The bar sits in a feed channel behind the headstock. A pusher drives it forward through a guide bushing, and the headstock itself travels on the Z slide. The bushing grips the bar with a clearance measured in microns. Because the headstock moves with the bar, the unsupported length between bushing face and cutting tool stays constant for the whole cycle. This is how CNC screw machines work in one sentence: the support point travels with the cut.

On a conventional chucking lathe the part is held at one end and the tool pushes against air at the other, so a Ø4 mm shaft with 40 mm of stick-out bends under a 0.3 mm depth of cut. On a screw machine the same part is supported millimeters from the tool, so the cut stays true even at length-to-diameter ratios of 10:1 or more. That is the reason the process exists.

Tolerances follow from that rigidity. On stable bar stock and a settled process, sliding headstock work holds ±0.005 mm on diameter and Ra 0.8–1.6 μm on turned surfaces. Tighter finish, down to Ra 0.2–0.8 μm, usually comes from a finishing pass with a wiper insert or from a secondary operation such as tumbling or polishing.

The trade-off is bar geometry. Anything that cannot be gripped as round bar needs a different plan. Parts with large flat features, deep pockets on the side, or wall sections under 0.5 mm often need a mill-turn center or a separate milling operation after the screw machine cycle.

• 1
  Guide bushing clearanceTypically 0.005–0.015 mm on the bar diameter for steel; too tight scores the bar, too loose lets it whip.
• 2
  Synchronized ZThe headstock feed rate equals the bar advance rate; a mismatch shows up as taper or a shiny rub mark.
• 3
  Sub-spindle pickupParts with back-end work are transferred mid-cycle so the second face is machined without a second setup.

Start with the bar. If the finished part fits inside a diameter range of roughly Ø1 to Ø32 mm and the material is available as ground or turned bar, the process is a candidate. Materials we run this way include 303 and 316L stainless, 6061-T6 and 7075 aluminium, C36000 brass, 1018 and 4140 steel, and TC4 titanium. Plastics such as POM and PEEK also run well, but they need tighter bushing clearance and lower cutting speeds.

Then look at the aspect ratio. A part with a long, slender feature is the strongest case for a screw machine, because that feature is where a chucking lathe fails. A Ø3 mm pin 30 mm long, a stepped shaft with a 2 mm spigot, a bone screw, a connector pin: all of these are natural sliding headstock work.

Volume matters more than size. Screw machines are efficient at high mix and low volume as well as long runs, because the setup is short and the bar feeder does the loading. A 200-piece run of a small turned part is reasonable. A single large block with machined pockets is not. When the part is basically a rectangular solid, milling is the honest answer.

There is also a geometry trap. Cross-drilled holes, flats and slots are fine if they sit near the front end of the part, because the machine can reach them with a driven tool while the bar is still supported. The further back they sit, and the larger they are relative to the bar diameter, the more the cycle wants a mill-turn center or a second operation.

• 1
  Good fitLong slender turned features, Ø1–32 mm bar, multiple diameters, threads and small cross holes near the front.
• 2
  Poor fitLarge flat plates, deep side pockets, heavy interrupted cuts on big diameters, parts that must be cast or forged first.
• 3
  BorderlineShort stubby parts with a lot of off-axis work; a mill-turn center is usually faster than two setups.

Hand-written G-code is a poor fit for synchronized Swiss work. Two or three axes move at once, the sub-spindle picks up the part mid-cycle, and the bar feed advances between operations. CAM software built for mill-turn and Swiss machines handles the synchronization and posts code that the control can run without manual axis juggling.

The practical starting point is the operation list, not the tool list. Write down every feature, decide whether it is cut on the main spindle or after transfer, and only then assign tools. Front-end work stays on the main spindle. Back-end work moves to the sub-spindle. If a feature appears on both ends, decide which end carries the datum and keep it there.

Tool assignment follows the zone logic. Turning tools sit on the front slide; driven tools and back-working tools sit on the gang or turret positions that can reach the part after transfer. A typical layout for a Ø6 mm stainless pin uses one rough turn, one finish turn, one threading tool, one parting tool and one back-chamfer tool. Five tools, no more, if the part is simple.

Cutting data should be conservative at first. For 303 stainless on a Ø6 mm bar, a starting point is 90–120 m/min surface speed, 0.03–0.06 mm/rev feed for roughing and 0.01–0.02 mm/rev for finishing. Aluminium runs faster, often 200–300 m/min. These are starting values. The first article tells you which way to move them.

• 1
  Order of workFeatures first, spindle assignment second, tool numbers third. Reversing this order causes collisions.
• 2
  Synchronization checkVerify that no two tools occupy the same zone at the same time before the first dry run.
• 3
  Bar feed logicThe advance must match the part length plus parting width plus a small safety margin, typically 3–5 mm.

Diameter drift during a run is the most frequent complaint. The first thing to check is bar feed slip. If the pusher loses grip, the bar stops advancing by the full stroke and the next part comes out short or undersized. Look for a polished band on the bar where the pusher has been slipping, and check the pusher collet for wear.

Poor surface finish on a long slender section usually points at bushing clearance or bar straightness. A bar that is not straight will whip inside the bushing and leave a chatter pattern. Check the bar on a surface plate, and if it is bent, replace it. Do not try to compensate with feed and speed; the pattern will move but not disappear.

Taper on a turned length is a synchronization or alignment problem. If the headstock feed and bar feed do not match, the effective depth of cut changes along the part and the diameter walks. Verify the sync parameters against the machine manual, and check that the guide bushing is not worn on one side.

Thread problems are usually tool offsets or pitch errors, not machine faults. Check the thread tool height and the programmed pitch against the drawing. If the thread is tight only on the first few parts, the material may be work-hardening; reduce surface speed by 10–15% and increase the finishing feed slightly.

Cold-start size shift is real and easy to miss. The first two or three parts after a cold start often run 0.01–0.02 mm off. Warm the spindle for 10–15 minutes, then re-check the first article. Do not chase the offset on a cold machine.

• 1
  Short partsBar feed slip or incorrect stroke. Check pusher grip and stroke length.
• 2
  Chatter on slender sectionsLoose bushing, bent bar or excessive depth of cut. Fix the support before the speeds.
• 3
  Size drift over a runThermal growth or tool wear. Warm up, then adjust offsets in small steps.
