Slow-walking wire cut removes material by spark erosion between a moving wire electrode and the workpiece, submerged in deionized water. Nothing touches the part, so the wire never wears against the work the way a milling cutter does. Every discharge vaporizes a small crater. Thousands of discharges per second walk along the wire and cut a slot roughly 0.03 mm wider than the wire itself.

The gap between wire and workpiece is the whole process. If the gap closes, the wire touches the work, current spikes, and the wire burns through. If the gap opens too far, discharges scatter and the surface turns rough. The controller holds that gap by adjusting the pulse off-time, usually written as P. Raising P widens the gap. Lowering P narrows it and speeds the cut, up to the point where flushing can no longer clear the debris.

Debris removal is done by the water. Flush nozzles above and below the workpiece push clean water into the kerf and carry sludge out. When the nozzles are clogged, damaged, or sitting too far from the work, the gap fills with conductive particles and the discharge becomes unstable. Most so-called electrical faults on a wire machine are really flush faults.

Temperature matters more than most operators expect. A 0.25 mm brass wire expands about 0.005 mm over a 20 °C rise across a 300 mm span. That is the same order as the tolerance on many parts. Machines with a temperature-controlled water chiller hold the wire length steady. Machines without one drift through the day, which is why a part cut at 08:00 may not match one cut at 16:00.

• 1
  Gap is the control variablePulse off-time sets the spark gap; everything else reacts to it.
• 2
  Flush is not optionalWeak flushing reads as an electrical fault on the display.
• 3
  Wire length drifts with heatThermal growth shows up directly as a dimensional error.

A wire break mid-cut almost never has a single cause. The machine usually reports an electrical fault, but the trigger is mechanical or hydraulic. Work through the list in order rather than changing five parameters at once, or you will not know which change helped.

Start with discharge status. Reduce P by one or two steps. This narrows the gap and cuts the discharge energy per pulse, which lowers the thermal load on the wire. The trade-off is real: the cut slows and the surface may need a trim pass. That is acceptable when the alternative is a break inside a deep cavity.

Next check the upper and lower flush nozzles. If the veneer or the nozzle face is damaged, water reaches the gap unevenly and the wire heats on one side. Reduce P as well and inspect both nozzles for chips, wear, or a bent face. A nozzle that no longer seals against the work is a nozzle that needs replacing.

Then look at the driver block and the contact pins. A worn driver block lets the wire slip, so the tension reading looks fine while the wire is actually running slack. Slack wire whips in the gap and touches the work. Replace the block at the interval the machine builder lists, not when it finally fails.

Wire tension itself is the fourth check. The compression ratio of the wire path should sit around 1:1.5 to 1:1.6. Outside that band the wire either stretches or binds. Reduce tension when cutting a cone, because a tapered cut pulls the wire sideways and a tight wire snaps. On tall tapers, lower the tension before you lower anything else.

• 1
  Reduce P firstSmaller discharge energy, lower wire temperature, slower cut.
• 2
  Inspect both nozzlesOne blocked nozzle is enough to break a wire in a deep cut.
• 3
  Check the driver blockA worn block hides itself behind a normal tension reading.
• 4
  Tension ratio 1:1.5–1.6Slack wire whips and touches; tight wire snaps on tapers.

Taper error shows up as an angle that measures correctly in the middle of a wall and wrong at the top and bottom edges. The wire cannot bend instantly at the guide, so the machine has to lead and lag the movement. If the lead-in distance is too short, the first few millimeters of the taper come out under-formed.

Corner error has a different origin. On a sharp internal corner, the wire has to change direction while the discharge is still eroding. The result is a rounded corner with a radius roughly equal to the spark gap plus the wire radius. No amount of servo tuning removes it entirely. What you can do is slow the feed near the corner and let the machine dwell, which trades cycle time for a tighter radius.

For parts that need both tight corners and a fine finish, plan a rough pass plus two or three trim passes. The rough pass cuts at high energy and leaves a recast layer. The trim passes remove that layer at low energy with the offset stepped in by 0.02 to 0.05 mm per pass. Skipping trims to save time usually costs more in hand finishing than it saves on the machine.

Choose the process sequence before you choose the settings. Parts with a hardened or pre-treated surface should be roughed before heat treatment and trimmed after. Parts with thin walls should be sequenced so the wire is never cutting a wall that has already lost its support. A reasonable sequence file prevents more scrap than any single parameter change.

• 1
  Lead-in lengthToo short and the taper never fully forms at the entry edge.
• 2
  Corner radiusGap plus wire radius is the physical floor; dwell to reach it.
• 3
  Trim offsetsStep in 0.02–0.05 mm per pass to remove the recast layer.

Flush pressure falls off with the square of the distance from the nozzle to the work. If the nozzle is 1 mm off the surface instead of touching it, you lose a noticeable share of the flow before it reaches the kerf. The fix is mechanical, not electrical: reseat the nozzle, check the O-ring, and confirm the workpiece is flat against the fixture.

Sludge builds up in the tank and the piping. A tank that has not been cleaned in months sends fine conductive particles back through the nozzles and into the gap. The symptom is intermittent instability that comes and goes with no parameter change. Clean the waste bucket on a schedule, and do not let overflowing waste wire sit in the bucket where it can short against the machine frame.

Water conductivity is a second, quieter variable. Resin that is exhausted lets conductivity climb, and the gap behaves differently at 10 μS/cm than it does at 1 μS/cm. Most builders publish a working band. If your conductivity drifts upward through a shift, change the resin before you touch the cutting parameters.

Material choice changes how much of this matters. Aluminium and copper load the water with fine particles quickly, so flush discipline is tighter than on tool steel. On 6061, 7075, and C110 copper, expect to clean more often. On 4130 or 4140 steel, the debris settles faster and the water stays workable longer.

• 1
  Nozzle contactSeat the nozzle on the work; distance costs pressure fast.
• 2
  Clean the tankOld sludge returns through the nozzles as instability.
• 3
  Watch conductivityExhausted resin changes gap behavior mid-shift.
