Metal cuts by shear. Plastic cuts by a mix of shear and fracture, and the balance shifts with every material. Acrylic and polycarbonate crack ahead of the tool edge. POM and PA cut cleanly but spring back against the flank. PEEK needs sharp edges and enough spindle speed to keep the chip thin. Same machine, same fixture, different rules.

Heat is the first constraint. Polymers conduct heat poorly, so the heat a cutter generates stays near the cut instead of leaving through the chip. Above the glass transition temperature the surface smears, and a smear cannot be polished out. Below it, the material may chip instead. The usable window sits between those two failures.

Elastic recovery is the second. A machined wall springs back after the tool passes, so the finished dimension lands slightly over the programmed one. On a thin rib that rebound can reach several hundredths of a millimeter. We measure it on a test cut before running the batch.

Stiffness is the third. Plastics run from about 1 GPa to 20 GPa in modulus, roughly one tenth to one third of aluminum. Light finishing passes and low radial engagement keep deflection small enough that the tolerance holds.

Tolerance is a property of the material as much as the machine. Amorphous plastics such as ABS, PC and PMMA soften gradually, so a heavy cut leaves a gummy edge. Semicrystalline grades such as POM, PA, PP and PEEK hold a sharper edge but move more with temperature and moisture.

POM is the usual first choice for tight work. It machines fast, holds ±0.01 mm on a stable part, and resists moisture. PEEK takes higher cutting temperatures and holds similar accuracy, but the raw stock costs far more, so the design should justify it.

PA is the material that surprises people. It absorbs moisture from the air and grows. A dry nylon part measured on the bench may be a different size in a humid warehouse a week later. For anything with a fit, we machine from conditioned stock and note the condition on the drawing.

Carbon-filled grades behave differently again. The fibers raise stiffness and cut abrasion resistance on the tool, so the edge dulls faster and the surface finish drops over a long run. We change cutters on a count rather than on a schedule.

Tooling for plastics looks like tooling for aluminum and behaves like tooling for nothing else. Two flutes, a high helix, and a sharp rake give the chip somewhere to go. A router-style cutter with a polished flute reduces the rubbing that turns into heat.

Spindle speed sits high, usually 10,000 to 24,000 rpm on small cutters, with chipload kept light. Depth of cut can be generous because the material cuts easily; stepover should stay low on thin walls. Air blast is normally enough to clear chips. Flood coolant on a hygroscopic grade can leave it wet and dimensionally unstable, so we use air or a mist.

Sharp edges matter more than coating. A worn edge rubs the surface, raises local temperature, and leaves a white stress mark on transparent plastics. On PMMA and PC we keep a separate set of cutters and inspect the edge every few hours.

For holes and pockets, climb milling gives a cleaner wall on most polymers. Conventional milling can leave a torn edge on the exit side. The difference is visible under low magnification and shows up later as a crack origin.

A plastic blank is soft, so the fixture can do more damage than the cutter. Hard jaws leave impressions and can bow a part before the cut even starts. We use soft jaws machined to the blank profile, or a vacuum plate for thin sheet, so the clamping load spreads over a wide area.

Machining removes material that was holding the part in balance. A pocketed block or a long thin plate will move as the internal stress redistributes. The fix is sequencing: rough all faces first, let the part rest, then take finishing passes that remove only a few hundredths of a millimeter.

Thin walls need support, not pressure. Support the back of a 1 mm wall with a sacrificial backing plate or a potting compound, then remove the support after machining. Free-standing thin walls will chatter and no amount of speed reduction fixes it.

Deburring is part of the process. A sharp edge on a machined plastic part is a crack starter. We break edges with a controlled chamfer or a light bead blast rather than a hand scrape, so the geometry stays repeatable.

Design rules for machined plastics follow the tool. Inside corners need a radius at least equal to the cutter radius, because a square internal corner requires a cutter that cannot exist. A 1 mm corner radius is a reasonable default; 0.5 mm is possible but needs a small cutter and slower feed.

Bosses and ribs should be thicker than the wall they sit on, and generous fillets at the base spread the load. Sharp internal corners concentrate stress in service as well as in machining. Threads below M3 are fragile in most polymers; a molded insert or a metal insert is often the better answer.

Deep pockets are limited by tool reach. A pocket 5 mm wide and 30 mm deep needs a long, thin cutter that will deflect. Beyond about 4:1 depth to diameter, accuracy drops and the surface finish suffers. Splitting the part or opening the pocket may cost less than chasing the tolerance.

Molding takes over when volume justifies a tool. The crossover depends on geometry and material, not on a fixed number. We quote both paths when a design sits near that line. Below the crossover, machining wins on lead time and on the freedom to change the design between runs.

A plastic part can be measured wrong. Touch probes and calipers apply pressure, and a soft material deflects under the gauge. A reading that looks good on the bench may not match the same part measured with a light touch or an optical system.

For tight features we use optical measurement and non-contact scanning where the geometry allows it, and agree on the method before the first article. Contact measurement stays in the plan for hard grades such as PEEK and filled materials, where deflection is small.

Temperature and time matter too. A part measured straight off the machine is often warmer than the inspection room. We let parts stabilize before final inspection so the number recorded matches the number the customer will see.

Every shipment leaves with 100% inspection and reports on request. Raw material certificates, in-process checks and a final dimensional report can be bundled with the parts when the program calls for it.
