How to Diagnose Spindle System Failure on a Twin Spindle Machining Center

Two spindles share one control, one hydraulic circuit and one thermal environment, so a fault on one head often shows up on the other. This guide walks through the checks we run in our own shop, in the order that finds the cause fastest.
