The nameplate on a VF2 lists a total connected load, not a running draw. That figure assumes every motor starts at once, the spindle is at full rated output, the coolant pump is running, and the tool changer is mid-cycle. In practice you will never see that number on a clamp meter for more than a fraction of a second.

For a typical 40-taper VMC in this class, the spindle motor is the largest single load. A 15 kW (20 hp) spindle at continuous duty draws real watts only in proportion to the depth of cut and material removal rate. Cutting 6061 aluminum with a 12 mm end mill at moderate feed uses a small fraction of that rating. Hogging 4140 steel with a 50 mm face mill uses most of it.

So when someone asks about the watts of power a VF2 CNC machine uses, the honest answer is a range tied to the cut, not a single figure. Treat the nameplate as an upper bound and measure the real load before you commit to a breaker size.

• 1
  NameplateWorst-case connected load with every motor engaged.
• 2
  Measured cutWhat a clamp meter shows during a real toolpath.
• 3
  IdleControl, servos and lube hold a small steady load.

Break the machine into states and the numbers become manageable. With the control on, servos energized and spindle stopped, expect roughly 0.5–1.5 kW. Add the coolant pump and chip conveyor and you are near 1.5–2.5 kW. This is the load the machine carries between cuts, and it is what most shops underestimate when planning a panel.

During steady cutting the spindle load follows material and toolpath. Aluminum at moderate removal rates holds the spindle near 30–50% of rated power. Steel and stainless steel push higher, and titanium or Inconel can hold the spindle near 80% of rating for minutes at a time. Add axis servos, coolant and the tool changer and the total climbs into the 6–10 kW band for a 15 kW spindle machine.

Peaks come from acceleration. Spindle ramp from 0 to 10,000 rpm, a rapid traverse on all three axes at once, or a heavy interrupted cut can spike demand toward 15 kW for a few seconds. The breaker and feeder have to survive those peaks without tripping, even though the average is far lower.

• 1
  Idle0.5–1.5 kW with the spindle stopped.
• 2
  Coolant and conveyorAdds roughly 1–1.5 kW when running.
• 3
  Steady cut6–10 kW on a 15 kW spindle machine.
• 4
  PeakUp to about 15 kW during accel or heavy cuts.

Your electrician works in amps, not watts. For a three-phase feed the relation is watts equals volts times amps times the square root of three, times power factor. At 240 V three-phase with a power factor near 0.85, a 10 kW draw works out to roughly 28 A. At 15 kW it is near 42 A. That is why the VF2 is usually fed from a 50 A or 60 A three-phase breaker.

Voltage sags change the picture. A shop at the end of a long feeder sees the spindle pull more current for the same watts, and the drive trips on undervoltage before the breaker ever opens. Measure line voltage under load, not at rest. If it drops more than about 5% during a cut, the feeder is too small or the transformer is loaded by other machines.

Single-phase operation is not an option on a machine of this class. The spindle drive needs three-phase input to deliver rated torque. If your building only has single-phase service, plan for a rotary phase converter sized well above the machine rating, and expect some loss of spindle performance.

• 1
  10 kW at 240 V 3-phaseAbout 28 A with power factor near 0.85.
• 2
  15 kW at 240 V 3-phaseAbout 42 A, so a 50–60 A breaker.
• 3
  Voltage drop under loadKeep it under about 5% during a cut.

A machine that draws 8 kW during a cut does not draw 8 kW all day. Real duty cycle on a job shop VF2 is often 30–60% spindle-on time, with rapid moves, tool changes and part loading filling the rest. Multiply average load by hours to get kilowatt-hours, then by your local rate. For a shop running two shifts, that is the number that shows up on the utility bill.

Air cutting costs money too. Long rapids, conservative feeds and slow spindle ramp times all add idle watts without removing metal. If you are trying to justify a feed upgrade or a second machine, log the actual spindle-on percentage for a week. Most shops find it lower than they assumed, which changes the electrical plan.

Heat is the other cost. Every watt not turned into chip removal becomes heat in the spindle, drive or cabinet. A machine pushed near its rated watts for hours needs clean cabinet filters, working fans and a shop that can hold a reasonable ambient temperature. Overheating shortens drive life more than any other single factor.

• 1
  Spindle-on timeTypically 30–60% on a job shop machine.
• 2
  Energy costAverage kW times hours times your rate.
• 3
  HeatWaste watts load the cabinet and spindle bearings.

A VF2 covers a lot of work, but its power ceiling is real. If your parts need deep pockets in hardened tool steel, or long roughing passes in Inconel, the spindle will spend most of its time near rating. That shortens tool life, forces light depths of cut, and pushes the machine into thermal drift that shows up as tolerance problems.

For that class of work, more spindle power and a stiffer structure matter more than a bigger table. Machines with higher-rated spindles and box ways hold tolerance through heavy cuts. If your typical part is a large aluminum plate, the VF2 envelope may also be too small before power ever becomes the limit.

The practical test is simple. Look at your worst-case part, not your average part. If the worst case holds the spindle above about 80% of rating for more than a few minutes, the machine is undersized for that job and the watts question turns into a capability question.

• 1
  Heavy steel roughingSpindle runs near rating for long stretches.
• 2
  High-temp alloysInconel and titanium need more spindle power and rigidity.
• 3
  Large platesTravel limits may bind before power does.
