inside the part instead of relaxing. Cut the build plate too early and that stress releases as warp, bow, or a cracked support.

Printers are also not machining centers. A metal printer holds general dimensional accuracy in the range of a few tenths of a millimeter on a good day, which is far from the ±0.005 mm that a bored bearing seat or a dowel hole needs. No amount of printing speed closes that gap. It is a different machine class.

So the fast route to a precise metal part is usually hybrid: print the organic geometry that would be expensive to cut, then machine only the features with tight callouts. A topology-optimized bracket can print in near-net form while its two mating bores are cut on a 5-axis center to ±0.005 mm with Ra 0.8–1.6 μm finish.

If your part is a simple block with three holes, printing is the wrong start. A 3-axis mill cuts it in hours from 6061 or 17-4PH bar stock, with no support removal and no heat treat detour. The fastest metal part is often the one that never enters a printer.

• 1
  Residual stress is the warp sourceStress relief before plate removal is not optional on thin or long parts.
• 2
  Printer accuracy ≠ machining accuracyTight bores and flats belong on a CNC center.
• 3
  Hybrid shortens the critical pathPrint the hard geometry, cut the tight features.

Metal additive pays off when geometry defeats subtractive tools. Internal cooling channels that curve and branch cannot be drilled. Lattice regions save mass without dozens of setups. Conformal channels in a mold insert or a heat exchanger are the classic case: the print does what no mill can reach, and the machined faces around it stay simple.

It also pays off when the part count is low and the design is still moving. With no minimum order quantity, one prototype through a 10,000+ part run is possible, and design changes cost a file, not a tool. That matters in aerospace brackets, EV thermal hardware, and robotics end effectors where the first article is often the fifth revision.

It stops paying off when the part is mostly prismatic. If 80% of the volume is flat faces, slots, and straight holes, a printed blank still needs those faces finished, and you pay additive cost plus machining cost. Compare the two quotes honestly: printed near-net plus finish machining against bar stock plus 5-axis.

Material choice decides the rest. Ti-6Al-4V, Inconel, and 17-4PH are common in additive, and the same grades appear in our machining stock, so a hybrid route keeps one material spec across both operations. Mixing grades between print and finish creates paperwork and inspection headaches you do not need on a rush job.

• 1
  Good fitConformal channels, lattices, hollow sections, low volume, moving design.
• 2
  Poor fitMostly prismatic geometry, high volume, flat sealing faces.
• 3
  Check the gradeConfirm the printed and machined material match the drawing.

Stress relief usually runs before the part is separated from the plate, because the plate itself restrains the part. Temperatures depend on the alloy, commonly in the 600–900 °C band for titanium and stainless grades, then controlled cooling. Skip it and the part may look fine on the plate and move the moment it is cut free.

Support removal is hand work and it is where thin features break. Printed supports are designed to be weaker than the part, but a 0.8 mm wall does not care. Expect the shop to cut supports with a saw, grind the stubs, and bead blast the surface. Bead blasting also cleans the semi-sintered powder from internal channels, which is easy to forget until flow testing fails.

As-printed surfaces typically sit around Ra 10–15 μm, rougher than most sealing and sliding interfaces accept. CNC finishing brings a face to Ra 1.6–3.2 μm as-machined, or Ra 0.2–0.8 μm with finer passes. Add anodizing, electroless nickel, black oxide, or powder coating if the drawing calls for it, and remember laser marking needs a minimum character height of 1.5 mm.

Every one of these steps has a queue. The real question for a rush job is whether those queues sit in the same building as the printer. When they do, a part can be printed, relieved, cut, machined, finished, and inspected in one sequence instead of five separate vendor schedules.

• 1
  Relieve before separationThe build plate restrains the part until stress is out.
• 2
  Clean internal channelsTrapped powder shows up as flow restriction or contamination.
• 3
  Plan the finish earlyCoating and marking add their own lead time.

Speed does not excuse skipped inspection. Every part we ship goes through 100% inspection before shipment, covering raw material check, in-process monitoring, and final inspection, with reports on request. On a hybrid job the in-process checks matter most, because a bore that drifts after heat treat is cheaper to catch before finishing than after.

Certification is a separate question from speed. We hold ISO 9001:2015, IATF 16949:2016, ISO 13485:2016, and ISO 27001:2022, which matters when the printed part feeds an automotive, medical, or defense program with its own documentation requirements.

The historical late-delivery probability across our work is below 2%. That number comes from running the whole sequence in-house, not from expediting shipments after the fact. A part that is finished on day four does not need a courier miracle.

One practical note for engineers: ask for the inspection report with the parts, not after. Dimensional data, material certificates, and finish measurements should travel with the shipment so incoming inspection does not become the next bottleneck.

• 1
  100% inspection before shipmentRaw material, in-process, and final checks; reports on request.
• 2
  Four quality systemsISO 9001, IATF 16949, ISO 13485, ISO 27001.
• 3
  In-house sequenceLate-delivery probability historically below 2%.
