An undercut is any geometry that blocks the part from pulling straight off the core. A side hole in a housing, a snap hook, a thread, an internal clip: all of them need steel that travels sideways before the ejector system pushes the part out. The slide action mold side action device is that steel, plus the wedge, the wear plates, the guide way, and the retainer that keep it moving in one direction only.

The cycle is mechanical, not electrical. As the mold opens, an angled horn pin or a cam on the A-side pushes the slide body away from the part. The slide travels laterally for a distance set by the undercut depth plus clearance, usually 3–10 mm on small parts and more on large appliance or automotive tooling.

Once the slide clears, the part can be ejected without dragging on the undercut. When the mold closes, the same horn pin drives the slide back home, and a heel block or wedge locks it against injection pressure. The lock is what takes the load. Without it, the slide would push back and flash the part.

Every element in that chain has to hold position at mold temperature. A slide body that moves 0.01 mm during injection can flash a 0.2 mm witness line along the undercut. On a visible class-A surface, that line becomes scrap.

Injection pressure acts on the projected area of the slide face. A 30 mm × 20 mm slide face at 800 bar sees roughly 48 kN pushing it back toward the cavity. That force lands on the heel block, the wear plate, and the guide way, not on the slide body itself. This is why side actions fail at their contact surfaces long before the steel body cracks.

The sliding surfaces also run dry or near-dry. Molders grease them at setup, but a 30-second cycle at 200 °C cooking the lubricant means the surfaces are effectively metal on metal. Wear plates in bronze or hardened tool steel take that abuse so the slide body does not.

Heat is the second load. The slide sits near the cavity, so it grows with the mold. If the slide body and the guide way are different materials, they grow at different rates. At 200 °C a 150 mm aluminum guide block can grow about 0.7 mm; the same block in tool steel grows closer to 0.25 mm. That gap changes the fit you measured at room temperature.

Finally, cycle count matters more than peak load. A slide that survives 10,000 shots may still be out of tolerance at 300,000. Wear is cumulative, and the clearance that opens up shows as flash first, then as a stuck slide.

The sliding fit between the slide body and the guide way is the number that matters most. A common target is 0.01–0.02 mm clearance per side on a 50 mm wide slide, tight enough to stop flash and loose enough to run at temperature. Below 0.005 mm per side, the slide will gall on a hot mold. Above 0.04 mm, you will see flash.

Wear plate thickness usually lands between 4 mm and 12 mm. The plate should be replaceable without scrapping the slide body, so it is doweled and bolted, not welded. Holes for dowels need to be reamed, not drilled, if you want the plate to come back to the same spot after service.

Surface finish on the sliding faces does not need to be a mirror. Ra 0.4–0.8 μm is a practical target. A polished face holds less grease than a fine-ground one, and grease retention is what keeps the slide alive between service intervals. Ground faces at Ra 0.8–1.6 μm are often the better choice.

Angles on horn pins and cam surfaces are typically 15° to 25° from the mold axis. Steeper angles move the slide further per millimeter of mold opening but raise side load on the pin. Under 15° the pin is stronger but the mold gets taller.

Most slide bodies are not one setup parts. The guide way faces, the cam angle, the undercut form, and the mounting holes usually sit on four or five different orientations. On a 3-axis machine that means multiple fixtures and re-datuming at every flip. Every re-clamp adds stack-up error, and stack-up is what kills slide fit.

On a 5-axis machine the part stays in one vise. The cam angle and the guide way faces are cut in the same coordinate system, so the relationship between them is set by the machine, not by the fixture. We run 16 simultaneous 5-axis machining centers, which is where most slide components land. A 4,000 mm maximum processing size covers the long slides used in large appliance and automotive tools.

The undercut form itself is often a mirror of the part geometry. That surface should be cut with a ball or bull nose tool and then hand-polished to the required finish. Sharp internal corners on the undercut are a crack starter. Add a 0.5 mm corner radius minimum unless the part print forbids it.

Hardened slides are a different job. Tool steel at 48–52 HRC needs the roughing done before heat treat and the finishing done after, either by hard milling or by grinding. We plan the heat-treat allowance into the program so the finished slide still meets ±0.005 mm.

Slide bodies in low-volume tooling are often 1.2343 or 1.2344 tool steel, pre-hardened around 38–42 HRC. They machine well and hold wear reasonably. For high-volume tools, 48–52 HRC is common on the sliding faces, with the body left softer where it does not wear.

Wear plates are usually bronze or hardened steel. Bronze plates are easier on the mating surface and self-lubricating to a degree. Hardened steel plates last longer but need a harder mating face or they will wear it instead. Match the pair, not just the plate.

Heel blocks and wedges see the highest load, so they are typically hardened tool steel at 50–54 HRC, ground after heat treat. Aluminum bronze (C95400) is also used for heavy-duty heel blocks because it resists galling under high pressure.

Guide pins and horn pins are usually 17-4PH or 4140, hardened and ground to a sliding fit. In corrosive or medical molding, 420 or 440C stainless is common. We machine 17-4PH (SUS630) and 440C regularly, along with 4140 and 4340 for the larger pins.

Aluminum slides exist, mostly in prototype and low-volume tooling where cycle count is low. 7075-T6 gives the best strength-to-weight of the aluminum options, but it will not survive the wear of a hardened steel plate for long. Use it where the slide is light and the run is short.

The first is galling on the sliding surface. It starts as a rough patch, then picks up metal, then seizes. Galling usually comes from too little clearance, a dry surface, or a material pair that should never have been matched, like two similar hardened steels running against each other. The fix is a bronze plate on one side or a coating on the other.

The second is heel block wear. The heel takes the injection load, so it wears into the slide body over time. Once the heel wears, the slide moves back under pressure and flashes. A replaceable hardened heel insert solves this. If the heel is machined into the slide body, the whole slide gets scrapped.

The third is horn pin bending. A steeper cam angle, a pin that is too small for the side load, or a mismatch between the pin and the slide bore will bend the pin. Once it bends, timing drifts and the slide may not fully retract. Check the pin diameter against the side load before you commit to a 25° angle.

All three failures show up as flash or drag marks on the part first. If you see a witness line along an undercut, stop the press and check the slide clearance before you chase the injection profile.
