Milling is subtractive. A cutter follows toolpaths and removes material from a solid block until the geometry matches the model. Assembly starts where milling stops. Two or more milled parts meet at mating faces, dowels, bores or threads, and the question shifts from single-part accuracy to how errors accumulate across those interfaces.

That is the core of precision CNC milling assembly. It is not one operation. It is a chain: part geometry, datum choice, setup count, fixture stiffness, surface finish, and finally the joining method. Weakness anywhere shows up as runout, misalignment or a shim stack nobody planned for.

A common misconception is that tight individual tolerances guarantee a tight assembly. They do not. Ten parts at ±0.05 mm can stack to ±0.15 mm or worse at the far end of a bolt circle. The tolerance that matters is the one on the assembly drawing, not the one on each detail print.

So the first engineering question is not "how tight can you mill this?" It is "which dimensions close the loop?" Identify the closing dimensions, then decide where to spend tolerance and where to leave it loose.

• 1
  Single part toleranceThe ±0.005 mm figure applies to a controlled feature on a single part.
• 2
  Assembly toleranceThe sum of several part errors plus joining clearance.
• 3
  Datum transferEvery re-setup adds a small positional shift that feeds the stack.

Each time a part leaves the vise and returns, the machine must find it again. Re-clamping error is usually 0.01 to 0.03 mm on a good three-axis setup. On a rough fixture it can exceed 0.05 mm. If a bearing bore and a mounting face are machined in two setups, that error lands directly in the assembly stack.

Five-axis machining removes most of that risk. With 16 simultaneous 5-axis centers we can reach five sides of a part in one clamping, so bores, faces and dowel holes that share a functional relationship are cut in the same coordinate frame. The rotary table is Ø400 mm, which covers most manifold, housing and bracket work.

The limit is reach and rigidity, not axis count. A 4,000 × 400 × 150 mm travel machine handles long extrusions, but a thin wall at the far end of that travel will deflect under cutter load. Long parts sometimes need support fixtures or a second setup regardless of axis count.

Practical rule: if two features must line up during assembly, try to cut them in one setup. If you cannot, plan an in-process check between setups instead of trusting the fixture.

• 1
  One setupBest for bores, faces and dowel holes that share a datum.
• 2
  Two setupsAcceptable when the interface has clearance or a floating fastener.
• 3
  Three or moreUsually a sign the part should be redesigned or split differently.

Worst-case stack-up adds the tolerances in a chain. Statistical stack-up assumes errors distribute and uses the root sum square. Real assemblies sit between the two. Machined features tend to be biased by tool wear and thermal drift, so they are not perfectly random, which pushes results toward the worst-case end.

Take a three-part bracket: a base plate, a riser and a cap. If each has a ±0.05 mm position tolerance on its mating holes, the worst case is ±0.15 mm at the cap. Add 0.1 mm of clearance in the bolt holes and the assembly still bolts up. Remove that clearance and the parts must be reamed in place.

This is where surface finish matters more than people expect. A face milled at Ra 1.6–3.2 μm has visible scallops. Two such faces bolted together touch on the high spots, so the joint is less stiff than the drawing suggests. For a bearing seat or a sealed joint, specify Ra 0.8–1.6 μm, and Ra 0.2–0.8 μm where a seal lip or an O-ring groove is involved.

Flatness is the other quiet variable. A face that is flat to 0.02 mm over 100 mm will pull the mating part into shape when bolted, and that distortion can close a bore by several micrometers. Check flatness on the assembly drawing, not just on the detail print.

• 1
  Worst caseAdd every tolerance in the chain. Use for safety-critical joints.
• 2
  RSSRoot sum square. Use only when processes are truly centered.
• 3
  ClearanceFloating fasteners absorb stack-up. Dowels do not.

Aluminium 6061-T6 and 7075 machine cleanly and hold ±0.005 mm on well-supported features. They also move with temperature. A 300 mm aluminium part grows about 0.07 mm over a 20 °C shift. If the mating part is steel, that difference shows up as a changing fit between a cold morning and a warm afternoon.

Stainless 304 and 316L resist corrosion but work-harden. Deep pockets and thin ribs need light radial cuts. 17-4PH (SUS630) is the better choice when you need strength plus corrosion resistance in a milled housing. Titanium Ti-6Al-4V cuts at roughly one third the speed of aluminium and needs sharp tooling and flood coolant.

Finishes change dimensions. Anodizing adds roughly 5 to 15 μm per surface depending on type. Hardcoat can add more. If a bore is anodized after machining, the bore shrinks. Either mask the bore, or cut it undersize by the coating thickness. The same logic applies to electroless nickel and zinc plating.

For assemblies with sliding fits, plan the finish before you set the tolerance. A ±0.005 mm bore that gains 10 μm of coating is no longer a ±0.005 mm bore.

• 1
  AluminiumFast to cut, thermally active. Good for housings and brackets.
• 2
  StainlessCorrosion resistant, work-hardens. Keep radial engagement low.
• 3
  Coating offsetMask functional bores or compensate before plating.

Bolted joints are the default. They are serviceable, they tolerate stack-up through clearance holes, and they can be preloaded. The catch is that bolt preload depends on friction and torque control. A joint that relies on friction to resist shear will slip if the surfaces are smooth and the preload is low. Add dowel pins when shear location matters.

Press fits transfer load through interference. A typical light press in aluminium is 0.02 to 0.04 mm on a 20 mm bore. Heavy press fits in aluminium risk galling and can crack a thin wall. For assemblies that must come apart, use a transition fit and a retaining compound instead.

Adhesive bonding spreads load over an area and avoids holes, which is useful on thin panels. It needs a clean, roughened surface and a controlled bond-line gap of roughly 0.1 to 0.2 mm. Bead blasting before bonding improves peel strength measurably.

Welding is the stiffest option and the hardest to keep precise. Heat distorts the part, so weld-then-machine is the normal order. If the drawing calls for a welded frame held to ±0.05 mm, expect to machine the critical faces after welding, not before.

• 1
  Bolted plus dowelsBest when location and serviceability both matter.
• 2
  Press fitGood for permanent joints with thick surrounding walls.
• 3
  Weld then machineThe only reliable route to tight welded assemblies.
