A pipe flexion machine does one physical thing: it bends metal past its yield point and leaves permanent deformation in a controlled arc. Everything in a specification list exists to keep that arc inside tolerance after the tooling is removed. If you read a datasheet as a list of numbers, you miss the point. The numbers describe how the machine resists three enemies: springback, wall thinning and ovality.

Three variables set the difficulty of any bend. Outside diameter, wall thickness and centerline radius. Their ratios get names you will see in every requirement document. Wall factor is OD divided by wall thickness. D of bend is centerline radius divided by OD. A 25 mm OD tube with a 2 mm wall has a wall factor of 12.5, which is comfortable. The same tube at a 25 mm centerline radius has a D of bend of 1.0, which is not.

That is why two machines with the same maximum OD can be completely different products. A bender rated for Ø60 mm tube at 3D may fail on the same Ø60 mm tube at 1D. Mandrel support, boost pressure, wiper die clearance and clamping force all have to be sized for the tighter case. Ask for the rating at a stated D of bend, never as a bare diameter.

Cold bending is the normal case. Requirements written for cold bending assume the tube enters at ambient temperature and the only heat in the process comes from friction and plastic work. Hot bending changes the rules, because yield strength drops and springback shrinks. If a machine is bought for cold work, do not assume it will hold tolerance on preheated stock without a new setup.

Bend torque is the requirement that decides whether the machine stalls. It scales with section modulus, material yield strength and the distance from the bend die center to the point of force. A thick-wall stainless tube can demand several times the torque of an aluminium tube of identical OD. A machine that bends 6061 aluminium all day may not touch 316L at the same size.

The drive type matters for repeatability, not just for power. Hydraulic drives give high torque and tolerate overload, but oil temperature changes viscosity and can drift the bend angle over a long shift. Electric servo drives hold angle by encoder count and repeat well, but they have a torque ceiling that cannot be exceeded. Most modern cells use servo for the bend axis and hydraulic or pneumatic pressure for the mandrel.

Clamping and pressure die force are separate requirements and are often underspecified. The clamp die has to grip the tube hard enough to prevent slip without crushing it. Thin-wall tube at high torque is the hard case: enough grip to stop slipping, little enough force to avoid an oval cross section at the clamp. Pressure die force follows the tube along the bend and controls wall support on the outside of the arc.

Bend speed sits between quality and cycle time. Running too fast on a tight radius pulls material instead of flowing it, which shows up as a rippled inside radius or a torn outside wall. A machine that lets you program a slow approach and a slower finish pass gives the operator a way out. Fixed single-speed machines remove that lever.

Tooling is where most bend failures are decided, long before the machine moves. The bend die sets the centerline radius. The clamp die and pressure die hold the tube against it. The mandrel supports the inside of the arc. The wiper die supports the material just ahead of the tangent point. Each one has a clearance requirement against the tube surface, and those clearances are often tighter than the machine tolerance itself.

Mandrel choice follows the wall factor. Above roughly 20, a plug mandrel is often enough. Between about 8 and 20, a ball mandrel with one or two balls is typical. Below 8, you usually need a multi-ball mandrel with lube holes and a wiper die, and the setup becomes a craft. A machine that cannot pull a mandrel on a controlled axis, with adjustable advance, will not repeat on thin-wall work.

Wiper dies wear and they wear fast on stainless and titanium. The tip clearance has to stay in a narrow band. Too much clearance and the inside of the bend wrinkles. Too little and the die rubs, heats up and galls the tube. A requirement list should state whether the machine supports a wiper die at all, and whether the holder allows fine adjustment without shimming.

Radius change is a tooling cost, not just a setup cost. Every new centerline radius needs a new bend die, and often a matching clamp die and mandrel. If a part family spans several radii, the number of tool sets drives the real cost of ownership. Ask how many radii the machine can cover with one clamp die before you compare prices.

Springback is the reason a bender needs a control system at all. Metal bends elastically first and plastically after yield. When the tooling releases, the elastic part recovers. The recovered angle depends on material, wall factor, D of bend and how long the material sat at the end of the stroke. Aluminium 6061 and 304 stainless recover differently at the same geometry, so a machine that stores one springback value per program will drift when the material lot changes.

A practical requirement is a control that lets the operator enter a measured correction per material and per radius, and that applies the correction to the commanded angle. Over-bending by a fixed percentage is the crude version. Look for a machine that logs the correction so the next run starts closer. This is not a luxury feature on tight-radius work.

Elongation sets the hard limit. The outside wall of the bend stretches, and if the required strain exceeds what the material can take, it cracks. Low-ductility alloys and work-hardened tube fail early. If a part sits near that limit, no amount of machine accuracy saves it. The answer is a larger radius, a thinner wall, an annealed condition before bending, or a different process.

Tolerance on a bent tube is usually stated in three separate ways: bend angle, centerline radius and the position of the end relative to a datum. Angle tolerance of ±0.5° and radius tolerance of ±0.5 mm are common targets for automotive work. End position is the one that matters to the fixture, and it accumulates error from every bend in the sequence. A machine that measures and compensates per bend holds the last one as tightly as the first.

Real parts rarely have one bend. A tube with four bends in two planes needs the machine to rotate the tube between bends and keep track of where the previous bends left the datum. That is where the technical requirements get strict. The rotation axis has to index accurately, and the carriage has to feed a known length after the tube has already been deformed.

Feed accuracy on a straight section is easy. Feed accuracy after three bends is not, because the tube is no longer straight and the carriage grips a section that may be slightly out of line. Collet design and carriage guidance decide whether the fourth bend lands where the model says. On long parts, the tube also droops, and the support has to follow without adding drag.

Envelope limits are usually quoted as maximum OD, maximum wall and maximum centerline radius, but the controlling number is often the straight length between bends. If two bends are closer than the machine can clamp, the part cannot be made on that machine at all. Check the minimum distance between bends and the minimum straight length at each end before anything else. Our own cells run to a 4,000 mm maximum processing size, and the travel on the large platform is 4,000 × 400 × 150 mm, which sets the practical ceiling for long tube work.

For prototypes, the sequence is usually cut and bend, then trim the ends. For production, the sequence is chosen so the last operation is the most accurate one. That single decision changes the fixture design and the number of re-clamps, and it belongs in the requirement document alongside the machine spec.

Acceptance testing is the part of the requirement list that protects the buyer. A machine that meets every number in a brochure can still fail on your part. The test should use your material, your wall factor and your tightest D of bend, not the demonstrator tube the seller brings.

Measure three things on the first article: bend angle at each bend, centerline radius, and wall thickness at the outside of the tightest arc. Add ovality at the same section. Compare against the drawing, not against a feel. Repeat the run and check whether the second set of parts matches the first. Repeatability is a stronger signal than absolute accuracy on a single part.

Then run the part that worries you most. Thin wall, tight radius, stainless, several bends in different planes. If the machine needs a long setup and a skilled operator to hold that part, say so in the acceptance criteria. A machine that only works when the tool room stands next to it is a different purchase than one that runs unattended.

Keep the records. Angle corrections, tooling numbers and inspection results turn a one-off success into a process. At GreatLight, parts are inspected 100% before shipment, with raw material checks, in-process monitoring and a final inspection, and reports are available on request. That discipline applies to bent tube just as it does to machined parts.
