A CNC machine does not read a drawing. It reads a program, and the program only makes sense inside a setup. That is why a how cnc machines work PDF is not a textbook chapter. It is a package of four linked documents: the part drawing with tolerances, the setup sheet, the tool list, and the G-code listing with a program number. Read them in that order.

The setup sheet is the part engineers skip and then regret. It names the fixture, the zero point for X, Y and Z, the work offset number (G54 to G59), and the stock size. If the drawing says the datum is the bottom face and the setup sheet says Z0 is the top face, the part will be produced 12 mm short and every feature will shift.

The tool list gives each cutter a station number, a diameter, a corner radius and a length offset (H value). A 6 mm end mill with a 0.5 mm corner radius is not the same as a square 6 mm end mill, even if both sit in the same holder. The radius shows up on every internal corner, and it is the usual reason a mating part will not seat.

Finally, the G-code listing. You do not need to read all 4,000 lines. Read the header, the first approach move, and the tool change blocks. Those three places carry most of the risk. The rest is repetition you can scan.

One more thing about the PDF itself. Treat it as a living file. When a machinist swaps a tool or shifts an offset to hold a tight bore, that change belongs in the document. On a 10,000-part run, an undocumented offset shift is how a batch drifts out of tolerance around part 600.

• 1
  DrawingGeometry, datums and tolerance callouts such as ±0.005 mm.
• 2
  Setup sheetFixture, work offset number, Z zero face and stock size.
• 3
  Tool listStation, diameter, corner radius and length offset for each cutter.
• 4
  Program listingHeader, approach moves and tool changes are the parts worth reading.

The controller reads the program one block at a time and converts each block into axis motion and switch commands. On a three-axis mill, X, Y and Z move the tool relative to a fixed table. On a five-axis machine, two rotary axes tilt either the tool or the work, so the cutter can reach a face that would need a second fixture on a three-axis machine.

The order inside a block matters. A typical line reads G01 X50.0 Y25.0 Z-3.0 F400. The G01 sets the mode, the X, Y and Z values are the endpoint, and F400 sets the feed in millimeters per minute. The machine interpolates a straight line from the current position to that endpoint. It does not know or care where the material is.

Compensation happens in the controller, not in the geometry. G41 and G42 offset the path left or right by the cutter radius stored in the offset table. If the operator measures the tool and enters 5.98 mm instead of 6.00 mm, the finished slot will be 0.02 mm oversize. The program text is identical. The part is not.

Rapid moves are where crashes live. G00 moves at the machine's maximum rate and ignores the feed value. A G00 Z10.0 written before the tool clears the vise jaw will drive the holder straight down into steel. Every safe program lifts Z first, then moves in X and Y.

Spindle speed and feed are linked through chip load. Feed in mm per minute equals spindle rpm times number of teeth times chip load per tooth. For a 10 mm three-flute carbide cutter in 6061-T6 at 8,000 rpm and 0.05 mm per tooth, that is 1,200 mm/min. Push the chip load past 0.1 mm per tooth in aluminium and the cutter will chatter; drop below 0.02 mm and it will rub and work-harden the surface.

Aluminium is the forgiving case. 6061-T6 cuts clean at 300–500 m/min surface speed with uncoated or ZrN-coated carbide and generous coolant. 7075 is stronger and gummier; drop the surface speed about 20% and keep the chip load up so the tool does not rub. Thin walls below 1.5 mm need a lighter radial depth of cut, usually 5–10% of the cutter diameter, or the wall will deflect and spring back undersize.

Stainless 304 and 316 work-harden quickly. Keep the cutter engaged, never let it dwell, and use a feed high enough to stay under the hardened layer. A 6 mm cutter at 0.03 mm per tooth and 2,500 rpm is a reasonable starting point, with flood coolant. 17-4PH in the H900 condition is harder again; expect shorter tool life and check the first article for size before running the batch.

Titanium Ti-6Al-4V and Inconel sit at the other end. Surface speed drops to 30–60 m/min, coolant must reach the cutting edge, and a rigid setup matters more than a fast one. If you hear a high-pitched squeal, the tool is rubbing, not cutting. Stop and adjust the feed before the insert fails.

Plastics behave differently again. POM and ABS cut fast but melt if the chip cannot clear. Use sharp two-flute cutters, high spindle speed, and air blast instead of flood coolant. PEEK and carbon fibre are abrasive; carbide with a diamond coating lasts noticeably longer than plain carbide on carbon fibre laminates.

A tolerance without a datum is a guess. When a drawing calls out a bore at Ø20.00 +0.02/0 mm, it also has to say which face the bore is measured from. GD&T callouts solve this with a datum reference frame, usually three faces marked A, B and C. In the setup, those three faces become the work offset and the fixture stops.

Finish callouts follow the same logic. Ra 0.8–1.6 μm is a standard machined finish from a sharp cutter at a moderate feed. Ra 0.2–0.8 μm needs a finer stepover, a smaller chip load, or a finishing pass with a dedicated tool. On a deep pocket, a long reach cutter will chatter before it reaches that finish, so the geometry may need a design change rather than a process change.

Position tolerance is where most arguments start. A hole pattern at true position Ø0.1 mm is achievable on a rigid three-axis machine with a good fixture. Tighten it below Ø0.05 mm and you are into five-axis territory with in-process probing, because thermal growth over a 4,000 mm part will eat the budget on its own.

The practical check is simple: can the machine reach the tolerance over the full part length? GreatLight holds ±0.005 mm on parts within the machine envelope, and every shipment gets 100% inspection with reports available on request. If a feature sits beyond the envelope, the part is split into two setups, and the second setup adds its own stack-up.

Most scrap is not caused by a bad program. It is caused by a setup that changed after the program was proven. The vise jaw gets replaced, the fixture gets re-clamped, or a new operator loads the wrong tool. That is why the first article matters more than the tenth.

Measure the first article against every callout, not just the tight one. A part that holds the Ø20 mm bore but misses the 50 mm bolt spacing will not assemble. Record the measured values on the setup sheet so the next operator starts from a known baseline rather than an assumption.

Watch for tool wear on long runs. A 10,000-part order will outlast several inserts. If the operator only checks the last part of each shift, the batch can drift 0.03 mm before anyone notices. In-process monitoring catches the trend, not just the endpoint.

Thermal drift is the quiet one. A spindle running at 12,000 rpm for six hours grows, and Z moves with it. On tight work, let the machine warm up with a 10–15 minute spin cycle, then set offsets. If the shop is not temperature controlled, plan the tightest features for the first hours of the shift.
