A web form makes every machine shop look the same. You upload a STEP file, pick a material from a dropdown, and a price appears. What that price means depends entirely on the machines behind the form. An online CNC machining service that runs three-axis mills only will quote a part with undercuts and simply miss the feature. One with simultaneous five-axis capacity cuts it in a single setup.

Tolerance is the first place this shows. A shop with older machines can hold ±0.1 mm all day and will quote that. A shop with 16 simultaneous five-axis machining centers and a Ø400 mm rotary table can hold ±0.005 mm (±0.0002 in) on datum-controlled features. Neither number is wrong. They fit different parts, and the quote should say which one you are buying.

The second place is setup count. Every extra setup adds a re-fixturing error. For a bracket with holes on four faces, a three-axis route needs three or four setups; a five-axis route needs one. Ask how many setups the quote assumes. If the answer is vague, the tolerance will be too.

• 1
  Ask for the setup planIt explains more about final accuracy than the machine list does.
• 2
  Match tolerance to functionDo not pay for ±0.005 mm on a clearance hole that only needs ±0.2 mm.
• 3
  Check the travel envelopeA 4,000 mm part needs a machine that can actually reach it.

Before comparing suppliers, write down three numbers on your own drawing: the tightest tolerance that matters, the surface finish on any sealing or sliding face, and the smallest internal corner radius. These three drive machine choice, setup count and cycle time. They also explain price differences you will see between quotes.

Tolerance should be tied to a datum. A common failure is a drawing with a ±0.01 mm callout on a hole position but no datum scheme, so the shop measures from a different edge than the one you designed from. When the part arrives out of position, nobody is technically wrong. Add datums before you send the file.

Surface finish is usually quoted as a range. Ra 1.6–3.2 μm is a normal as-machined result from a sharp insert. Ra 0.8–1.6 μm needs a controlled finishing pass and a clean tool. Ra 0.2–0.8 μm needs a separate finishing operation, often on a different machine, and adds a setup. Do not put a fine finish callout on the whole part if only one face touches a seal.

Small corners cost money. A 6 mm end mill leaves a 3 mm corner. If your internal corner is 0.5 mm, the shop either uses a 1 mm tool with a long reach and many light passes, or it sinks an EDM electrode. Both work. Both raise the price. Changing the corner to 1.5 mm often removes a whole operation.

• 1
  Datum firstFix the datum before you fix the tolerance number.
• 2
  Finish only where it functionsSealing faces and bearing fits, not cosmetic surfaces.
• 3
  Corner radius drives toolingRadius equals roughly half the cutter diameter.

Two lead times matter and they are often confused. The first is quote turnaround. The second is time to first cut. A supplier can return a price in an hour and still not start for two weeks because the material is not in stock. Ask both questions in the same email.

Material availability drives more delays than machining does. Aluminum 6061 and 7075, stainless 303 and 304, and standard tool steels are usually on the shelf. Inconel, titanium TC4 (Ti-6Al-4V) and magnesium AZ31B often are not. If your part uses a specialty alloy, ask whether the blank is in stock before you accept a date.

MOQ tells you how the shop is set up. A shop with a minimum order quantity of 500 pieces is optimized for volume and will price a single prototype badly. A shop with no minimum order quantity runs one piece and a 10,000+ piece run on the same floor. For R&D teams and hardware startups, the second model is usually the right fit, because design changes are normal.

A usable quote contains more than a number. It should state the material grade, the finish, the tolerance the price assumes, the inspection plan, and any DFM notes. If the quote is a single line of text, you will be negotiating change orders later.

• 1
  Ask both datesQuote turn and first cut are different commitments.
• 2
  Confirm the blankStock material is the biggest single lead-time variable.
• 3
  Read the assumptionsTolerance and finish in the quote define what you receive.

Certifications are scope documents, not badges. ISO 9001:2015 says a quality management system exists and is audited. IATF 16949:2016 adds automotive-specific requirements such as traceability and change control. ISO 13485:2016 is written around medical device manufacturing. ISO 27001:2022 covers information security, which matters when you upload proprietary CAD.

The practical question is not which certificates a supplier holds, but which one applies to your part. If you make automotive components, IATF 16949:2016 is the relevant framework. If you make a surgical instrument housing, ISO 13485:2016 is. A supplier holding all four can take the same shop through different documentation routes.

Confidentiality is a separate issue. Uploads should be secure and confidential, and an NDA should be available on request rather than treated as a special favor. For defense, medical and unreleased consumer products, sign the NDA before the first file transfer, not after the first quote. It costs nothing and removes a later argument.

Inspection evidence is the last item. A certificate does not tell you what was measured on your parts. Ask for first article inspection on the first run, and for dimensional reports where a feature is critical. 100% inspection before shipment is a process claim; a report is proof.

• 1
  Match the scopeAutomotive, medical and general ISO serve different buyers.
• 2
  NDA before uploadEspecially for unreleased products.
• 3
  Ask for the reportInspection data, not just an inspection claim.

Online quoting works best when the material list is finite and the prices are stable. Aluminum 6061-T6, 7075 and 2024 cut fast and hold tolerance well, which is why they dominate prototypes. Stainless 303 machines cleanly; 316L is tougher but needed for corrosion and medical parts. Steel grades 1018, 1045, 4140 and 4340 cover most structural and shaft work.

Titanium TC4 (Ti-6Al-4V) and Inconel are machinable but slow. Tool wear is high, feeds are low, and cycle time can be three to five times the aluminum equivalent. Budget for that before you choose the alloy. Magnesium AZ31B and AZ91D cut quickly but need care with chips and coolant.

Plastics behave differently again. POM and ABS are dimensionally stable and cheap to machine. PEEK holds strength at high temperature but costs many times more and needs sharp tooling. Carbon fibre machines well but the dust is abrasive and needs extraction, so expect a shop that handles it to say so openly.

Finishes are usually the last decision and the easiest to over-specify. Anodizing in clear, color, hardcoat and conductive variants covers most aluminum parts. Electroless nickel, zinc, silver and gold plating serve electronics and wear surfaces. Powder coating suits larger frames; black oxide suits tooling. Bead blasting, tumbling, brushing and polishing change appearance and, in some cases, edge geometry.

• 1
  Start with 6061-T6It is the default for functional prototypes.
• 2
  Price the alloy, not the partTitanium and Inconel change cycle time, not just material cost.
• 3
  Laser marking has a limitMinimum character height is 1.5 mm.
