A bend is local plastic deformation. The inner surface compresses, the outer surface stretches, and one layer in between keeps its original length. That layer is the neutral axis. Its position controls how much material you need to feed into the tool to hit a target flange length. On a 2 mm mild steel sheet bent to R2, the neutral axis sits close to mid-thickness. On a tight R0.5 bend in 6061-T6, it shifts inward, and the outer fibers see far more strain than the drawing suggests.

Strain is the number that matters. For a sheet of thickness t bent to an inside radius r, outer fiber strain is roughly t / (2r + t). Bend 3 mm sheet to R1 and the outer surface stretches about 43%. Bend the same sheet to R6 and strain drops to 20%. Aluminum 6061-T6 cracks somewhere near 8–10% elongation, which is why tight bends in that temper need a larger radius or a different temper.

The minimum bend radius is not a rule from a handbook. It comes from the material's elongation at the bend line, the temper, and the grain direction. A 5052-H32 sheet will take a much tighter bend than 6061-T6 at the same thickness. Cut a test strip, bend it, and look at the outer surface under 10× magnification before you commit a full blank.

This is the core of the secret of the bend: the tool does not decide the radius. The material does. The die, the punch, and the tonnage only apply the force. If the outer fiber cannot stretch that far, the part cracks no matter how slowly the ram moves.

• 1
  Neutral axisThe unstretched layer; its position sets blank length and flange growth.
• 2
  Outer fiber strainApproximately t / (2r + t); keep it under the material's elongation.
• 3
  Grain directionBending across the rolling direction tolerates a tighter radius.

Every bend springs back when the ram lifts. The elastic portion of the strain recovers, and the angle opens. For mild steel, springback is often 1–3°. For 304 stainless it can reach 5–8°. For 7075 aluminum or 17-4PH, expect even more. A 90° punch does not produce a 90° part. The operator has to overbend by that amount, or the die has to be set with a compensating angle.

Springback scales with yield strength and with the ratio of bend radius to thickness. Thin sheet bent over a large radius springs back more because a larger share of the section stays elastic. Thick sheet bent tight springs back less. This is why a shop that runs 1 mm cold-rolled steel all day can still miss the first article on a 6 mm 304 stainless job.

Air bending gives you angle control through ram depth, so the same tool can hit different angles. Bottoming forces the punch into the material and nearly eliminates springback, but it needs 3–5× the tonnage and a dedicated die. Coining goes further and needs even more force. Pick bottoming when the angle tolerance is tighter than the press brake can hold in air bend.

You cannot grind springback out of a finished part. It has to be predicted before the first hit. For runs above 500 pieces, a test bend on the actual heat lot is cheaper than scrapping the first 50 parts. Ask for the elongation and yield values from the mill certificate, not just the grade name.

• 1
  Air bendingFlexible angle, needs ram-depth control, largest springback.
• 2
  BottomingLow springback, high tonnage, dedicated die per angle.
• 3
  CoiningNear-zero springback, highest tonnage, shortest tool life.

In air bending, the inside radius is set mostly by the die opening, not by the punch tip. A common shop rule is inside radius ≈ die opening / 6.5 for mild steel. Open the die and the radius grows; close it and the radius shrinks until the punch tip takes over. If the punch tip radius is larger than the natural radius, the punch controls instead. This is why tool selection is not a one-line decision.

Die opening also sets the required tonnage. A wider die needs less force but leaves a larger radius and more springback. A narrow die needs more force and can mark the outside surface. For 3 mm mild steel, a typical V-die opening is 18–24 mm. For 1 mm sheet, 6–8 mm. Push below those and the punch may bottom out or the die shoulder may dig in.

The punch tip radius has a hard limit. If you ask for an inside radius smaller than about 0.5× the sheet thickness, the tool will not produce it in air bend. You have to coin, or you have to machine the feature instead. That is where a CNC mill takes over: cut a relief groove, a radiused corner, or a full 3D form that no press brake can reach.

At GreatLight we run both paths. Sheet metal fabrication covers the press brake side. For tight radii, closed profiles, or bends that intersect a machined pocket, we cut the form on a 3-axis or 5-axis mill from solid stock. Tolerance on those machined bends holds to ±0.005 mm, far tighter than any press brake.

• 1
  Air bend radiusRoughly die opening / 6.5 for mild steel; die sets the radius.
• 2
  Punch-controlledWhen tip radius exceeds the natural radius, the punch wins.
• 3
  Machined bendUse when the radius is below 0.5× thickness or the profile is closed.

Tube bending adds two failure modes that flat sheet does not have: ovality and wall thinning. A mandrel inside the tube supports the inner wall and keeps the cross-section round. Without a mandrel, a 1D bend on thin-wall tube will flatten into an oval and the wall on the outside of the bend will thin by 15% or more. With a mandrel and a wiper die, a 1D bend is routine on 304 and 316 tube.

The wall factor and the bend factor decide whether you need a mandrel. Wall factor is outside diameter divided by wall thickness. Bend factor is centerline radius divided by outside diameter. High wall factor plus low bend factor means you need a mandrel. Low wall factor plus high bend factor means you can bend on a simple roll bender. Check both before you quote a tube assembly.

Machined reliefs are the other half of the story. When a bent sheet has to sit flush against a machined block, the corner where the bend meets the block is a stress riser. A relief groove cut at the bend line lets the sheet bend without tearing and lets the two parts seat. The groove width should be at least the sheet thickness plus 0.2 mm, and the depth about half the thickness.

A common mistake is to draw a sharp internal corner where a bend meets a milled pocket. The tool that cuts the pocket has a corner radius, usually 0.5–2 mm depending on the end mill. If the drawing shows a sharp corner, the shop has to either leave a radius or add a relief. Say which one you want on the drawing. It changes the fit and the cost.

• 1
  Mandrel bendingNeeded when wall factor is high and bend factor is low.
• 2
  Ovality limitKeep cross-section distortion under about 5% for fluid paths.
• 3
  Relief grooveWidth ≥ thickness + 0.2 mm; depth about half the thickness.

Give the shop three numbers, not one. State the inside radius, the angle, and the flange length after bend. If you only give the outside radius, the shop has to guess the thickness callout. If you only give the angle, springback is left to the operator. With all three, the brake operator can pick the die and set the ram depth in one pass.

Add the grain direction. A part that bends across the rolling direction will take a tighter radius than one that bends along it. If the grain direction is not controlled, the same drawing can pass on one heat lot and crack on the next. Mark the rolling direction on the blank layout and keep the bend line perpendicular to it where possible.

Call out the bend relief. If a flange ends next to a milled wall, a relief notch stops the tear that starts at the corner. A width of one thickness plus 0.2 mm and a depth of half the thickness is a safe starting point. Without it, the crack may not show until the part is in service.

For tight-radius work, send the 3D model as well as the 2D drawing. A STEP file lets us check for tool collision on a 5-axis machine and pick the right cutter. It also lets us quote the machined-form route against the press-brake route in the same DFM review. That review comes back within 12 hours with the quote.

• 1
  Three calloutsInside radius, angle, and finished flange length.
• 2
  Grain directionBend across the rolling direction for a tighter radius.
• 3
  Send STEPLets us check tool collision and compare forming routes.
