New Hampshire CNC Processing Services: How to Pick One

• 1
  Key takeaways
• 2
  What to compare between New Hampshire CNC processing services
• 3
  Matching part geometry to the right machine
• 4
  Lead time, order quantity and quoting discipline
• 5
  Certifications, inspection and confidentiality
• 6
  Material and finishing questions that change the price
• 7
  Step by step: how to run a CNC quote comparison

Tolerance is the first filter. A shop that quotes ±0.005 mm on a part with five angled faces needs simultaneous five-axis capability, not a three-axis machine with a re-fixture between operations. Each re-fixture adds stack-up error. On a 100 mm aluminum bracket, two setups can eat 0.02 mm before the cutter touches metal.

Geometry matters as much as the number. Deep pockets, undercuts and compound angles push you toward five-axis. Flat plates with holes on one face are cheaper on a three-axis machine. We run 27 three-axis machines, 12 four-axis mills and 16 simultaneous five-axis centers, so the quote reflects the machine the job actually needs.

Wall thickness is the quiet cost driver. Below 0.8 mm in aluminum, chatter and deflection show up fast. Below 0.5 mm in stainless, you are gambling on the fixture. If your design has thin walls, say so in the RFQ. The shop can adjust cutter paths, add support wax or suggest a small rib.

Surface finish follows the same logic. Ra 0.8–1.6 μm is a normal machined finish. Ra 0.2–0.8 μm usually needs a finishing pass with a smaller stepover or a secondary operation. Ask which one is included before you compare prices, because the two numbers are not the same job.

• 1
  One setup beats twoFewer re-fixtures means less stack-up error and shorter cycle time.
• 2
  Thin walls need a planTell the shop about any wall under 1 mm before quoting.
• 3
  Finish is a separate line itemAs-machined, high-finish and fine-finish sit in different price bands.

Lead time has three parts, and shops usually quote only one. There is quoting time, programming and setup time, then spindle time. A shop can return a price in 12 hours and still start cutting three days later. Ask when the first chip flies, not when the PDF arrives.

Quantity changes the manufacturing method. One part is machined from billet. Fifty parts may justify a soft jaw or a dedicated fixture. At 10,000 pieces, a shop should be asking whether die casting or vacuum casting is cheaper than milling. We quote no minimum order quantity, from one prototype to 10,000+ part runs, because the method, not the price, is what should change.

Batch size also affects inspection. A one-off prototype often gets a full dimensional report. A 10,000-part run gets sampling plus in-process monitoring. Neither is wrong. They answer different questions. Decide which one your quality system needs before you compare suppliers.

Watch for quotes that arrive with no assumptions listed. A price with no material grade, no tolerance band and no finish callout is not comparable to anything. A useful quote states the stock size, the number of setups, the inspection level and the finish. If those are missing, ask.

• 1
  Quote time ≠ start timeAsk for both dates in writing.
• 2
  Quantity changes the processAt high volume, ask whether casting beats milling.

Certifications are only useful when you know their scope. ISO 9001:2015 covers a general quality system. IATF 16949:2016 applies to automotive production parts. ISO 13485:2016 applies to medical devices. ISO 27001:2022 covers information security, which matters if your CAD files are sensitive. Ask which process line holds the certificate, not just whether the company has one.

Inspection depth should match the part risk. For a bracket, a first-article check plus a final visual may be enough. For a medical implant housing or a fuel system component, you want raw material certification, in-process monitoring and a final dimensional report. We inspect 100% of parts before shipment and can supply reports on request.

Confidentiality is a real procurement issue, especially for prototype work. Uploads should be encrypted in transit, and the shop should be willing to sign an NDA before you release drawings. If a supplier hesitates on that, treat it as a signal about how they handle customer data.

Material traceability closes the loop. For aerospace and medical work, ask for the mill certificate and the heat lot number. It links your finished part back to the raw stock. Without it, a material substitution question has no answer.

• 1
  Check the scope, not the logoA certificate for one line does not cover the whole shop.
• 2
  NDA before drawingsSign it before you upload the STEP file.
• 3
  Traceability on requestMill certs and heat lot numbers for regulated parts.

Material choice is not just a strength decision. Aluminum 6061 machines fast and holds tolerance well. 7075 is stronger but gummier, so tool life drops. Stainless 316L work-hardens, which means light cuts and sharp tools. Titanium Ti-6Al-4V needs slow speeds and plenty of coolant. Inconel is the hardest of the common group and the slowest to cut.

Tell the shop the alloy and the temper, not just "aluminum" or "stainless." 6061-T6 and 6061-O machine differently. 304 and 316L behave differently under the same cutter. A quote built on the wrong temper is a quote that will change.

Finishing is a second supply chain. Anodizing, plating, powder coating and laser marking often happen outside the machine shop. If the shop coordinates those steps, you avoid shipping parts between vendors. If it does not, add two to five days and a freight leg to your plan.

Laser marking has a practical floor. Minimum character height is 1.5 mm. If your part number or UDI string is smaller than that, the mark will not read reliably. Adjust the drawing before tooling, not after.

• 1
  Name the temper6061-T6 is not the same job as 6061-O.
• 2
  Finish adds a logistics legAsk whether the shop manages plating and anodizing in-house.
• 3
  Marking has a size floor1.5 mm minimum character height.
