Precision CNC parts are metal or plastic components cut from solid stock by a computer-controlled machine that follows G-code. The tool path, spindle speed and feed are fixed in the program, so the same geometry repeats part after part. The word precision refers to how tightly the finished dimensions hold to the drawing.

A tolerance of ±0.005 mm means a 20 mm bore may measure anywhere from 19.995 to 20.005 mm. That band is roughly one fifteenth the width of a human hair. Achieving it is not a matter of a better machine alone. Fixturing, tool wear, thermal drift and how the part is held all move the result.

Precision parts appear where failure is expensive: jet engine brackets, surgical instrument bodies, optical housings, robot joints and EV drivetrain components. In those places a loose fit is not a cosmetic defect. It becomes noise, leakage, vibration or a fracture that starts at a stress riser.

The sections below walk through the decisions that decide whether a design machines cleanly: tolerance stack, axis count, material behavior, surface finish and inspection method. Each one is a lever you can pull before the first chip is cut.

Tolerance is a budget, not a wish. Every feature on a part spends part of it. If a bore carries ±0.005 mm and the bolt pattern that locates it carries ±0.1 mm, the assembly may still fail because the two features move relative to each other. Engineers who model the stack before release catch this on screen instead of on the bench.

The physical sources of error are few and predictable. Spindle runout, thermal growth over a long cycle, tool deflection on deep pockets, and re-clamping error when a part moves between setups. A single-setup 5-axis cut removes the last one entirely, which is why it often holds tighter than a three-setup sequence on the same machine.

Thin walls are the classic failure point. A 0.5 mm wall on a 60 mm aluminum pocket will deflect under cutting force no matter how sharp the tool is. Adding a temporary rib, reducing depth of cut to 0.2 mm per pass, or switching to a smaller diameter cutter usually saves the part. Chasing the same wall with a heavier pass does not.

It also pays to ask which dimensions actually matter. A ±0.005 mm callout on a non-functional cosmetic edge adds cost and inspection time for nothing. Reserve the tight band for fits, sealing faces, bearing seats and datums.

• 1
  Stack firstAdd up feature tolerances before release, not after a failed build.
• 2
  Fewer setupsEach re-clamp adds positional error that no machine can remove.
• 3
  Tight only where neededCosmetic edges rarely justify a ±0.005 mm band.

A three-axis mill moves the tool in X, Y and Z. The workpiece stays put. That works well for prismatic parts with features reachable from one direction. Add a fourth axis, usually a rotary table, and the part can index to new faces without leaving the fixture. Our shop runs 12 four-axis mills and a Ø400 mm rotary table for that middle ground.

Five-axis machining adds two rotary axes, typically A and B, so the tool can approach the workpiece from almost any angle in one setup. Contoured surfaces, undercuts, angled holes and deep pockets with sculpted floors stop being special cases. We run 16 simultaneous five-axis machining centers for exactly this class of work.

The payoff is not only geometric freedom. Fewer setups mean fewer datum transfers, which means the tolerance stack stays short. A part that needed four operations on three-axis machines may finish in two on a five-axis center, with the sealing face and the bore machined in the same coordinate frame.

It is not always the right choice. Simple plates, shafts and brackets machine faster and cheaper on three-axis or mill-turn equipment. Five-axis earns its cost when the geometry is genuinely complex or when setup error is the dominant risk. For a 4,000 mm long extrusion with one angled face, a large three-axis machine with a tilting head is the better answer.

Aluminum 6061 and 7075 cut freely and hold ±0.005 mm without drama. They also move after machining if residual stress is high in the stock. For thin, long parts we rough, stress-relieve, then finish. Skipping that step is the most common reason a straight part arrives bowed.

Stainless 304 and 316 work-harden the moment the tool rubs instead of cuts. Feed rates must stay above a floor, usually around 0.05 mm per tooth, so the edge bites under the hardened layer. A light finishing pass with a dull tool will glaze the surface and ruin the next pass.

Titanium Ti-6Al-4V and Inconel 718 sit at the other end. Low thermal conductivity means heat goes into the edge, not the chip. Tool life drops, so roughing passes are conservative and coolant delivery matters more than raw speed. These alloys are machinable to ±0.005 mm, but the cycle is slower and the tooling cost is real.

Plastics and composites bring their own rules. PEEK and POM need sharp, polished flutes and high spindle speeds to avoid melting. Carbon fiber eats carbide, so diamond-coated tooling pays for itself. Magnesium AZ31B and AZ91D machine fast but demand chip control and fire-safe handling.

• 1
  AluminumFast and stable, but stress-relieve long thin parts.
• 2
  StainlessKeep feed above the work-hardening floor.
• 3
  Titanium and InconelHeat is the enemy; tool life drives the plan.
• 4
  PlasticsSharp flutes and high speed prevent melting.

Ra is the average roughness of a surface, measured in micrometers. As-machined surfaces sit around Ra 1.6–3.2 μm. A high-quality finish reaches Ra 0.8–1.6 μm with a controlled finishing pass. Fine finishes go to Ra 0.2–0.8 μm and usually need a dedicated operation or a secondary process.

Finish and tolerance interact. A sealing face may need both a tight flatness band and a low Ra, because a rough surface leaks past a gasket even when the dimensions are correct. A bearing seat needs roundness and a smooth bore so the race seats without fretting.

Secondary processes change the picture. Anodizing adds a thin oxide layer, typically a few micrometers, which shifts dimensions on tight features. Hardcoat anodizing adds more. If a bore carries ±0.005 mm and will be anodized, the shop needs to know before machining so the pre-plate size is set correctly.

Bead blasting, tumbling and brushing even out tool marks but can round edges. Laser marking needs a minimum character height of 1.5 mm to stay legible. Each of these steps should be listed on the drawing, not decided after the part is cut.

A tight tolerance is a claim until it is measured. Inspection starts with the raw material certificate, because a wrong alloy can machine perfectly and still fail in service. In-process checks catch drift while the part is still in the fixture, when a correction is cheap.

Final inspection confirms the drawing before the part leaves the shop. We inspect 100% of parts before shipment and provide reports on request. CMM data, roundness traces and surface roughness readings can all be supplied when the drawing calls for them.

First article inspection matters on new designs. It confirms that the process, the fixture and the program produce the intended geometry before a full run. Catching a datum error at article one costs far less than scrapping a batch.

Our quality system is built on ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022. That last one covers information security, which matters when customer drawings and CAD files pass through the shop.
