A precision CNC service is judged by what it can hold on your part, not by the tightest number in its brochure. ±0.005 mm (about ±0.0002 in) is achievable on rigid features with a short tool reach, stable fixturing and temperature control. The same shop will hold something looser on a 4,000 mm long extrusion or a 0.8 mm thin wall, because tool deflection and thermal drift dominate at that scale.

So when a supplier quotes a single tolerance for the whole drawing, ask which features it applies to. A machined bore, a face, a slot and a bolt pattern each carry different risk. A flat face is easy. A deep bore with a 10:1 length-to-diameter ratio is not, and it will need a boring head, a reamer or a second setup.

Tolerance also drives cost in steps, not in a straight line. Moving from ±0.050 mm to ±0.025 mm is usually a process tweak. Moving to ±0.005 mm can force slower feeds, more in-process checks and possibly a finish pass. That is why two quotes on the same drawing can differ by 40% and both be honest.

A useful test: send one part with three critical features marked and the rest left general. Ask the shop to explain how each critical feature will be reached and measured. The reply tells you more than the price line.

• 1
  Mark critical featuresTwo or three per part, not twenty.
• 2
  State the datumInspection follows the datum, not the drawing view.
• 3
  Note the materialAluminium 6061 and 17-4PH behave very differently.

CNC machining fits metal parts with defined geometry, moderate to tight tolerances and a need for repeatability. Housings, brackets, manifolds, impellers, heat sinks, medical instrument bodies and EV busbar components all land here. If your part has pockets, threads, cross-holes or a sealing face, subtractive machining is usually the shortest route.

It is a poor fit for parts that are mostly thin sheet, for very high volumes of a simple shape, and for hollow forms with no machining access. Those belong in sheet metal fabrication, die casting or vacuum casting. A shop that tells you this is being useful, not turning down work.

Part size sets the machine class. Small parts under 500 × 500 × 450 mm run well on compact 5-axis centers. Mid-size parts fit the 750 × 1,150 × 550 mm and 600 × 600 × 600 mm travels. Long parts need the 4,000 × 400 × 150 mm envelope, and that class of machine is far less common.

Count your setups before you count the price. A part that needs four sides machined is a four-setup job on a 3-axis mill, with four chances for position error. The same part on a simultaneous 5-axis center can often be done in one or two setups, which lifts accuracy and cuts handling time. That is the real argument for 5-axis, not the machine count.

Ask what happens between the last cut and the shipping box. A workable answer names three stages: raw material check, in-process monitoring, and final inspection before shipment. Every part is inspected, and dimensional reports are available on request. If a shop only offers a visual check, you will find the problem at your own incoming inspection.

Certification is a filter, not a ranking. ISO 9001:2015 covers general quality systems and is the baseline for most industrial buyers. IATF 16949:2016 is what automotive and EV programs expect. ISO 13485:2016 applies to medical devices. ISO 27001:2022 matters when your drawings and CAD data are sensitive. Match the certificate to your industry instead of collecting all four.

Confidentiality is part of the same conversation. Uploads should be secure, and an NDA should be available on request before you transfer CAD. For defense, medical and consumer electronics work, this is often the first document exchanged, not the last.

Material traceability closes the loop. If your part is 316L for a corrosive line or 17-4PH for a stressed joint, the mill certificate should follow the parts. Ask for it up front, because pulling it later is slow.

• 1
  Three inspection stagesIncoming, in-process, final.
• 2
  Reports on requestSay the format you need in the RFQ.
• 3
  NDA before CADCheaper than a dispute after.

A quote that arrives without DFM notes is incomplete. The useful reply points out a wall that is too thin, a corner radius smaller than the cutter, or a tolerance that needs a second operation. Quotation and DFM analysis within 12 hours is a realistic benchmark, and production can start within 24 hours once the drawing and material are confirmed.

Read the lead time as two numbers: when the material is cut, and when the parts ship. Parts shipping in 3–5 days is normal for small and mid-size runs in common alloys. A rare titanium grade or a hardcoat finish adds calendar time that no shop can compress.

MOQ is where prototypes die. If the supplier wants 500 pieces to start, your design iteration stalls. No minimum order quantity, from one prototype to 10,000+ part runs, is the right shape for engineering work. It also means the first article and the production run come off the same process.

Watch for the finish clause. Anodizing, electroless nickel, powder coating and laser marking are separate operations, each with its own setup and its own lead time. A quote that lists machining only will grow later. Ask for the finish to be included or priced as a clear line item.

Aluminium 6061-T6, 7075 and 6082 cut fast and hold tight tolerances well, which makes them the default for prototype housings and fixtures. Stainless 303 and 304 machine cleanly; 316L and 17-4PH are tougher on tooling and need more attention to work hardening. Titanium TC4 (Ti-6Al-4V) and Inconel take longer, and the quote should reflect that.

Copper and brass are common in busbars and RF parts. C110 and C36000 machine well; beryllium copper needs a controlled process because of the dust. Magnesium AZ31B and AZ91D are light but require chip handling rules that not every shop has in place.

Finish choice often decides whether the part passes or fails in service. Anodizing gives wear resistance and color, hardcoat adds thickness and hardness, and conductive anodizing keeps electrical contact. Electroless nickel holds a uniform layer on complex geometry, which is why it shows up on valve bodies and instrument housings.

For sealing faces and bearing bores, call out the finish in Ra on the drawing. Ra 1.6–3.2 μm is a normal as-machined face, Ra 0.8–1.6 μm is a fine machined face, and Ra 0.2–0.8 μm needs a dedicated finishing pass. Leaving the value off invites a guess that costs you a rework loop.
