A controller does not read a drawing. It reads a stream of blocks, each block a line of words. A word is a letter plus a number: G for preparatory action, M for machine function, X Y Z for linear position, I J K for arc centers, F for feed, S for spindle speed, T for tool number. The controller parses the block left to right, applies the modal state, then moves.

Modal means the command stays active until another command in the same group replaces it. Issue G01 once and every following block with X Y Z coordinates feeds at the programmed rate. G00 rapid, G01 feed, G02 clockwise arc, G03 counter-clockwise arc. This is why a missing G01 near the top of a program can send a tool across the part at rapid speed.

Absolute and incremental positioning follow the same idea. G90 sets absolute mode, where every coordinate is measured from the active work origin. G91 sets incremental mode, where each coordinate is a distance from the last position. Most production programs run in G90. Incremental blocks appear in subprograms, drilling patterns and bar-pull routines on lathes.

Units are a group too. G20 selects inches, G21 selects millimeters. A program that mixes the two will not alarm out on every control. Some controllers simply scale the motion, and a 25 mm move becomes 25 inches of travel. Post-processor output must match the control setting, not the drawing units.

• 1
  G90 / G91Absolute or incremental coordinate interpretation.
• 2
  G20 / G21Inch or metric units for all axis words.
• 3
  G17 / G18 / G19Plane selection for arc interpolation: XY, XZ, YZ.
• 4
  G94 / G95Feed per minute or feed per revolution.

The CAM system knows the nominal tool diameter. The shop floor knows the real one. G41 and G42 tell the control to shift the toolpath left or right of the programmed contour by the value stored in the offset register. G40 cancels it. That register is where an operator enters the measured radius after touching off a tool.

Cutter compensation lets you adjust a feature without reposting the program. A slot that measures 0.03 mm undersize can be brought in by editing the wear offset, not by rewriting 4,000 blocks of CAM output. On a production run this is the difference between a two-minute correction and a two-hour one.

Length offsets work the same way. G43 applies the tool length offset from the register named by the H word, and G49 cancels it. If the H number points at the wrong register, the tool will rapid to the wrong Z height. That single mismatch is behind a large share of crashes on vertical mills.

Work offsets define where the part sits. G54 through G59 each hold a stored origin, so a fixture with several stations can run the same program at different locations. G10 lets a program write values into those registers, which is useful on pallet systems but risky on a manual setup.

• 1
  G41 / G42 / G40Left, right and cancel cutter radius compensation.
• 2
  G43 / G49Apply or cancel tool length offset via the H register.
• 3
  G54–G59Select a stored work coordinate system.
• 4
  Wear vs geometryKeep cutting-size tweaks in the wear column.

F and S are not universal constants. Surface speed depends on material, cutter coating, rigidity and coolant. A 12 mm carbide end mill in 6061 aluminium runs far faster than the same cutter in 17-4PH stainless. Copying a feed rate from one job to another without adjusting for material is how tools break.

Chip load is the more useful number. Feed per tooth multiplied by tooth count and spindle speed gives the table feed. Too low a chip load rubs the edge and work-hardens stainless. Too high a chip load deflects a small cutter and pushes a wall out of tolerance. Aim for the middle of the cutter supplier's range first.

On a five-axis machine the programmed feed is the tip feed, not the feed of every axis. When the rotary table swings, the linear axes can move faster than the commanded value to keep the tip on path. Controls handle this with feed rate limits, but tight radii at high feed still show up as chatter or gouges.

Rigidity sets the ceiling. A 4,000 mm long part on a large travel machine will chatter long before the same alloy on a compact machine. Keep the toolholder as short as the feature allows, and reduce overhang before you reduce feed.

• 1
  Start from surface speedThen convert to rpm for the actual cutter diameter.
• 2
  Check chip loadFeed per tooth should stay inside the supplier range.
• 3
  Watch tool overhangLong reach cuts the achievable feed rate.

Most programs come off CAM and run. Some do not. Editing on the floor is normal, but it should be deliberate and recorded. If you change a feed rate, a Z clearance plane or a tool number, the next setup needs to know.

Safe start blocks matter. A retract plane set too low can scrape a vise or a clamp. A rapid move through a fixture zone can crash a holder. Setting a clearance plane above the tallest obstruction, and checking the first approach in single block, catches most of these before the spindle turns.

Restart points change the risk. M00, M01 and M30 control program flow, while M03 and M05 start and stop the spindle and M08 and M09 control coolant. Jumping to a mid-program restart without re-establishing modal state leaves the control in whatever mode the last block used. Re-enter the modal set before letting the cycle run.

Subprograms and macros reduce repetition on families of parts. M98 calls a subprogram, M99 returns. A macro can calculate a pocket depth from a variable instead of hard-coding it. Both are powerful and both hide errors from a reader who only scans the main program. Document what each call does.

• 1
  Clearance planeSet it above the tallest fixture element.
• 2
  Single block the first runVerify approach moves before full feed.
• 3
  Log every editFeed, offset and tool changes belong in the setup sheet.

G code describes motion. It does not describe intent. A program cannot tell you whether a 0.05 mm wall deflection is acceptable for the part's function, whether a surface finish meets a sealing requirement, or whether the tolerance is realistic for the geometry.

Complex free-form surfaces push the format hard. A dense set of tiny linear segments approximates a curve well enough, but the block count grows and the control spends time reading rather than cutting. High-speed machining options and spline interpolation exist for this, and they are not available on every control.

Tolerance drives the decision. Features held to ±0.005 mm need the compensation, probing and in-process checks that a bare G code program does not include. If your part carries those tolerances, the programming conversation is about setup and metrology, not about G words.

For simple prismatic parts, hand-written or lightly edited G code is fast and predictable. For contoured, multi-setup or five-axis work, CAM output with a verified post-processor is the practical route. Both are legitimate. Pick based on geometry and tolerance, not habit.

• 1
  Prismatic and simpleShort programs are easy to verify by reading.
• 2
  Contoured and multi-axisCAM output wins on block count and verification.
• 3
  Tight toleranceSetup and probing matter more than the code itself.
