A CNC lathe spins the workpiece while a single-point tool moves along X and Z. That is the whole difference from a mill, and it drives how you plan the job. On a lathe the part rotates, so every feature is defined relative to the centerline. Diameters are programmed in X, lengths in Z. If you come from milling, the first habit to break is thinking in Cartesian edges. Think in radii and faces instead.

Before you open CAM, you need three things on the bench: a released drawing with a clear tolerance block, a stock size that matches the bar or billet on the shelf, and a tool list that reflects what is actually loaded in the turret. A program built around a tool that is not in the machine is a program you will rewrite at the machine.

Check the drawing for features that a standard turning pass cannot reach. Cross-holes, milled flats, and slot features need live tooling or a second operation. If a feature sits on the back side of a shoulder, a right-hand tool will not cut it without a groove insert or a second setup. Flag those now, not after the first part is half finished.

Finally, decide which faces are datums. On a shaft, that is usually the finished face plus the centerline. On a bushing, it might be the bore. Write the datum callouts on the setup sheet so the operator and the programmer are working from the same reference.

• 1
  Drawing and revisionConfirm the revision letter matches the one in the traveler.
• 2
  Stock formBar, cast, or forged stock changes how much you rough in the first pass.
• 3
  Tool listMatch insert grades and nose radii to the material and finish callout.
• 4
  Datum calloutsMark the face and centerline datums on the setup sheet.

A turning program has a repeating shape: a safety block, a tool change, a speed and feed call, a positioning move, the cutting moves, and a retract. Once you see that pattern, reading someone else's program gets much faster. The header sets the work offset, the units, and the plane. After that, each tool block is a small self-contained story.

In inch or metric, pick one and stay in it. G20 and G21 are not interchangeable mid-program without a full rethink of your feeds and offsets. Most of our work runs in metric with G21 declared in the header. If the drawing is in inches, convert once and note the conversion on the setup sheet.

The work offset (G54 through G59) tells the control where the part sits. On a lathe this is usually a Z face plus an X centerline. Get the Z face from a touch-off on the finished face, not on the raw stock. Raw stock varies; the finished face does not.

Every program needs a safe retract position. Pick a point clear of the tailstock, the chuck jaws, and any live tooling. If you retract to a point that clears the part but not the jaws, the next tool change will tell you about it in the loudest possible way.

• 1
  HeaderUnits, plane, work offset, and a stop for the operator.
• 2
  Tool blockTool call, spindle speed, feed, and approach move.
• 3
  Cutting blockRough, finish, threads, grooves, and any live-tool work.
• 4
  Retract and endSafe position, spindle stop, and M30.

You do not need to memorize the whole G-code list. A working set of about a dozen codes covers the majority of turned parts. G00 moves at rapid, G01 at the feed you set. G02 and G03 cut arcs, clockwise and counterclockwise as viewed from the positive X axis. That viewing direction trips people up, so check it once and commit it to memory.

For turning cycles, G71 handles roughing a profile, G70 finishes it, G76 cuts threads, and G75 cuts grooves. G71 takes a start and end block for the profile, plus a depth of cut. A typical roughing depth on 4140 steel sits around 1.5–2.5 mm per side, while 6061-T6 can take 3–4 mm per side with the right insert.

Spindle control is G96 for constant surface speed and G97 for fixed RPM. G96 keeps the finish consistent as the tool moves across a changing diameter, but it needs a G50 max RPM clamp so the spindle does not overspeed near X0. On a small-diameter finish pass, that clamp is the difference between a clean cut and a spun insert.

Coolant, tool changes, and program stops round out the set. M03 and M04 start the spindle forward or reverse, M08 turns coolant on, and M00 stops the program for the operator. Use M00 deliberately, not as a substitute for planning the operation order.

• 1
  G00 / G01Rapid positioning and linear feed moves.
• 2
  G02 / G03Arc moves, viewed from positive X.
• 3
  G71 / G70Profile roughing cycle and its finishing pass.
• 4
  G76 / G75Threading cycle and grooving cycle.

Surface speed is the number that matters, not RPM. On 6061-T6 aluminium, 200–350 m/min is a reasonable roughing range with carbide. On 304 stainless, drop to 120–180 m/min and expect work hardening if the tool rubs. On titanium such as Ti-6Al-4V, keep surface speed low and never let the insert dwell in the cut.

Feed per revolution controls chip thickness and finish. A 0.8 mm nose radius insert at 0.15–0.25 mm/rev gives a finish in the Ra 0.8–1.6 μm range on many steels. Push the feed too low and the tool rubs instead of cutting. Push it too high and you trade surface finish for cycle time.

Depth of cut should engage the insert's intended range. Light passes on hard material wear the nose radius and generate heat. Heavy passes on a slender shaft push the part away from the tool and cut a taper. If the shaft is long relative to its diameter, use a tailstock or a steady rest before you blame the program.

Not every part belongs on a lathe. A flat plate with a few holes and a pocket is a mill job. A part with a deep internal cavity and no rotational symmetry is usually a mill or a mill-turn job. Mill-turn centers handle both, and we run 16 of them for parts that need turned and milled features in one setup.

• 1
  Aluminium 6061-T6200–350 m/min surface speed, 0.15–0.30 mm/rev feed.
• 2
  Stainless 304 / 316120–180 m/min, 0.10–0.20 mm/rev, keep the tool moving.
• 3
  Steel 4140150–220 m/min, 1.5–2.5 mm per side roughing depth.
• 4
  Slender shaftsUse a tailstock or steady rest before adjusting the program.

The most expensive mistake is a wrong work offset. If Z0 is set on raw stock instead of the finished face, every length in the program shifts by the stock allowance. The operator usually catches it on the first part, but only after the tool has already cut.

The second is ignoring tool deflection on a finish pass. A boring bar with a long overhang will push away from the cut. The result is a bore that measures small at the entrance and large at the back, or the reverse. Shorten the overhang or take a lighter finish pass.

The third is running G96 without a max RPM clamp. Near X0 the control commands very high RPM and the insert fails. Set the clamp to the spindle's safe limit for the workholding, and check it every time you change a work offset.

Chip control is the quiet one. On 304 stainless, a chip that wraps the tool will scratch the finish on the next pass. Adjust feed and depth to break the chip, or add a high-pressure coolant line if the machine has one.

• 1
  Wrong Z0Set Z0 on the finished face, never on raw stock.
• 2
  Tool deflectionShorten overhang before you change the feed.
• 3
  Missing RPM clampG50 or the control equivalent, set every setup.
• 4
  Chip wrappingFix feed and depth before adding a second coolant line.
