Pure copper sits near the top of the thermal conductivity table for common metals. Heat generated at the shear zone leaves through the chip, but a large share also travels back into the tool and the workpiece. The chip comes off cool enough to touch while the insert tip is running several hundred degrees hotter than it would in steel. That inverted heat balance is the root of most copper machining trouble.

The second mechanism is adhesion. Copper has no stable surface oxide at cutting temperature, and it is soft in the annealed condition. Where the chip slides across the rake face under high pressure and temperature, copper grains cold-weld to the carbide. The build-up edge that forms is not stable. It grows, breaks off, and takes tool substrate with it, which shows up on the part as a torn or smeared surface.

The third mechanism is thermal softening of the workpiece itself. Because heat is not concentrated at the cut, the material ahead of the edge stays soft and deforms plastically instead of shearing cleanly. On a finishing pass this produces smeared material rather than a cut surface, and burrs form where the edge exits the part. All three mechanisms point the same direction: raise cutting speed, keep the tool sharp, and remove heat before it reaches the part.

One more thing worth knowing: copper work-hardens little compared with stainless, but it galls badly against uncoated steel. That is why a tool that ran 200 parts in aluminium can fail in 20 parts in copper without any change in parameters.

• 1
  Heat pathHigh conductivity sends heat into tool and part, not into the chip.
• 2
  AdhesionNo oxide layer means copper cold-welds to carbide under pressure.
• 3
  Soft stockThermal softening causes smearing instead of clean shear.
• 4
  GallingUncoated steel tooling is the worst pairing for copper.

C101 and C110 are oxygen-free and high-conductivity coppers, roughly 99.9 percent pure. They give the best electrical and thermal performance and machine the worst. Stringy chips wrap around the tool, built-up edge forms quickly, and surface finish is hard to hold below Ra 1.6 μm without polishing. Use them when conductivity is the point of the part, such as busbars, RF cavities, waveguides, and heat spreaders.

C103 and C110 with a small silver or oxygen addition cut a little better, but the difference is small. Beryllium copper, usually C17200, is the other end of the range. It machines closer to a hard bronze, holds tight tolerance well, and takes a fine finish. It is also expensive, and beryllium dust requires specific shop controls, so it is normally reserved for spring contacts, diaphragms, and tooling inserts where hardness or fatigue life matters.

Brasses are not copper, but they appear in the same conversations. C36000 free-cutting brass machines easily and holds ±0.005 mm without drama, which is why it dominates fittings and connectors. C27400 and C28000 are stronger and more corrosion-resistant but gummier. If a drawing says copper and the function allows brass, saying so early saves both cost and lead time.

A practical rule: choose the grade from the function first, then ask whether the shop can hold tolerance on it. If the answer is no on a pure copper part, the fix is usually geometry or a secondary operation, not a different grade.

• 1
  C101 / C110Best conductivity, worst machinability, stringy chips.
• 2
  Beryllium copperMachines well, holds tolerance, needs dust controls.
• 3
  C36000 brassEasy to cut, good for fittings, lower conductivity.
• 4
  C27400 / C28000Stronger and more corrosion-resistant, gummier to cut.

Speed is the first lever. Copper wants higher surface speed than steel, often 150 to 300 m/min with carbide, because a fast, thin chip carries heat away and spends less time welding to the rake face. Feed per tooth stays moderate, around 0.05 to 0.15 mm for finishing, so the edge cuts rather than rubs. Too light a feed is a common mistake: the tool skates, work-hardens the surface, and the next pass cuts through a harder skin.

Coolant matters more than in steel. High-pressure through-tool coolant flushes chips out of deep pockets and keeps the part near room temperature, which protects thin walls from growing. For pure copper, a water-soluble flood coolant works well. For beryllium copper, coolant is not optional; it controls dust and keeps the operation safe.

Tool geometry does most of the remaining work. Polished rake faces, high positive rake angles, and a sharp edge radius reduce adhesion. Diamond-coated carbide and PCD tooling last far longer in pure copper than uncoated grades, and they hold the edge radius that keeps a built-up edge from forming. On a mill-turn or five-axis machine, cutting the part in one setup removes the re-clamping that dents soft copper.

Burrs are handled by geometry and by sequence. Chamfer or break edges in the same setup where possible. Where a burr is unavoidable, plan a light finishing pass or a vibratory tumbling step rather than scraping it off by hand, which damages the surface.

• 1
  Surface speed150–300 m/min with carbide in pure copper.
• 2
  Feed per tooth0.05–0.15 mm finishing; avoid rubbing passes.
• 3
  CoolantHigh-pressure through-tool to flush chips and hold size.
• 4
  ToolingPCD or diamond-coated carbide, polished rake face.

Very thin walls are the hardest case. Copper is soft and has low stiffness, so a 0.5 mm wall deflects under normal clamping pressure and sings during milling. The usual fixes are light radial depth of cut, support from sacrificial material, and a finishing pass with a sharp tool. Even then, expect to hold wall thickness rather than to hold a tight flatness callout on an unsupported wall.

Deep holes and small features are the second limit. Copper chips are long and stringy, so they pack into flutes and holes. Peck drilling with full retraction, high-pressure coolant, and a dwell-free retract cycle keep the hole clear. Gun drilling works for deep straight holes, but the tooling is specific and the setup cost only makes sense on a run, not on one part.

Surface finish has a floor. As-machined copper typically lands in Ra 1.6–3.2 μm, and getting to Ra 0.8–1.6 μm requires sharp tooling and a stable setup. Below Ra 0.8 μm, copper usually needs polishing or a chemical finish rather than a better cutter path. If a drawing calls for a mirror finish on a pure copper face, plan the polishing operation into the process from the start.

Cost is the last limit. Copper stock is expensive, and the material removed in a deep pocket is material paid for and thrown away. A near-net shape from casting or a redesign that keeps the wall thickness even will usually beat any machining optimization.

• 1
  Thin wallsLight radial cuts, sharp tools, support material.
• 2
  Deep holesPeck drilling with full retraction and through-tool coolant.
• 3
  Finish floorAs-machined Ra 1.6–3.2 μm; finer needs polishing.
• 4
  Stock costDeep pockets waste expensive copper; redesign first.

Copper tarnishes in air within days, so a finish is often a functional requirement rather than a cosmetic one. Electroless nickel gives a hard, uniform layer over complex geometry and is common on RF housings and busbars. Silver and gold plating protect conductivity at contact surfaces where an oxide layer would raise resistance. All three are available in-house, which keeps the part in one quality system.

For pure appearance, bead blasting and brushing give a matte or directional finish that hides tool marks. Tumbling smooths edges and removes light burrs without touching dimensions. Laser marking works for part numbers and traceability codes, with a minimum character height of 1.5 mm so the mark stays legible on a soft surface.

Anodizing is not a copper process. Copper can be anodized only in specialized baths and the result is not the hard oxide layer people expect from aluminium. If a drawing shows anodizing on a copper part, treat that as an error and confirm the real intent before quoting.

• 1
  Electroless nickelHard, uniform, good for complex RF housings.
• 2
  Silver / gold platingProtects contact resistance at mating surfaces.
• 3
  Bead blasting / brushingCosmetic matte or directional finish.
• 4
  Laser markingPart numbers and traceability, 1.5 mm minimum height.
