Tsaka CNC automatic lathe B0385 385L: how Swiss-type turning works

We explain the guide bush geometry, the Ø0.3–8 mm part window, and the stability limits of the Tsaka CNC automatic lathe B0385 385L. Written for engineers who need to decide whether a small turned part belongs on Swiss-type equipment or on a mill-turn center.

Ø0.3–8 mm windowGuide bush support±0.005 mm tolerance3–5 day shipping
Tsaka CNC automatic lathe B0385 385L turning a small precision part
Quick answer

Key takeaways

Guide bush is the whole pointSupport sits millimetres from the cut, so slender parts stop deflecting.
Sweet spot is Ø0.3–8 mmAbove 8 mm the guide bush advantage drops and a chucker or mill-turn wins.
Length-to-diameter decidesOver 4:1 slenderness is where Swiss-type turning separates from bar work.
One part per cycle, many featuresTurning, milling, drilling and cross drilling finish in a single pass.
Mechanism

What the Tsaka CNC automatic lathe B0385 385L actually does

The Tsaka CNC automatic lathe B0385 385L is a Swiss-type sliding headstock machine. Bar stock feeds through a carbide guide bush, and the cutting tools sit almost on top of that bush. The workpiece is supported within a few tenths of a millimetre of the cutting edge, so the bending moment that normally pushes a slender part away from the tool has very little lever arm to work with.

That single geometric fact drives everything else. Tool interference, axis layout, bar feed length and even coolant routing are arranged around keeping the unsupported length short. On the B0385 and 385L the working range is roughly Ø0.3 mm at the small end up to Ø8 mm. Below Ø0.3 mm the bar itself becomes hard to feed without buckling. Above Ø8 mm the guide bush no longer buys you much.

The machine carries live tools for milling, drilling, tapping and cross work. That matters because a part that needs a milled flat and a cross hole does not get handled twice. One bar feed, one cycle, one set of datums. For the volumes Swiss-type machines are bought for, that is the difference between a stable process and a scrap pile.

We are not the maker of this machine. When a drawing lands on our desk, we read it the same way we read any turned part: what is the smallest diameter, how slender is the longest unsupported section, which features need a second axis, and how many parts. Those four answers decide the process, not the machine name.

  • 1
    Sliding headstockThe bar moves, the tools stay put. Z travel equals part length, not machine size.
  • 2
    Guide bush clearanceTypically 0.005–0.02 mm on diameter. Too tight seizes, too loose loses support.
  • 3
    Live tool stationsEnable milling and cross drilling without a second operation.
Process window

Where the Ø0.3–8 mm window comes from

Bar diameter is not the only constraint. The guide bush has a bore, and that bore is fixed for the run. A Ø3 mm bar in a Ø3 mm bush gives you support. The same bar in a Ø5 mm bush gives you rattle. In practice a shop keeps a set of bush bores and matches them to the bar, which is why setup time on Swiss-type work scales with the number of different bar diameters in the job.

Feed rate is a second limit. As the bar gets thinner, the feed force has to drop, otherwise the bar buckles inside the bush. A Ø1 mm part might run at 0.02–0.05 mm/rev while a Ø6 mm part runs comfortably at 0.10–0.15 mm/rev. Spindle speed goes the other way. Small diameters turn fast because surface speed stays in the same band for a given insert.

Long parts change the picture again. A Ø4 mm part that is 30 mm long has a slenderness ratio near 8:1. Swiss-type turning handles that without a centre rest, because the support travels with the cut. A conventional chucker would need a tailstock, a steady rest, or several operations, and each re-chuck adds error.

The upper end of the window is where the trade-off bites. At Ø8 mm the guide bush is still useful, but a bar-fed chucker or a mill-turn center can often hold the same tolerance with fewer setup steps. Above that, tool shank stiffness and insert size start to favor the larger machine.

  • 1
    Bush bore matchingOne bore per bar diameter. Plan the run around how many diameters are in it.
  • 2
    Feed force limitThin bars demand low feed per revolution to avoid buckling.
  • 3
    Slenderness ratioAbove roughly 4:1, Swiss-type support starts paying off.
Material behavior

Material choice changes the setup, not just the speed

Free-machining stainless such as 303 turns cleanly on Swiss-type equipment. The chips break, the surface comes out near Ra 0.8–1.6 μm, and tool wear is predictable. A 316L or 17-4PH part behaves differently. Those alloys work-harden, so a dwell or a rubbed cut raises the surface hardness and the next pass cuts worse. On a guide-bush machine the fix is a higher feed per revolution, not a lower one.

Aluminium is the easy case. 6061-T6 and 7075 run at high spindle speed with sharp carbide and generous rake. The risk is chip packing around the guide bush, because aluminium chips are light and tend to wrap. A high-pressure coolant stream aimed at the bush exit clears them and keeps the part cool.

Brass and copper alloys are common on this class of machine. C36000 free-cutting brass machines faster than most stainless and leaves a good finish off the tool. Beryllium copper is the exception. It cuts well but the dust needs control, and we treat it as a controlled process rather than a routine one.

Titanium is where the guide bush earns its keep. Ti-6Al-4V at Ø5 mm over a 25 mm length would chatter on a chucker. With the support a few tenths behind the tool, the same part runs at a stable feed with flood coolant and modest cutting speed. The trade-off is tool life, which is why titanium jobs get quoted with a tool-change allowance built in.

  • 1
    Free-machining grades303 stainless and C36000 brass run with minimal intervention.
  • 2
    Work-hardening alloys316L, 17-4PH and Ti-6Al-4V need higher feed per revolution, never dwell.
  • 3
    Chip controlAluminium wraps; high-pressure coolant at the bush exit clears it.
Tolerances

Holding ±0.005 mm on small turned features

On a part with a Ø2 mm bore, a 0.005 mm error is a quarter of one percent of the feature size. Thermal growth in the bar and the spindle becomes a real term in the error budget. A shop that runs Swiss-type work watches spindle warm-up, coolant temperature and bar temperature, because a 5 °C shift moves a 20 mm steel part by roughly 0.002 mm.

The guide bush itself contributes. If the bush bore is worn, the bar sits off-centre and every diameter on the part shifts in the same direction. Checking bush wear is a routine step, not a diagnostic one. On a long run the bush is a consumable, and quoting a job without accounting for that is how a shop loses money on a tight-tolerance part.

Tool wear is the third term. Small carbide inserts on small diameters wear quickly because the cutting edge is short and the contact stress is high. In-process gauging or a tool-life counter catches the drift before it leaves the tolerance band. We inspect 100% of parts before shipment and keep reports on request, which is the practical way to close the loop.

The honest boundary: ±0.005 mm on a Ø1 mm feature over a long run is a process-control problem, not a machine-capability one. It can be held, but it needs a settled setup, a known tool-life schedule and a measurement method that does not add more error than it finds.

  • 1
    Thermal driftWarm-up and coolant temperature belong in the setup procedure.
  • 2
    Bush wearWorn bush shifts every diameter the same way. Check on schedule.
  • 3
    Tool-life countersSmall inserts wear fast. Change on count, not on sound.
Judgment

Choosing Swiss-type turning over milling for a small part

Start with the axis count the part actually needs. A simple Ø3 mm pin with two diameters and a chamfer is a two-axis turned part. Add a cross hole and it becomes a three-axis part. Add a milled flat on the side and a slot on the face and it is a four-axis job. Swiss-type machines cover that range comfortably, which is why they stay busy on connector pins, sensor housings and injection-moulded inserts.

The wrong fit is usually a part that is mostly a milled shape with a short turned feature. If 80% of the cycle time is milling a pocket, a mill-turn center or a 5-axis mill is the better home for it. Swiss-type machines can mill, but the tool envelope around a Ø4 mm bar is small, and long-reach milling tools chatter.

Volume is the second screen. Swiss-type work rewards a settled setup. One prototype is fine, but the setup cost per part is high, so the economics improve as the run gets longer. A job with ten different bar diameters and a hundred parts each is awkward. A job with one bar diameter and ten thousand parts is exactly what the machine was built for.

When the part sits near the Ø8 mm upper edge, run the comparison honestly. A bar-fed chucker with a collet and a tailstock can hold similar tolerance on a short, stiff part, and it takes larger tools. Swiss-type wins on slenderness, on features that need to be finished in one pass, and on parts small enough that handling becomes the bottleneck.

  • 1
    Count the axesTwo for turned features, three for cross holes, four for milled flats.
  • 2
    Mostly milled?Move it to a mill-turn or 5-axis center instead.
  • 3
    One bar diameterSingle-diameter, high-volume jobs suit Swiss-type best.
Shop practice

What we check before quoting a turned part

We read the drawing for the smallest diameter and the longest unsupported length first. That pair sets the process window. Then we look at the feature list and count how many need a second axis. Then we check the tolerance callouts against the feature size, because ±0.005 mm means something different on a Ø1 mm bore than on a Ø20 mm journal.

Material follows. Free-machining grades are routine. Work-hardening alloys get a different feed strategy and a tool-life allowance. Titanium and Inconel get quoted with longer cycle times and a note about tool changes, because pretending they run like brass is how a quote turns into a loss.

Volume decides the rest. From one prototype to 10,000+ part runs, with no minimum order quantity, we can match the process to the batch. A single prototype on Swiss-type equipment is a real option if the geometry demands it, but we will say so plainly when a mill-turn center would deliver the same part faster.

We have run turned and milled work since 2011 across 127 high-precision CNC machines in three wholly-owned plants, including 16 simultaneous 5-axis machining centers and 16 mill-turn centers. That matters here because a part that does not fit the Swiss-type window usually does fit one of the others, and the honest answer is to move it rather than force it.

  • 1
    Geometry firstSmallest diameter and longest unsupported length set the window.
  • 2
    Tolerance vs feature sizeA 0.005 mm callout on a Ø1 mm bore is a different job.
  • 3
    Match batch to processNo minimum order quantity, from one prototype to 10,000+ parts.
Selection data

Swiss-type automatic lathe vs bar-fed chucker vs mill-turn center

Use the part geometry, not the machine name, to pick a column.

CriterionSwiss-type automatic latheBar-fed chuckerMill-turn center
Typical part diameterØ0.3–8 mmØ6–40 mmØ6–80 mm
Slenderness handled8:1 and beyondAround 4:1Around 3:1
Guide bush supportYes, travel with cutNoNo
Cross drilling and millingLive tools, small envelopeLive tools, largerFull milling envelope
Number of bar diametersOne per run is idealFewFew
Best run lengthThousands of partsHundreds to thousandsOne to thousands
Setup cost per partHigh on short runsModerateLow on short runs
Typical choice forPins, sleeves, connector bodiesShafts, bushingsHousings, brackets

The short verdict

If the part is under Ø8 mm, slender past 4:1, and needs turned and cross-drilled features in one pass, Swiss-type turning is the right process. If it is mostly a milled shape or wider than Ø8 mm, send it to a mill-turn or 5-axis center instead.

FAQs

Questions engineers ask about Swiss-type automatic lathes

Can a Swiss-type automatic lathe cut a part larger than Ø8 mm?

The guide bush and bar feed set the practical ceiling. Above roughly Ø8 mm the support advantage shrinks while tool shank stiffness and insert size become the limiting factors.

A bar-fed chucker or mill-turn center handles those diameters with larger tools and fewer setup steps. The honest move is to change process, not to push the machine.

Why does feed per revolution need to increase on 316L stainless?

Austenitic stainless work-hardens. A light cut or a dwell rubs the surface instead of shearing it, and the rubbed layer is harder than the material underneath.

Higher feed per revolution keeps the edge biting under the hardened layer. Cutting speed comes down to control heat, so the two parameters move in opposite directions.

How much does guide bush wear affect part tolerance?

A worn bush lets the bar sit off-centre, and every turned diameter shifts in the same direction by a similar amount.

Because the error is systematic rather than random, it is easy to miss on a single sample check. Bush condition belongs on the maintenance schedule for any long run.

Is Swiss-type turning worth it for a single prototype?

Sometimes. If the geometry is slender enough that a chucker would need a steady rest or several re-chucks, the Swiss-type route can be the faster path even at quantity one.

If the part is short and stiff, a mill-turn center will usually deliver it sooner. We quote both when the answer is not obvious.

What surface finish comes off the tool on small turned parts?

As-machined turned surfaces typically land in the Ra 1.6–3.2 μm band. A settled setup with sharp inserts reaches Ra 0.8–1.6 μm, and fine finishing can reach Ra 0.2–0.8 μm.

The limiting factor on tiny diameters is often measurement, not the cut. A finish spec tighter than the metrology can resolve is not a useful spec.

How do we handle confidentiality on a turned part drawing?

Uploads are secure and confidential, and we sign an NDA on request before any drawing is reviewed.

For parts with tight tolerances we usually need the full drawing, including datums and tolerance callouts, because a partial view leads to a quote that misses a setup step.
