A milling machine spins a multi-tooth cutter and moves it through metal along controlled axes. Each tooth takes a small chip. The surface you get is the sum of many overlapping cuts, so the finish depends less on the operator's hand and more on feed per tooth, spindle speed, and how rigidly the part is held.

Remove too little per tooth and the tool rubs instead of cutting. Rub a 6061 aluminium wall at the wrong feed and it work-hardens, then tears. Remove too much and the tool deflects, leaving a taper the inspector will find. The window is narrow on thin walls and wide on chunky blocks.

That is the whole story behind precision. A tolerance of ±0.005 mm (±0.0002 in) is not a magic number the machine prints on every part. It is a result of cutting force, tool runout, thermal drift over the run, and how the fixture resists the push. Change one and the others move.

So when a shop promises tight numbers, the real question is which of those four it controls. Spindle and ballscrew accuracy are bought with the machine. Fixture stiffness and thermal control are earned per job. That second half is where quotes quietly differ.

Every time a part moves to a new fixture, you re-establish a datum. Each re-clamp adds a small positional error, and errors stack. A part machined in five setups is not five times less accurate than one machined in a single setup, but it is measurably worse, and the scrap rate climbs with each move.

This is the practical case for 5-axis work. On a simultaneous 5-axis center the tool reaches five faces without the operator touching the part. Datum stays put. Holes drilled on two perpendicular faces stay perpendicular to each other because they came from one coordinate system, not two.

The trade-off is cost and programming time. Five-axis toolpaths take longer to prove out, and a simple bracket with three drilled holes does not need them. Put your budget where the geometry actually demands it.

A useful test: count the faces that carry toleranced features. One or two faces, 3-axis is fine. Features on four or five sides, or a compound angle, and 5-axis pays for itself in scrap you never make.

Aluminium 6061-T6 machines fast and holds tolerance well, which is why it dominates prototypes and fixture plates. 7075 is stronger but gummier and springs back more on thin ribs. On a 0.8 mm wall, 7075 will move after you release the vise.

Stainless 304 work-hardens the moment the tool rubs. You have to keep the chip load up and never let the cutter dwell. 17-4PH in the H900 condition is harder again and often needs a pre-machined soft state followed by heat treat, which adds a step and a re-datum.

Titanium Ti-6Al-4V conducts heat poorly, so the heat stays in the cutting edge. Tool life drops, spindle time rises, and the cost follows. Inconel is worse still and usually belongs on a 5-axis center where one setup limits the number of times you re-enter a hard cut.

Plastics are a different problem. POM and PEEK move with temperature and clamp pressure, so a part measured in the vise is not the part measured on the bench. For those, we machine, let the part rest, and inspect after it stabilizes.

Surface finish and dimensional tolerance are not independent. A Ra 0.8–1.6 μm finish usually comes from a finishing pass with a small radial cut. That pass also corrects the deflection left by the roughing pass, so tighter finish often means tighter size, not just a prettier surface.

Ra 1.6–3.2 μm is a normal as-machined result and is perfectly fine for brackets, housings, and most internal parts. Asking for Ra 0.2–0.8 μm on a non-sealing face adds cost and time for a surface nothing touches.

Where the two do diverge is on sealing faces and bearing bores. There, finish drives function: a rough bore wears a shaft faster, and a polished one may not hold lubricant. Tell us what the surface does and we can pick the pass.

Anodizing and plating add a layer, typically 5–25 μm depending on the process. If a bore is toleranced before coating, it will be undersized after. Flag coated surfaces on the drawing so we can adjust the pre-plate dimension.

Milling removes material from a solid block. If your part is a thin-walled enclosure with uniform 1.5 mm walls in a 300 mm box, you will cut away most of what you bought, and the part will distort. Sheet metal fabrication or die casting serves that shape better.

Very high volumes push the same way. Milling has no tooling cost but a higher per-part cost. Past a few thousand identical parts, a casting or a progressive die usually wins on unit price, even after the tooling bill.

Deep small holes, long slender bores, and parts that are essentially rotational belong on a lathe or a mill-turn center. A 16 mm bore at 8× depth in stainless is a drilling and boring job, not a milling job.

None of this is a defect of milling. It is a boundary. Knowing where the boundary sits is what keeps a quote honest, and it is the fastest way to tell whether a supplier is listening to your drawing.
