Every precision CNC cutting solution removes material with a rotating edge that shears metal ahead of it. The tool pushes into the workpiece, the material deforms plastically, and a chip separates along a shear plane. Heat leaves with the chip. If the chip carries most of the heat, the part stays cool and dimensions hold. If heat stays in the part, it grows, the tool rubs, and the finish turns rough.

Chip load per tooth sets the pace. Too small a load and the edge rubs instead of cuts, which work-hardens stainless and burns the coating off carbide. Too large a load and the tool deflects, so the wall bows and the slot runs wide. On a 6 mm carbide end mill in 6061, a 0.05 mm load per tooth is a normal starting point; in 316 stainless it drops to roughly 0.02 mm.

Rigidity decides how close you get to ±0.005 mm. Tool overhang, fixture stiffness, and spindle bearings all add to the error stack. A tool hanging 60 mm out of a holder will deflect far more than the same tool at 25 mm. Short tools, short holders, and a fixture that supports the part near the cut do more for tolerance than any control setting.

• 1
  Heat pathChips carry heat away; coolant and air blast clear them.
• 2
  Chip loadBelow the minimum, the edge rubs and work-hardens.
• 3
  DeflectionOverhang multiplies error faster than feed rate does.

A three-axis machine moves the part under the tool in X, Y, and Z. It cuts flat faces, pockets, slots, and drilled holes well. Most brackets, plates, and housings never need more. Setup is simple and cycle times are short. If your part can be reached from one direction with a few refixtures, three-axis is the cheaper route.

A four-axis machine adds rotation around one axis, usually A. That lets the tool reach four sides of a part in one setup. Long shafts, cylindrical features, and parts with holes on multiple faces benefit most. The gain is fewer setups, which means fewer datum shifts and tighter position between features.

A five-axis machine tilts both the tool and the table. The tool can stay normal to a curved surface, so it cuts contours in one pass instead of many. This matters for impellers, turbine blades, and deep cavities with undercuts. It also lets a short, stiff tool reach features that a three-axis machine would need a long tool for. The trade is programming time and a slower cycle, so it pays off on geometry that genuinely needs it.

• 1
  3-axisFlat faces, pockets, plates, drilled holes.
• 2
  4-axisShafts and multi-face parts in one setup.
• 3
  5-axisCurved surfaces, undercuts, deep cavities.

Aluminum cuts fast and holds tight tolerance when the tool is sharp. Grades like 6061 and 7075 machine cleanly, but 7075 is more abrasive and wears edges sooner. Thin walls in aluminum deflect under cutting force, so light passes and a support fixture are more useful than a heavier cut.

Stainless steel and titanium push back. They work-harden if the tool rubs, and they hold heat near the edge. Sharp tools, a positive rake, and a steady feed keep the cut under the hardened layer. Titanium also burns, so coolant flow and chip evacuation need attention. Inconel is slower still and often needs lower surface speed and more passes.

Plastics and composites behave differently. ABS and POM cut cleanly but melt if the feed is too slow. Carbon fiber is abrasive and dulls edges quickly, so coated tools and dust extraction are needed. Every material sets its own window for speed, feed, and depth of cut, and the precision CNC cutting solution has to respect that window rather than force a single recipe.

The ±0.005 mm figure is a machine and process capability, not a promise on every feature. It applies to features that can be reached with a stiff setup and measured reliably. A deep bore or a thin rib will not hold that closely because deflection and vibration grow with the aspect ratio.

Surface finish comes from the tool edge, the feed per tooth, and the rigidity of the setup. A sharp tool at a fine feed leaves Ra 0.8–1.6 μm on most metals. Polishing, bead blasting, or tumbling push it finer or change the texture. A mirror finish on a curved surface often needs a five-axis pass followed by hand polishing.

Measurement closes the loop. A cut part is checked against the drawing, and the difference tells you whether the process drifted. Raw material checks, in-process monitoring, and final inspection catch drift before it becomes a rejected lot. Reports are available on request so the buyer can see the numbers.
