A conventional die casting cell makes small parts fast. Integrated die casting technology does the opposite: it fills one big cavity with a single shot, so a rear underbody that used 70 stamped parts becomes one casting. The mechanism does not change. Molten aluminium alloy enters a steel die at high speed and solidifies under pressure.

What changes is scale. A shot can exceed 40 kg of metal, travel 1.5 m or more from the sprue, and cool across sections that range from 2.5 mm to 12 mm. The filling front loses heat the whole way. That is the core engineering problem, and every production factor below exists to solve it.

Alloy choice sets the window. ADC12 flows well and tolerates thin walls. AlSi10MnMg (a common structural die casting alloy) gives higher elongation after heat treatment, which matters for crash-loaded parts. Magnesium AZ91D fills even faster but brings corrosion and flammability handling rules.

• 1
  Filling timeTypical large-part fill in 80–150 ms.
• 2
  Shot weightMachine capacity must exceed the casting plus biscuit and overflow.
• 3
  Gate areaToo small and the front freezes; too large and it flashes.

A large die is not one temperature. It is a map of hot spots near the gate and cold corners far from it. The target is a uniform die surface between roughly 180 °C and 250 °C at the start of each cycle. Miss that and the part tells you immediately.

Conformal cooling channels that follow the part surface pull heat out of thick bosses. Straight drilled lines are cheaper but leave heat behind in exactly the places that cause shrinkage porosity. For deep, thin ribs, a baffle or bubbler often beats a plain drilled channel.

Thermal balance is also a cycle-time factor. If one zone stays hot, the operator extends the cycle to protect the part, and cost per part climbs. Multi-zone oil heaters or hot-water units let you trim each circuit independently instead of slowing the whole die.

• 1
  Die surface target180–250 °C before fill.
• 2
  Hot spotsAdd bubblers or die inserts in thick bosses.
• 3
  Cold zonesLocal heaters, not a longer cycle.

Air trapped in a large cavity becomes porosity. In a small part, air escapes through the parting line before the metal arrives. In a 1.5 m cavity, the front moves fast enough to seal off pockets before they vent. Vacuum assist is the usual answer.

A vacuum system pulls the cavity down to roughly 50–200 mbar before the shot. The melt then fills into a near-empty space, and entrained air leaves with the gas stream. Vacuum alone does not fix a bad gate. If the gate sends metal past a pocket before the vent opens, the pocket is still sealed.

Vent placement and overflow design matter as much as the pump. Overflows act as reservoirs for cold metal and trapped gas. They add weight to the shot, so there is a real trade-off: more overflow means cleaner metal and a heavier biscuit to recycle.

• 1
  Cavity pressure50–200 mbar before fill.
• 2
  Vent depthTypically 0.10–0.20 mm at the parting line.
• 3
  OverflowsPlace where the front last arrives.

Hydrogen dissolves in molten aluminium and comes out as gas porosity during solidification. The higher the melt temperature and the longer the hold, the more hydrogen the bath picks up. Degassing with argon or nitrogen drops the level, and a rotary degasser does it faster than a lance.

Iron content is a second lever. Low iron reduces die soldering, a real problem on large dies with long contact times. Too much iron forms brittle platelet phases that cut elongation. Most structural alloys sit in a narrow iron band, and the supplier certificate is not enough.

Melt cleanliness is a process variable, not a purchasing detail. Oxide skins and inclusions travel with the front and end up in the last-filled region. Ceramic foam filters in the runner catch a good share of them. Weekly spectro checks and a hydrogen test on the furnace keep the window visible.

• 1
  HydrogenKeep below roughly 0.15 ml/100 g Al for structural parts.
• 2
  IronNarrow band; too low causes soldering, too high cuts ductility.
• 3
  FiltrationCeramic foam filter in the runner.

Thick sections cool slower than thin ones. The thin section freezes first and pulls metal from the thick one, which then shrinks and forms a void. This is why a 12 mm boss next to a 2.5 mm wall almost always shows shrinkage porosity at the center.

Designers can move the problem instead of solving it. Coring a thick boss into a thinner ribbed wall equalizes the cooling. A general rule: keep nominal wall between 2.5 mm and 4 mm, and design ribs at about 60–70 percent of the wall thickness with a draft of 1–2 degrees.

Some features cannot be cast cleanly at any thickness. Precision bores, sealing faces, threaded holes and bearing seats usually need machining after casting. Starting from a casting and finishing on a 5-axis machining center keeps the near-net shape and holds tight tolerances where the part actually interfaces.

• 1
  Nominal wall2.5–4 mm for large structural castings.
• 2
  Rib thicknessAbout 60–70 percent of the adjacent wall.
• 3
  Draft1–2 degrees on as-cast walls.

A casting is a near-net shape, not a finished part. Datum faces, bores, threads and sealing surfaces are cut after the part cools. Because a large casting moves slightly as residual stress relaxes, the machining setup must hold the part without forcing it into shape.

Heat treatment is a fork in the road. T5 or T6 treatment raises strength and elongation, but it also distorts the part and can blister if gas porosity is present near the surface. A part with high gas porosity should not go into a T6 furnace. The two decisions are linked.

Inspection closes the loop. X-ray or CT scanning shows internal porosity in critical sections. Dimensional reports on the machined interfaces confirm the casting plus machining stack. At GreatLight we machine cast and forged blanks to ±0.005 mm and hold finishes from Ra 1.6–3.2 μm as-machined down to Ra 0.2–0.8 μm when the drawing calls for it.

• 1
  FixturingSupport the casting; do not clamp it straight.
• 2
  Heat treatmentT5 or T6 only if porosity is low enough.
• 3
  InspectionX-ray or CT plus dimensional report on request.
