Granite is an igneous rock, so it is heterogeneous at the crystal scale. Quartz, feldspar, and mica sit next to each other with different hardness. A diamond tool does not cut a smooth homogeneous chip. It fractures individual crystals and pulls out weaker grains. Surface finish therefore depends less on spindle speed than on grain size and binder wear.

The practical consequence is that precision CNC granite cutting is a controlled grinding operation, not a milling operation. Tools are diamond-impregnated or diamond-coated, and they remove material by abrasion. Heat goes into the tool and the stone, not into a chip. If coolant flow stops for even a few seconds, the diamond binder can glaze and the cut quality drops immediately.

Granite also has no plastic deformation zone. Metals bend before they break, which gives a machinist warning. Stone fails in a brittle mode. A small change in feed rate can move the process from steady grinding to edge chipping, and the part may still measure correctly on the outside while the subsurface is cracked.

This is why shops that quote granite like aluminium usually lose money on the first article. The setup, the wheel selection, and the inspection plan all have to be built around brittle fracture.

Metrology granite is graded by flatness and straightness, not by color. DIN 876 and ISO 8512-1 define the common grades. Grade A, AA, and AAA plates differ mainly in allowed deviation over a given length. A surface plate for a general workshop might be grade A. A plate that carries a laser interferometer or a CMM reference usually needs grade AA or better.

Grain size matters as much as grade. Fine-grained black granite is dense and closed, so it takes a better polish and holds a sharper edge. Coarser gray or pink stone is cheaper and still stable, but it chips more readily on thin ribs and small holes. For a part with a 3 mm wall, fine-grained stone is the safer choice.

Porosity is the third variable. Natural stone can contain sealed micro-cracks and voids. A void near a mounting hole may only show up after the part is loaded and bolted. Good suppliers inspect the raw block before cutting, and they reject blocks with visible inclusions on the finished faces.

There is no standard granite alloy. Two blocks from the same quarry can behave differently. That is why a first-article inspection on the actual stone matters more here than in metal work.

For most precision parts we work in fine-grained black granite. It is the grade that holds ±0.005 mm over a 500 mm face most reliably.

Diamond is the only practical abrasive for granite at production rates. Two families dominate. Metal-bond diamond wheels last longest and suit heavy stock removal. Resin-bond wheels cut cooler and give a finer finish, but they wear faster and need more frequent dressing. Vitrified bond sits between them for form grinding.

Coolant is not optional. Water-based coolant at 8–12 L/min per cutting zone keeps the diamond binder below its breakdown temperature and flushes the stone dust out of the kerf. Stone dust is abrasive, and if it recirculates it acts like a lapping compound on the machine ways. Filtration to 5 μm or better is normal.

Feed and depth of cut are set by grit size. A 100–120 grit wheel might take 0.10–0.25 mm radial depth per pass at 1,500–3,000 mm/min on a CNC router. A 400–600 grit finishing wheel takes 0.01–0.03 mm per pass. Pushing a fine wheel too hard glazes the bond and burns the surface.

Spindle speed follows wheel diameter. A Ø100 mm wheel running at 2,500 rpm gives roughly 785 m/min surface speed, which is a reasonable starting point for granite. Go much higher and the bond wears too fast. Go much lower and the wheel rubs instead of cutting.

Dressing keeps the wheel open. A glazed wheel looks polished and cuts hot. Dressing with an alumina stick every 20–40 minutes of contact time restores the bite.

Granite parts are usually large and heavy. A 1,000 × 600 × 200 mm plate can weigh 300 kg or more. The machine needs the travel and the table capacity to carry it without deflection. On our larger 5-axis centers the working envelope reaches 4,000 × 400 × 150 mm, which covers most metrology frames and machine bed segments.

Workholding is a common failure point. Clamping a brittle plate with point loads cracks it. Soft jaws, vacuum chucks, or a bed of wax and shims spread the force. For thin sections we support the underside across the full footprint. If the part rings when tapped, it is not supported.

Thermal drift matters because granite has a low coefficient of thermal expansion, around 6–8 × 10⁻⁶ /°C. That is lower than steel, but it is not zero. A 20 °C shop swing over an 800 mm part moves the dimension by roughly 0.1 mm if the part is not soaked. Let the stone stabilize in the shop for several hours before the finishing pass.

Vibration is the other enemy. Granite damps vibration well once it is a finished part, but during cutting a loose setup will chatter. Chatter shows up as a wavy surface and a fast-wearing wheel. Reducing depth of cut and increasing coolant flow usually fixes it.

Granite cannot be checked with a caliper alone. Flatness needs an autocollimator, a laser interferometer, or a repeat-reading with a high-grade reference plate. Straightness on a long edge needs a granite square and a dial indicator, or a laser over the full length.

Hole position and edge quality are separate checks. A hole can be on position and still have a chipped entry. We inspect chamfers and edges under magnification because a chip that is 0.3 mm deep can later propagate into a crack under load.

Subsurface damage is the hard one. Grinding leaves a damaged layer that can be 20–100 μm deep depending on grit. For critical optical or metrology faces, a light etch or a finishing pass with a finer wheel removes it. The final pass should be small, 0.01–0.03 mm, and with a fresh-dressed wheel.

Documentation should list the grade, the measured flatness, the parallelism, the surface finish in Ra, and the hole positions. We record these on the inspection report for every granite part and send reports on request.

If your drawing gives only a tolerance and no datum scheme, the measurement will be ambiguous. Define the datums on the drawing before the first cut.
