A screw for a bone plate and a screw for a machine enclosure start the same way: bar stock, a spindle, a turning tool. They stop being similar very quickly. The medical part carries load through living tissue, sits in a saline environment at 37 °C, and may be asked to survive 10 million gait cycles. Its minor diameter, root radius and flank angle are all functional dimensions, not reference ones.

That changes how we plan medical CNC screw processing. Thread root radius controls fatigue crack initiation, so a radius that looks acceptable on a profile projector can still shorten service life if it is inconsistent from part to part. Pitch diameter sets how the screw engages bone or a tapped plate. Runout between the thread axis and the head seat decides whether the screw seats flush or cams out under torque.

Small screws amplify every error. A 2.0 mm cortical screw has a minor diameter near 1.4 mm, so a 0.01 mm deviation is a much larger fraction of the remaining wall than it would be on a 12 mm bolt. At that scale, thermal growth of the workpiece, tool wear and fixture repeatability all show up in the finished thread.

None of this is exotic. It is ordinary machining discipline applied to a part that punishes shortcuts. The rest of this page covers the four variables that decide the outcome: material, thread method, heat, and inspection.

Ti-6Al-4V (TC4) is the default for load-bearing screws, and it is the material that separates a capable shop from a lucky one. Its thermal conductivity is roughly 7 W/m·K, about a tenth of steel. Heat generated at the cutting edge has nowhere to go, so it concentrates in the tool tip and the workpiece surface.

The practical consequences are specific. Cutting speed drops to 30–60 m/min for carbide in Ti-6Al-4V, well below what the same tool would run in 316L. Tool edges need to stay sharp and coated, typically TiAlN or AlCrN. Rigid setups matter more than spindle power, because chatter in titanium work-hardens the surface and raises the risk of a cracked thread root.

High-pressure through-tool coolant is close to mandatory on deep threads. We run it as a standard strategy rather than an option, because flood coolant alone rarely reaches the root of a small-diameter thread. Without it, you get built-up edge, torn flanks and a surface that looks fine under low magnification.

Stainless behaves differently. 316L and 17-4PH (SUS630) cut more predictably but work-hardens if the tool rubs instead of shearing. 17-4PH in the H900 condition gives high strength and is common for instruments; the annealed condition is easier to thread but needs a later heat treat that can distort thin shanks. 316L stays the choice for corrosion resistance and biocompatibility, at lower strength.

CP titanium grades TA1 and TA2 are softer and gummier. They thread cleanly at lower speeds but burr readily on exit, so deburring becomes a controlled step rather than a quick brush. PEEK screws appear in radio-transparent applications; they machine well but need sharp tooling and lower feed to avoid melted edges.

Thread milling uses a rotating multi-tooth cutter that orbits the bore or boss while the workpiece indexes. It produces a full thread in one helical pass, and because the tool is smaller than the thread, it handles interrupted threads, off-axis features and thin walls that a die head would distort. On a 5-axis center, it lets us cut the thread and the drive feature in the same setup.

Single-point turning remains the better choice for high-volume screws with a continuous thread and a straight shank. Cycle time is lower, thread form is generated by one controlled insert, and pitch diameter repeatability is excellent once the insert is dialed in. It is also easier to hold a specific root radius, which matters for fatigue.

Thread rolling is not machining, but it belongs in the conversation. Rolling forms the thread by displacing material instead of cutting it, which leaves a compressive stress layer at the root and typically improves fatigue strength. The trade-off is that rolled threads need a ductile material and a dedicated set of rolls, so it suits a stable, high-volume product rather than a 50-piece prototype run.

The decision usually comes down to volume and geometry. Below a few hundred parts with complex heads, thread milling wins on setup time. Above that, with a simple shank, single-point turning or rolling wins on cost per part. We run all three, and the quote reflects which one the geometry actually suits.

One more factor: thread form. Cortical screws use a relatively fine pitch for grip in dense bone. Cancellous screws use a deeper, coarser thread with a wider pitch to capture trabecular structure. Self-tapping flutes and self-drilling tips add features that must be cut after the thread, so sequence the operations carefully or the flute will interrupt the thread flank.

Most rejected medical screws fail for reasons that were never visible on the machine. Thermal growth is the classic one. A titanium blank can grow 15–20 μm over a long threading cycle as the part warms; measure it hot and it passes, measure it cold and it drifts out of tolerance. We control this with coolant, shorter passes and in-process gauging rather than trusting a single final measurement.

Chatter is the second. A slender screw shank has low stiffness, and any vibration leaves a pattern on the flank that reduces thread contact area. On a fatigue-loaded screw, that pattern becomes a crack initiation site. Reducing overhang, using a tailstock or a steady rest, and dropping radial engagement usually fixes it. Sometimes the answer is to change the process order and machine the thread before the shank is thinned.

Burrs are the third. A burr at the thread start or on a self-tapping flute can shed particles, and particle shedding is a serious problem in an implant. Controlled deburring, often by hand under magnification after machining, is part of the process rather than a cleanup step.

We hold ±0.005 mm on critical diameters and ±0.0002 in for teams working in imperial, across 127 high-precision CNC machines and 16 simultaneous 5-axis centers. Surface finish on thread flanks typically lands at Ra 0.8–1.6 μm, with Ra 0.2–0.8 μm available when a specification calls for it. Those numbers are only meaningful with a measurement plan behind them.

A certificate on the wall does not measure a thread. The measurement plan does. For medical work we start with raw material verification, including mill certificates and, where the specification calls for it, chemistry or hardness checks on incoming bar stock.

In-process monitoring follows. Pitch diameter is checked with thread gauges or optical comparison at defined intervals, and critical diameters are measured against the drawing rather than against a nominal. For small screws, optical measurement and vision systems give better data than a hand micrometer, because contact force on a 1.4 mm minor diameter can flex the part.

Final inspection is 100 percent before shipment, with reports available on request. That is a policy choice, not a marketing line. On a 10,000-piece run, sampling a threaded implant screw and hoping the untested parts match is a bad trade.

We work to ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022. The ISO 13485 scope is the relevant one for medical device components, and the ISO 27001 scope covers how design files and patient-adjacent data are handled. Uploads are treated as confidential, and an NDA is available on request before files move.

A useful rule for engineers: ask the supplier to describe how they measure thread root radius and runout, not whether they can. The answer tells you more than any equipment list.

Thread milling and turning are excellent for prototypes, low and mid volume, complex heads and design iterations. They are not always the right production route. Once a screw design is frozen and annual volume climbs into the hundreds of thousands, cold forming, heading or a dedicated screw machine may deliver a lower unit cost, provided the geometry has no undercuts and the material is ductile enough to form.

Very small screws have a practical floor. Below roughly M1, thread milling tools get fragile, chip evacuation becomes difficult and measurement uncertainty grows relative to the tolerance. Some of those parts are better made by a specialist micro-machining house or by a forming process.

Cannulated screws are another boundary case. The axial hole must be drilled deep and straight without wandering, and it reduces the cross-section that carries load. Deep-hole drilling on a long, small-diameter screw needs peck cycles and high-pressure coolant; a shop without that capability will struggle to hold concentricity between the hole and the thread.

Finally, porous or coated surfaces can be a regulatory decision rather than a machining one. If the surface treatment is part of the device's claimed performance, the machining supplier and the coating supplier need to agree on pre-treatment dimensions. We would rather flag that early than discover it at final inspection.

If your part falls on the wrong side of any of these lines, say so in the RFQ. A clear no on a quote is cheaper than a rework loop.
